ROG STRIX G17 (G713R) series
Service Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G713R and is the answer not in the manual?

Questions and answers

Summary of Contents for Asus G713R

  • Page 1 ROG STRIX G17 (G713R) series Service Guide...
  • Page 2 LIMITATION OF LIABILITY Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property;...
  • Page 3 Disclaimer ASUS is not responsible for direct, indirect, intentional or unintentional damages resulting from improper installation and operation. Safety precautions • Keep liquids or moisture away from your Notebook PC before installing or removing any components. • Ensure to place your Notebook PC on a stable surface before installing or removing any components.
  • Page 4: Table Of Contents

    Table of Contents ⚫ Service Overview ⚫ ROG STRIX G17 (G713R) Overview ⚫ Components Top View ⚫ Components Bottom View ⚫ Repair Overview ⚫ Appropriate Tools ⚫ Key parts and Related Parts ⚫ Disassembly steps : • BOTTOM CASE •...
  • Page 5: Service Overview

    Service Overview • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs. • To provide the best service, we have provided the below information for technicians from distributors and resellers to perform the complete device disassembly and assembly.
  • Page 6: Rog Strix G17 (G713R) Overview

    ROG STRIX G17(G713) Overview Bottom View Top View ❶ Air vents ❶ Display panel ❷ Audio speakers ❷ Status indicators ❸ Compartment cover ❸ Capital lock indicator ❹ Keyboard ❺ Array microphones ❻ Power button ❼ Numeric Keyboard ❽ Touchpad Left View Right View ❶...
  • Page 7: Components Top View

    Components Top View LCD COVER MODULE KEYBOARD MODULE SPERAKER MIC FFC 4P MAIN BOARD DDR4 TP PCB TAPE 0.5MM L70 DDR Absorber THERMAL MODULE ASSY SSD THERMAL PAD TP FFC 8P 0.5 L133 LCD BEZEL TOUCHPAD GPU FAN / CPU FAN EDP CABLE 17.3‘...
  • Page 8: Components Bottom View

    Components Bottom View LCD COVER MODULE MAIN BOARD KEYBOARD MODULE KB BRKT LED BD CONDUCTIVE TAPE ANTENNA CABLE ACETATE CLOTH TOP CASE SPONGE LCD PANEL ADHESIVE SOUL KEY BOARD LCD BEZEL BASE CASE INDICATOR BOARD BEZEL ADHESIVE UP BEZEL ADHESIVE SIDE BEZEL ADHESIVE LCD Panel THERMAL MODULE ASSY...
  • Page 9: Repair Overview

    Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
  • Page 10: Appropriate Tools

    Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ROG STRIX G17 (G713R) series notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade PLASTIC CARD T=0.35mm PLASTIC PICK T=0.5mm...
  • Page 11 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ROG STRIX G17 (G713R) series notebook. ❺ ❼ ❶ ❸ ❻ ❷ ❹ Item Part Name Memo ❶ Silicone scraping pen Please store it in the environment of 10 ~ 40 ℃.
  • Page 12: Bottom Case

    BOTTOM CASE For G713RX/RS/RW/RM (X60) Disassembly Notice Screws Spec Torque (kgf-cm) There are cables connected Step 1 : Remove screws *10pcs. M2.5*12L(4.2,0.8)(K) #1 2.5±0.2 to MB, so please do not pull out Step 2 : Use plastic blade to pry the bottom case. M2.5*6L(4.5,0.5)(K)#1 2.5±0.2 the bottom case directly.
  • Page 13 BOTTOM CASE Disassembly Notice Step 1 : Remove screws*2pcs and LED module. Step 2 : Disconnect LED BD FFC*2pcs. Screws Spec Torque (kgf-cm) Assembly Notice M2*3.5L(4,0.8) (K)#1 2.0±0.2 Please follow red mark below to tidy FFC. Remove If FFC is damage during disassembly, please replace new one.
  • Page 14: Battery

    BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet. Screws Spec Torque(kgf-cm)
  • Page 15: Ssd And Ddr

    SSD and DDR Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw and SSD *1pc. Screws Spec Torque (kgf-cm) Assembly Notice Step 2 : Remove Thermal Pad and Graphite M2*2.5L (5,0.5) (K) #1 2.0±0.2 Sheet.
  • Page 16: Soul Key Board & Wifi Card

    SOUL KEY BOARD & WIFI CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw *1pc SOUL KEY BD. and remove Screws Spec Torque (kgf-cm) Step 2 : Disconnect the RF CABLE connectors *2pcs. M2*3.5L (4,0.8) (K) #1 2.0±0.2 Step 3 : Remove the screw *1pc.
  • Page 17: Speaker

    SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Release the tape *2pcs. Step 2 : Disconnect the SPEAKER connector. Assembly Notice Step 3 : Remove the SPEAKER. For Speaker assembly, please follow the mark below to tidy up cable. Disconnect Speaker cable Release...
  • Page 18: Fan

    Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the FAN connectors *2pcs.(yellow mark) Torque (kgf-cm) Screws Spec Step 2 : Remove screws *6pcs.(red mark) Step 3 : Release tapes *2pcs. M2*4.5L (4.5,0.8) (K) #1 1.8±0.1 Step 4 : Remove FAN *2pcs.
  • Page 19: Main Board With Thermal Module

    MAIN BOARD With THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the connectors. (yellow mark) Screws Spec Torque (kgf-cm) Assembly Notice Step 2 : Tear off TP MODULE GND CONDUCTIVE TAPE. Step 3 : Remove screws *8pcs.(red mark) M2*3.5L (4,0.8)(K) #1 2.0±0.2...
  • Page 20: Thermal Module

    THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Please follow the reverse screws numbers to remove screws *8pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the THERMAL MODULE from MB. M2*3.5L (4,0.8) (K) #1 2.5±0.2 Recommend that the force point is at green block, and pull up thermal module to take it out.
  • Page 21: Main Board

    MAIN BOARD Mainboard connector placement LED BAR 1 Indicator+Mic EDP CABLE CPU FAN VGA FAN RF Cable LED BAR 2 SPEAKER WIFI ANTENNA TP Pad KB FPC BATTERY KB Function Supports using JIG BOARD to refresh F1 BIOS Supports using JIG BOARD to refresh F1 BIOS For G713RM/RS/RW For G713RC...
  • Page 22 MAIN BOARD G713ZE/ZC =X50 Materials on mainboard G713ZE/ZC =X50 G533QS CPU ABSORBER(X50 GPU) G513QC MB AL+ABSORBER G513QC HDMI GASKET G713ZX/ZW/ZM=X60 G533QS GPU ABSORBER(G733ZW/ZM) G533ZX GPU ABSORBER(G733ZX) G513RX/RW/RS/RM/RC G513RX AMD PCB TAPE|TENYI G533ZX TYPEC AL FOIL MYLAR G532LWS CPU BKT ASSY|WAN CHENG G533QS MB MYLAR|TENYI Please refer Repair Notice SOP for Liquid metal rework.
  • Page 23: Indicator Bd

    INDICATOR BD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the INDICATOR BD . Assembly Notice 1-1. Tear off KB BRKT LED BD CONDUCTIVE TAPE *2pcs and If FFC is damage during disassembly, please disconnect FFC.
  • Page 24: Mic Board

    MIC BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws*4pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the Hinge cover. Step 3 : Disconnect the FFC and remove the screws *2pcs. M2*3.5L (4,0.8)(K) #1 2.0±0.2 Step 4 : Remove the MIC BD and MIC RUBBER *2pcs.
  • Page 25: Touchpad Module

    TOUCHPAD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Disconnect the FFC. Assembly Notice Step 2 : Tear off GND CONDUCTIVE TAPE. M2*3.5L (4.5,0.8) (K)#1 2.0±0.2 Step 3 : Remove screws *3pcs. For New TOUCHPAD Module assembly, please follow the steps below.
  • Page 26: Keyboard Module

    KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws*6pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the KEYBOARD MODULE. M2.5*4.5L (4.5,0.8) (K)#1 2.5±0.2 Open and remove Back...
  • Page 27 KEYBOARD MODULE Assembly Notice Please be sure to pull out adapter and disconnect the battery. Please follow the mark location to assembly and tidy up WIFI ANTENNA. ANT1 (Black cable) ANT2 (White cable) ANT3 ANT4 (Gray cable) (Blue cable) Back...
  • Page 28: Lcd Bezel

    LCD BEZEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Remove LCD BEZEL. Assembly Notice Start from the bottom right corner of the bezel, using the Plastic Blade to pry open bezel. When reuse the LCD BEZEL: Please paste new LCD BEZEL ADHESIVE before assembly BEZEL.
  • Page 29: Lcd Panel

    LCD PANEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *8pcs,then remove Right hinge. Screws Spec Torque (kgf-cm) Step 2 : Unlock hinge cap hook ,then remove Left hinge. Step 3 : Pull out LCD adhesive *2pcs. M2*3L (4.5,0.5)(K) #0 2.0±0.2 Step 4 : Disconnect the EDP cable then separate LCD PANEL.
  • Page 30 LCD PANEL Assembly Notice Please be sure to pull out adapter and disconnect the battery. When reassembly Hinge, please make sure to paste the hook rubber. (2pcs) Before assembly Left hinge, please follow the steps to tidy up EDP cable, hinge cap and L HINGE.
  • Page 31: Lcd Cover

    LCD COVER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the EDP CABLE. Assembly Notice When reuse the LCD COVER : Please paste LCD ADHESIVE R and L *2pcs (yellow mark). (New LCD COVER already contains LCD ADHESIVE R and L *2pcs) Remove Please follow the mark below to tidy up EDP cable on LCD COVER.
