SUNTECK STFP D50 Owner's Manual

In wall recessed electric fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
In Wall Recessed Electric Fireplace
WARNING: Read and understand this entire owner's manual, including
all safety information before plugging in or using this product. Failure to do
so could result in fire, electric shock, or serious personal injury.
CAUTION: Keep this owner's manual for future reference. If you sell or
give this product away, make sure this manual accompanies this product.
Model Number: STFP D50
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STFP D50 and is the answer not in the manual?

Questions and answers

Related Manuals for SUNTECK STFP D50

Summary of Contents for SUNTECK STFP D50

  • Page 1 OWNER’S MANUAL In Wall Recessed Electric Fireplace Model Number: STFP D50 WARNING: Read and understand this entire owner’s manual, including all safety information before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information..............3 Preparation................4 Operating Instruction..............8 Care and Maintenance............11 Troubleshooting..............12...

  • Page 3: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. Any use of this appliance other than that recommended by the manufacturer in the owner manual may cause fire, burns, electric shock or other serious injuries or death.

  • Page 4: Preparation

    PREPARATION Installation: Please assemble on a soft and clean surface to prevent damage or scratch. Get off the Front Frame Installing the Fireplace. Unscrew the screws (Size M4x8mm) on both Secure the fireplace to the wall using anchor sides, and get off the Front Frame. screws 4x25mm Hanging the Front Frame Hang the front frame on the fireplace and gently push on the lower part of the frame until it...
  • Page 5 4. Two Options for Assembly Option 1: Electric fireplace with log Option 2: Electric fireplace with Crystal Embers Step 1: Remove the glass frame from the fireplace.
  • Page 6 Step 2: Unscrew 2 silver screws on each side of the fireplace body by a Philips screwdriver shown as below. Step 3: Take out of the fire log first, then lay out all of the crystal embers above the plastic below.

  • Page 7: Wall Mount Installation

    PREPARATION Wall Mount Installation: Please assemble on a soft and clean surface to prevent damage or scratch. .Mark the location of the bracket on the wall and then mount the bracket to the wall using the supplied screws and drywall anchors. The hooks in the bracket MUST be pointed away from the wall, upward, and level.

  • Page 8: Operating Instruction

    Wall Recessed Installation: OPERATING INSTRUCTION Read all instructions and warming before operating the appliance. Ensure that all controls are in the "OFF" position before plugging the appliance into a properly grounded electrical outlet. Flame and heater can be presented separately or at the same time. The Fireplace control functions can be accessed in two ways.

  • Page 9: Flame Control

    Figure 4 Figure 5 Using the Control Panel Figure 6 Control Panel Control panel is located in the bottom right corner of the unit. Button A Power ON / OFF Press the power button to turn on the unit. Press again to turn off the unit. Hide Function: Press the power button 3 seconds, can turn off the button light and vice versa.

  • Page 10: Heater Control

    Button C Heater Control Press the heater control to turn on and off the heater. Button Press Heater Condition Display Value Fireplace Appearance Press Heater Off Press Lower Power 750W Power eating Press High Power 1500W Power Heating Press Heater Off When the heater is turned on, press and hold the heater control button for 3 seconds to enter temperature adjustment mode.

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE WARNING: Before attempting to perform any maintenance on this unit, turn all controls to the “OFF” position and unplug. Allow the unit to be “OFF” for at least 10 minutes before any maintenance is applied in to allow all components to cool down properly.

  • Page 12: Troubleshooting

    TROUBLESHOOTING WARNING : Turn off the unit, unplug and allow the unit to cool down for at least 10 minutes before attempting to perform any service. Only a qualified professional electrician should attempt to service or repair the unit. PROBLEM POSSIBLE CAUSE SOLUTION Simulated flame...
