Nozzle Types (Type 1-2) - Aqua Control COMBO Series Instruction Manual

Horizontal Combo units are shipped fully assembled on a shipping pallet.
1. Remove straps holding the fountain to the pallet and remove any cartons that were shipped with the fountain on the pallet. (lights, cord, etc.).
See diagram. DO NOT CUT SUPPORT STRAPS
2. Inspect for any visible damage that may have occurred during shipping. Contact Aqua Control, Inc. immediately if any damage is found. DO NOT
CUT THE SUPPORT STRAPS holding the discharge to the lower pump.
3. See the nozzle, cord, and light instructions for attaching these to the unit.
Find the nozzle that is being attached to this unit in the table below. This table will tell you which of the five nozzle types a nozzle falls under to locate the correct
instructions.
FOUNTAIN NOZZLES
Buckingham
Cluster Arch & Sky Geyser
Daffodil
Double Arch & Sky Geyser
Fleur De Lis
Spider & Arch & Sky Geyser
Spoke & Sky Geyser
Tiara
Tornado & Sky Geyser
Weeping Willow & Sky Geyser
2
COMBO SERIES HORIZONTAL FOUNTAIN
NOZZLES
NOZZLE TYPE
Type 1
Type 1
Type 2
Type 1
Type 1
Type 1
Type 1
Type 1
Type 2
Type 1
