Summary of Contents for AGD Andante
- Page 1 AGD Productions, Inc. AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 1 of 28...
- Page 2 AGD Productions, Inc. AGD Andante Reference Preamplifier DAC – Phono Stage – Analog Hi-Def Streamer by AGD Productions, Inc. AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 2 of 28...
- Page 3 UNCONTROLLED OUTDOOR CONDITIONS. BE CERTAIN TO INSTALL IT IN A SECURE LOCATION FROM WHICH IT CANNOT FALL OR TIP OVER. TIME SPENT FAMILIARIZING YOURSELF WITH THIS MANUAL WILL BE WELL REWARDED. AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 3 of 28...
-
Page 4: Table Of Contents
Introduction ..............page 8. Main Features..............page 9. Unpacking the AGD ANDANTE ........page 10. Installation of the AGD ANDANTE ........page 11. Front Panel Functions and Operation ......page 12. Back Panel Connectors ........... page 14. 10. AC Power Entry module ..........page 12. -
Page 5: About This Document
This user manual is integral part of the AGD “ANDANTE” and must be available and consulted prior the installation of the equipment. - Page 6 It took a long time to merge harmonically the two worlds into a single unit, delivering all the musicality required for a world class audio system. We at AGD believe the goals we set when we started this challenging design have been finally achieved.
- Page 7 AGD Productions, Inc. IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS: All the safety and operating instructions of your AGD ANDANTE PREAMPLIFIER should be read before power is applied to the equipment. RETAIN OWNER'S MANUAL: These safety and operating instructions should be retained for future reference.
-
Page 8: Introduction
(MM & MC), the sophisticated R2R DAC with DSP functions, and full-fledged versatile Network Player with seamless Roon, Tidal and Qobuz services integration, the “ANDANTE” is by design the perfect companion preamplifier for our “Vivace” and “The Audion” GaNTube Monoblocks. -
Page 9: Main Features
• Three analog outputs (for multi-amplification solutions. • 1 XLR balanced output (6.4VRMS max) • 2 Single-ended stereo output (low/high pass X-Over customizable) • Remote control. AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 9 of 28... - Page 10 AGD Productions, Inc. UNPACKING Unpacking All AGD products shipping boxes have been specially designed to protect their contents and special care has been taken to prevent damage under normal shipping conditions. When unpacking the product: • Mishandling should be evident upon inspection of the flight case.
- Page 11 AGD Productions, Inc. INSTALLATION POWER REQUIREMENTS: The AGD “ANDANTE” has universal voltage input configuration and can operate between 90~264VAC 50/60Hz single phase. A detachable IEC power cable intended for use in the region where the unit is sold is included.
-
Page 12: Front Panel Functions And Operation
AGD Productions, Inc. FRONT PANEL FUNCTIONS AND OPERATION All keys of the AGD ANDANTE are touch-sensitive (no mechanical movement) hence attention to familiarize with their operation is required. The functions of the left end side switch group are: Stand-by - Switches the unit from stand-by to operational mode. - Page 13 Turn the volume control up by one step ▪ Menu navigation (up). Enter ▪ Apply input selection ▪ Select highlighted menu item. Volume Down ▪ Turn the volume control Down by one step ▪ Menu navigation (down) AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 13 of 28...
-
Page 14: Back Panel Connectors
AGD Productions, Inc. BACK PANEL CONNECTORS DIGITAL INPUTS The AGD Andante has a complete front end of digital signal inputs. • All the Digital input connectors are located on the upper area of the back panel. • Please refers to the above picture to locate their positions and identify the functionality. - Page 15 AGD Productions, Inc. BACK PANEL CONNECTORS ANALOG INPUTS: The AGD Andante has four different analog inputs. • All the Analog input connectors are located on the bottom left area of the back panel. • Please refers to the above picture to locate their positions and identify the functionality.
- Page 16 One pair of XLR (balanced output) • 2 pairs of RCA (single ended outputs). The Andante output interface is then capable of driving up to six different independent amplification channels. The buffer output stage circuit is designed around a professional grade operational amplifier ICs with output characteristics capable to drive any system of amplification thanks to an output impedance of ~50Ω...
-
Page 17: Ac Power Entry Module
Fuse Holder IEC Power Cable Input The AGD “ANDANTE” has universal voltage input configuration and can operate between 90~264VAC 50/60Hz single phase. A detachable IEC power cable intended for use in the region where the unit is sold is included. -
Page 18: Operation
ON. A red light will illuminate. The unit is powered-up. • Please note that LED lights of the ANDANTE will illuminate the front panel area. •... - Page 19 THE AGD ANDANTE streaming function is available via Ethernet port (LAN). • Once the LAN input is selected, the AGD ANDANTE acts as DNLA, UPNP renderer or as ROON or AirPlay device (and it is recognized as such buy the relevant application software in use).
- Page 20 AirPlay or, for the open source application, BUBBLEUPNP (available in Adroid and Windows). • • THE AGD ANDATE USB module is based on the latest XMOS chipset and can decode any format available and specifically: • Sampling frequencies: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz and 768kHz...
-
Page 21: Remote Control Operation
AGD Productions, Inc. REMOTE CONTROL REMOTE CONTROL FUNCTIONALITIES: ▪ All functions of the AGD ANDANTE are available via Remote control. ▪ The “ANDANTE” is compatible with a standard Apple Remote type, included with the unit, ▪ The Remote control delivered with the unit is already setup to work with the ANDANTE and does not require any additional setup. -
Page 22: Troubleshooting
• Incorrect operation is sometimes mistaken for malfunction. • If problems occur, see this section for troubleshooting information. • If problems persist, contact your authorized AGD Productions’ dealer. NO POWER • Examine the power cord to ensure that it is connected to both the AC mains connector and a working, un-switched, electrical outlet. - Page 23 ANDANTE. IF ALL ELSE FAILS… • Contact your authorized AGD Productions, Inc. dealer and/or contact AGD Productions Customer Service at www.AGDproductions.com AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1...
-
Page 24: Specifications
Frequency: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz Resolution: 16, 24 & 32-bit. DSD64 (2.8224MHz and 3.0720MHz), DSD128 (5.6448MHz and 6.1440MHz) and DSD256 (11.2896MHz and 12.2880MHz), DSD512 (22.5792MHz and 24.576MHz). AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 24 of 28... - Page 25 Infrared Trigger Output 12V, 0.1A DC (Custom Request) Flight Case Dimension 22”x 18”x 10” (560 x 457 x 254mm) Net Weight 22lb/10kg Gross Weight 29lb/13kg Input voltage Universal (110-240V, 50-60Hz) AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 25 of 28...
- Page 26 Directive: 2014/30/UE (EMC), 2014/35/UE (LVD), 2011/65/UE (RoHS) Palos Verdes Estates, March 28th, 2020 Alberto Guerra, President and CEO AGD Productions, Inc. ……………………………… AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 26 of 28...
- Page 27 AGD Productions, Inc. AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 27 of 28...
- Page 28 AGD Productions, Inc. AGD ANDANTE REFERENCE DAC_PRE_PHONO_STREAMER Operating Manual_Rev1 Page. 28 of 28...
