- Page 1 Steam Sterilizer Operation Manual Ningbo Jiangbei Woson Medical Instrument Co., Ltd Technical Publications TANDA Steam Sterilizer Operation Manual ASS0007 REV-E Operation Documentation All rights reserved © 2016 By Ningbo Jiangbei Woson Medical Instrument Co.,Ltd.
-
Page 2: Regulatory Requirements
Steam Sterilizer Operation Manual Regulatory Requirement This product complies with regulatory requirements of the following European Directive 93/42/EEC concerning medical devices. Ningbo Jiangbei Woson Medical Instrument Co., Ltd Address: No.25, Lane 300, Jinshan Road, Jiangbei District, Ningbo 315032, China Tel: 86-574-83022668 Fax: 86-574-87639376 Website: www.woson.com.cn... -
Page 3: Revision History
Please verify that you are using the latest revision of this document. Information pertaining to this document is maintained on manufactory. If you need to know the latest revision, please contact your distributor, sales representative, or our service dept. TANDA Model REV-E Page of 43... -
Page 4: Regulatory Requirements
The CE label affixed to the product testifies compliance to the Directive. The location of the CE marking is shown in this manual. In this manual there are present the CE certification and the Conformity. Check appendixes. TANDA Model REV-E Page of 43... -
Page 5: Table Of Contents
4.7 Sterilization Cycle ....................18 Chapter 5 Panel and Functions ..................19 5.1 Display Panel ......................19 5.2 Controlling Button ....................19 5.3 Sterilization Program .................... 21 5.4 Window of Sterilization Cycle ................21 TANDA Model REV-E Page of 43... - Page 6 Appendix 1 Instruments Preparation Procedure ............38 Appendix 2 Error Code List .................... 39 Appendix 3 Piping and Circuit Diagram ................ 40 Piping Diagram ......................40 Circuit Diagram ......................41 Appendix 4 The Standards of Testing ................42 TANDA Model REV-E Page of 43...
-
Page 7: Chapter 1 Introduction
This sterilizer can be used for dental clinic, laboratory, surgical room, emergency room, ophthalmology, gynecology and steam, cosmetic hospital and so on, by doctors and professionals. 1.3 Contraindication There is no any contraindication of this equipment. TANDA Model REV-E Page of 43... -
Page 8: Chapter 2 Safety
Label Description Symbol for Symbol for "SERIAL NUMBER" "MANUFACTURER" Symbol for "AUTHORISED Symbol for REPRESENTATIVE IN THE "CATALOGUE NUMBER" EUROPEAN COMMUNITY Symbol for Symbol for "DATE OF MANUFACTURE" "CAUTION" TANDA Model REV-E Page of 43... -
Page 9: General Safety Recommendations
Do not fill the caustic liquid into the water tank. ❖ Do not fill the caustic matter in the chamber. ❖ Use only high quality distilled water. ❖ Unplug the mains lead before inspecting or servicing the machine. TANDA Model REV-E Page of 43... -
Page 10: Safety Parts
Cut off current when the connected power is too high or unstable. Electronic Filter Filter the electromagnetic interference during working. Mechanical Protection Part Name Function Jiggle Switch Ensure the door closed completely, avoiding safety risk. Tray Tong Avoid scald when removing articles from the chamber TANDA Model REV-E Page of 43... -
Page 11: Operation Risk
Pollution risk Please clean the chamber after every time use to avoid rudimental contamination left inside chamber. 2.5 Protection Device Device Name Function Plastic or fabric glove Useful during load and remove articles, avoid scald. TANDA Model REV-E Page of 43... -
Page 12: Chapter 3 Receiving And Installation
Open the package and take the product out, remove the plastic bag then open the door to take all the accessories and check as following: Part Name Rack 1 piece Tray 3 sets Removal Tool 1 piece Draining Tube 1 piece Power Supply Cable 1 piece Door Gasket 1 piece TANDA Model REV-E Page of 43... -
Page 13: Optional Accessories
❖ The temperature of enviroment: 5-40℃ ❖ The humidity of environment: ≤85% ❖ Atmosphere pressure: 860Hpa～1060Hpa ❖ An earth connection is essential. CAUTION: Do not place any stuff which easily melts near the sterilizer. TANDA Model REV-E Page of 43... -
Page 14: Installation
Do not put any heavy stuff on the power wire to avoid damage of power wire. Do not use other power wire to avoid damage of sterilizer. Do not try to add the power wire to avoid accident and risk. TANDA Model REV-E Page of 43... -
Page 15: Chapter 4 Description And Specification
Standard green power switch Show temperature, pressure or other sterilization information Displaying Window on the window, easy to operate during the working Door Handle Door handle with safe door locker to open and close the door TANDA Model REV-E Page of 43... -
Page 16: Rear View
Name Description Air Filter Filter the air and ensure air into chamber is clean Door Seal For sealing the door Water level sensor For used water tank Tray & Rack To load the articles TANDA Model REV-E Page of 43... -
Page 17: External Size
The loading size of sterilizer as followed: 4.6 Specification Basic Specification Rated voltage: a.c.220V-230V, 50Hz Rated power: 18L/ 1500VA, 23L/ 1700VA Fuse: T10A Operation temperature: 5～40℃ The board affording weight: 4000 N/m Noise: < 50db TANDA Model REV-E Page of 43... - Page 18 Main water tank volume: 18L (3.5L) 23L (4L) CAUTION: Water added into main water tank must be distilled water! Water temperature must be under 40℃. Test Method ❖ Vacuum Test ❖ B&D Test ❖ Helix Test TANDA Model REV-E Page of 43...
