Summary of Contents for AGD ANDANTE MKII
- Page 1 AGD Productions, Inc. AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 1 of 27...
- Page 2 AGD Productions, Inc. AGD Andante MKII Reference Preamplifier DAC – Phono Stage – Analog Hi-End Streamer by AGD Productions, Inc. AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 2 of 27...
- Page 3 UNCONTROLLED OUTDOOR CONDITIONS. BE CERTAIN TO INSTALL IT IN A SECURE LOCATION FROM WHICH IT CANNOT FALL OR TIP OVER. TIME SPENT FAMILIARIZING YOURSELF WITH THIS MANUAL WILL BE WELL REWARDED. AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 3 of 27...
-
Page 4: Table Of Contents
Introduction ..............page 8. Main Features ..............page 9. Unpacking the AGD ANDANTE MKII ......page 10. Installation of the AGD ANDANTE MKII ......page 11. Front Panel Functions and Operation ......page 12. Back Panel Connectors ........... page 14. -
Page 5: About This Document
This user manual is an integral part of the AGD “ANDANTE MKII” and must be available and consulted prior to the installation of the equipment. - Page 6 The AGD Audio Design team is confident the “Andante MKII” will meet your expectations and as a team we will always stand in support of your needs and future requirements.
-
Page 7: Important Safety Information
AGD Productions, Inc. IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS: All the safety and operating instructions of your AGD ANDANTE MKII PREAMPLIFIER should be read before power is applied to the equipment. RETAIN OWNER'S MANUAL: These safety and operating instructions should be retained for future reference. -
Page 8: Introduction
AGD Productions, Inc. INTRODUCTION The AGD “ANDANTE MKII” is a complete audiophile Analog and Digital Reference Preamplifier that delivers a unique set of features and components in a single beautifully crafted single billet aluminum cabinet. With its built-in fully balanced phono stage (MM & MC), the sophisticated R2R DAC with DSP functions, and full-fledged versatile Network Player 100% compatible DNLA/UPNP standard. -
Page 9: Main Features
Three analog outputs (for multi-amplification solutions. 1 XLR balanced output (6.4VRMS max) 2 Single-ended stereo output (low/high pass X-Over customizable) Remote control. AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 9 of 27... - Page 10 AGD Productions, Inc. UNPACKING Unpacking All AGD products shipping boxes have been specially designed to protect their contents and special care has been taken to prevent damage under normal shipping conditions. When unpacking the product: • Mishandling should be evident upon inspection of the flight case.
-
Page 11: Installation
AGD Productions, Inc. INSTALLATION POWER REQUIREMENTS: The AGD “ANDANTE MKII” has universal voltage input configuration and can operate between 90~264VAC 50/60Hz single phase. A detachable IEC power cable intended for use in the region where the unit is sold is included. -
Page 12: Front Panel Functions And Operation
AGD Productions, Inc. FRONT PANEL FUNCTIONS AND OPERATION All keys of the AGD ANDANTE MKII are touch-sensitive (no mechanical movement) hence attention to familiarize with their operation is required. The functions of the left end side switch group are: Stand-by - Switches the unit from stand-by to operational mode. - Page 13 Turn the volume control up by one step Menu navigation (up). Enter Apply input selection Select highlighted menu item. Volume Down Turn the volume control Down by one step Menu navigation (down) AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 13 of 27...
-
Page 14: Back Panel Connectors
AGD Productions, Inc. BACK PANEL CONNECTORS DIGITAL INPUTS The AGD Andante MKII has a complete front end of digital signal inputs. • All the Digital input connectors are located on the upper area of the back panel. • Please refers to the above picture to locate their positions and identify the functionality. -
Page 15: Analog Inputs
AGD Productions, Inc. BACK PANEL CONNECTORS ANALOG INPUTS: The AGD Andante MKII has four different analog inputs. • All the Analog input connectors are located on the bottom left area of the back panel. • Please refers to the above picture to locate their positions and identify the functionality. -
Page 16: Analog Outputs
One pair of XLR (balanced output) • 2 pairs of RCA (single ended outputs). The Andante MKII output interface is then capable of driving up to six different independent amplification channels. The buffer output stage circuit is designed around a professional grade operational amplifier ICs with output characteristics capable to drive any system of amplification thanks to an output impedance of ~50Ω... -
Page 17: Ac Power Entry Module
Fuse Holder IEC Power Cable Input The AGD “ANDANTE MKII” has universal voltage input configuration and can operate between 90~264VAC 50/60Hz single phase. A detachable IEC power cable intended for use in the region where the unit is sold is included. -
Page 18: Operation
ON. A red light will illuminate. The unit is powered-up. • Please note that LED lights of the ANDANTE MKII will illuminate the front panel area. •... - Page 19 THE AGD ANDANTE MKII streaming function is available via Ethernet port (LAN). • Once the LAN input is selected, the AGD ANDANTE MKII acts as DNLA, UPNP renderer or Airplay enabled player (and it is recognized as such buy the relevant application software in use).
- Page 20 Adroid/OS and Windows). • USB INPUT • THE AGD ANDATE USB module is based on the latest XMOS chipset and can decode any format available, MP3, WMA, MPEG-4 AAC, WAV, FLAC, AIFF, ALAC, DSD. • Sampling frequencies: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz and 768kHz...
-
Page 21: Remote Control Operation
AGD Productions, Inc. REMOTE CONTROL REMOTE CONTROL FUNCTIONALITIES: ▪ All functions of the AGD ANDANTE MKII are available via Remote control. ▪ The “ANDANTE MKII” is compatible with a standard Apple Remote type, included with the unit, ▪ The Remote control delivered with the unit is already setup to work with the ANDANTE MKII and does not require any additional setup. -
Page 22: Troubleshooting
• Incorrect operation is sometimes mistaken for malfunction. • If problems occur, see this section for troubleshooting information. • If problems persist, contact your authorized AGD Productions’ dealer. NO POWER • Examine the power cord to ensure that it is connected to both the AC mains connector and a working, un-switched, electrical outlet. - Page 23 ANDANTE MKII. IF ALL ELSE FAILS… • Contact your authorized AGD Productions, Inc. dealer and/or contact AGD Productions Customer Service at www.AGDproductions.com AGD ANDANTE MKII Operating Manual_Rev_0.2...
-
Page 24: Spécifications
Frequency: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz Resolution: 16, 24 & 32-bit. DSD64 (2.8224MHz and 3.0720MHz), DSD128 (5.6448MHz and 6.1440MHz) and DSD256 (11.2896MHz and 12.2880MHz), DSD512 (22.5792MHz and 24.576MHz). AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 24 of 27... - Page 25 Remote Infrared Trigger 12V, 0.1A DC (Custom Request) Output Flight Case 22”x 18”x 10” (560 x 457 x 254mm) Dimension Net Weight 22lb/10kg Gross Weight 29lb/13kg Input voltage Universal (110-240V, 50-60Hz) AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 25 of 27...
- Page 26 Directive: 2014/30/UE (EMC), 2014/35/UE (LVD), 2011/65/UE (RoHS) Palos Verdes Estates, March 28th, 2020 Alberto Guerra, President and CEO AGD Productions, Inc. ……………………………… AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 26 of 27...
- Page 27 AGD Productions, Inc. AGD ANDANTE MKII Operating Manual_Rev_0.2 Page. 27 of 27...
