Appendix A: Specifications - TP-Link TD-W300KIT User Manual

TD-W8961ND

Appendix A: Specifications

Standards and Protocols
Safety & Emission
Ports
LEDs
Network Medium
Data Rates
System Requirement
Working Temperature
Working Humidity
Storage Temperature
Storage Humidity
300Mbps Wireless N ADSL2+ Modem Router User Guide
General
ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5,
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE
802.3u, TCP/IP, PPPoA, PPPoE, SNTP, HTTP, DHCP, ICMP, NAT
FCC、CE
Four 10/100M Auto-Negotiation RJ45 ports（Auto MDI/MDIX)
One RJ11 port
Power, ADSL, Internet, WLAN, 1,2,3,4(LAN), QSS
10Base-T: UTP category 3, 4, 5 cable
100Base-TX: UTP category-5
Max line length: 6.5Km
Downstream: Up to 24Mbps
Upstream: Up to 3.5Mbps（With Annex M enabled）
Internet Explorer 5.0 or later, Netscape Navigator 6.0 or later
Win 9x/ ME/ 2000/ XP/ Vista/Windows 7
Physical and Environment
0 ~ 40
℃ ℃
10% ~ 90% RH (non-condensing)
-40 ~ 70
℃ ℃
5% ~ 90% RH (non-condensing)
65