-
Page 19: Sterilization Cycle
The description identifies ranges of products and test loads. Non wrapped sterilized instruments are intended either for immediate use or for NOTE 2 non sterile storage, transport and application (e.g. to prevent cross infection). TANDA Model REV-E Page of 43... -
Page 20: Chapter 5 Panel And Functions
Used for prion, bacteria and virus etc. at 134℃, 210Kpa, 3 time vacuum. 5.2.4 “POROUS” Used for cotton yarn and similar articles at 121℃,110Kpa, 3 time vacuum. 5.2.5 TEST Choose Vacuum Test or BD Test. TANDA Model REV-E Page of 43... - Page 21 - UA (vacuum times, 1 time & 3 times & 5 times can be chose); - out (quit); Press TEST button to switch statuses; Press PROG. button to add count & confirm; Press START button to minus count. TANDA Model REV-E Page of 43...
-
Page 22: Sterilization Program
1st vacuum 1st pressurize 21.3 116.7 21.3 -80.4 80.8 -80.4 UA.2 Pr.2 UA.3 2nd vacuum 2nd pressurize 3rd vacuum 116.7 134.8 21.3 80.8 218.3 Pr.3 3rd pressurize Sterilization Exhaust 21.3 90.2 -80.4 0.11 PASS TANDA Model REV-E Page of 43... - Page 23 Steam Sterilizer Operation Manual 1 time pre-vacuum program example: UNPACKED 134℃ 21.3 21.3 116.7 -80.4 80.8 UA.1 Pr.1 Preheating 1st vacuum 1st pressurize 134.8 21.3 21.3 218.3 -80.4 Sterilization Exhaust 90.2 0.11 PASS TANDA Model REV-E Page of 43...
-
Page 24: Chapter 6 Operation Process
Fill in distilled water from the top of sterilizer. ( pic 6-2) CAUTION: Use distilled water only to extend the life time of sterilizer. Do not tilt the sterilizer when the reservoir is full of water. TANDA Model REV-E Page of 43... -
Page 25: Alarming If Used Water Reservoir Is Full
(pic 6-4) pic 6-4 Tray arrangement note: ❖ Read the following instructions for proper placing of articles and material. ❖ Make sure that the articles of different materials are separated and placed on different trays. TANDA Model REV-E Page of 43... -
Page 26: Closing The Door
Or you can push the door in while you turn the door handle. Anyway, latch the door handle completely. If you are sure the door has not been closed properly, adjust the door. TANDA Model REV-E Page of 43... -
Page 27: Starting A Program
20-50mins. It depends on the articles being sterilized, the initial temperature, and the program you selected. The Process of Sterilization Pre-heating: Display HE Chamber will start to be pre-heating when turning on the power switch, and keeping the chamber warm. - - - TANDA Model REV-E Page of 43... - Page 28 End: Display ED The buzzer make a sound means the total sterilization processes have been finished, then wait for the pressure down to “0” bar at the steam manometer on command front panel. TANDA Model REV-E Page of 43...
-
Page 29: End Of The Sterilization Working Cycle
If do not use it for a long time or for storage, please unplug the power cord. ATTENTION: During the sterilizing, we suggest that you use the indicator tape. Put them in the chamber in order to ensure reliability of sterilization. TANDA Model REV-E Page of 43... -
Page 30: Abnormal Exiting
In this state the air release solenoid valve will be opened and exhaust air. You have to cancel this information by press ”start/stop” button, and then to back normal state window. WARNING: Do not try to open the door if the pressure does not show “0”kPa. TANDA Model REV-E Page of 43... -
Page 31: Chapter 7 Essential Information
…add any chemicals or whatsoever analogous water to the sterilizer. ❖ …attempt to sterilize volatile substances, toxic materials or other unsuitable loads. Refer to your “Authorized Person” for advice. ❖ …place the sterilizer in direct sunlight. TANDA Model REV-E Page of 43... - Page 32 Steam Sterilizer Operation Manual ❖ …place the sterilizer on heat sensitive surfaces. ❖ …use inappropriate cleaning materials. ❖ …drop or abuse the sterilizer. ❖ …use in areas of risk associated with flammable materials or gases. TANDA Model REV-E Page of 43...
-
Page 33: Chapter 8 Maintenance
Use warm soapy water for keeping marks of sterilizer persistent, but ensure any soap residues are completely removed by wiping both the gasket and the vessel again with water using a lint free damp cloth. TANDA Model REV-E Page of 43... -
Page 34: Weekly Maintenance
Water draining filter (pic 8-1) might has been jammed by some dust because of use for a long-term, so effect of vacuum and drying would be influenced. Some tiny impurity might be deposited on the filter after a long-term use, blocking the filter, so as to influence the effect of TANDA Model REV-E Page of 43... -
Page 35: Monthly Maintenance
There are some impurities and some toxins had been left behind in the reservoir because distilled water stored for a long time. Need to drain and clean regularly. As pic 8-3 shows, loose the screw by screw-driver, and open the cover to clean inside. TANDA Model REV-E Page of 43... -
Page 36: Other Maintenance
Next, embed it equably by hands. The inner edge of gasket may be ectropion during embedding it in the door groove. You’d better to tight it back to the groove by using screwdriver carefully. TANDA Model REV-E Page of 43... -
Page 37: Servicing By The Approved Technician
Checking the hydraulic connections. Checking the safety thermostat. Cleaning the sterilization chamber. Cleaning the trays and the tray rack. Cleaning the reservoirs. Replacing the water filter. Replacing the air filter. Replacing the door gasket. TANDA Model REV-E Page of 43... -
Page 38: Chapter 9 Transportation And Storage
Package is used in transportation for protecting product, conveniently delivery and sales. The sterilizer package requirement should as followed: Product can not over 3/4 volume of package. Product should be fix inside the package. Package bag should be higher than product 6mm. TANDA Model REV-E Page of 43... -
Page 39: Appendix 1 Instruments Preparation Procedure
4. Run selected sterilization programs. 5. Take out and store. CAUTION: Make sure the packing of articles in good condition. The sterilized articles still exist lots of warmth. Do not fold in order to exhaust the residual steam. TANDA Model REV-E Page of 43... -
Page 40: Appendix 2 Error Code List
In-chamber sensors temp. differs too much (for dual sensors only) Er27 Air pressure low (due to high altitude) Er71 Pressure sensor output low Er72 Pressure sensor output high Er98 Out of power during cycle Er99 Forced exit program TANDA Model REV-E Page of 43... -
Page 41: Appendix 3 Piping And Circuit Diagram
Main Water Pump The Distilled Water Tank Vacuum Pump Air Release Valve Condensate Collector Water Supply Valve Relief Valve Vacuum Valve Distilled Water Drain Valve Air Return Valve Used Water Drain Valve Pressure Sensor Temperature Sensor TANDA Model REV-E Page of 43... -
Page 42: Circuit Diagram
Printer Single Port Line No.4 (Black) Steam Generator Heating Ring Temperature Sensor N (Black) Chamber Temperature Sensor L (Red) Heating Ring Pressure Temperature Sensor Sensor 1 Line No.1 (Red) Power Socket Fuse Ground Fuse Power Switch TANDA Model REV-E Page of 43... -
Page 43: Appendix 4 The Standards Of Testing
Water level state e) State of door In the condition of the vacuum - 0.07Mpa, the sterilizer shouldn’t leak Quantum of Leakage 0.13kPa/min. The sterilizer can’t leak under the work pressure Leakage Forbidden TANDA Model REV-E Page of 43... - Page 44 Dryness, Solid and load. Any remaining water droplets on the inner side of pouch should Wrapped Load evaporate within 5 min. For solid load the moisture content should not exceed 0.2%. TANDA Model REV-E Page of 43...
