- Page 1 INSTALLATION MANUAL RO BIF BEF- CLASSIC SLIM...
- Page 2 Failure to do so WARNING could result in fire, electric shock, or serious personal injury. Keep this owner's manual for future reference. If you sell or give this product away, make sure this manual accompanies this product CAUTION www.sunteck.ca info@sunteck.ca...
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION! WARNING When using electrical appliances basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read all instructions before using this heater This heater is hot when in use. To avoid burning, do not touch hot surface. If provided, use handles when moving this heater. -
Page 4: Parts And Hardware
Preparation This product includes a GLASS panel! Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts and assembly steps are grouped for wall-hanging or recessing use. - Page 5 PRODUCT DIMENSIONS MODEL NUMBER 49-3/4" 17" 5- 1/2" 48- 7/16" 15- 5/8" 12" 46" CLASSIC 50 [1262mm [430mm] [140mm] [1230mm] [397mm] [306mm] [1168mm] 12" 15- 5/8" 5- 1/2" 58- 7/16" 56" 59-3/4" 17" CLASSIC 60 [306mm] [397mm] [430mm] [140mm] [1484mm] [1422mm] [1516mm] 12"...
- Page 6 RECESSED TO WALL INSTALLATION STEP A. Selection a dry wall to open a hole for fireplace box. Size of hole as below chart Figure ( A ) FRAMING HOLE SIZE Model Number CLASSIC 50 48- 3/4" [1238mm] 15- 3/4" [400mm] CLASSIC 60 58- 3/4"...
- Page 7 ( C ) STEP C. Take off the screw in both sides of the glass panel. Figure ( C ) STEP D. Have two person to take the glass panel out of the fireplace box. Place it to a soft and clean place.
-
Page 8: Wall Mounted Installation
Wall Mounted Installation Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. A.Select a location that is not prone to moisture and is located at least 36" (914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc. - Page 9 Drift Logs / Crystals / Pebbles Installation (NOTE: Please make the installation according to the embers which you bought or selected.) Glass front must be removed and the appliance must be mounted in its final location before the drift logs embers are installed. Carefully place the small crystal embers or pebbles into the bottom tray on the front of the appliance as illustrated.
-
Page 10: Operation
Operation Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Plug the power cord into a AC 110-120 Volt outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3). - Page 11 Flame speed button:Controls the speed 1. Press once. Flame speed gets changing. of the flame.There are 3 flame speed 2. Press again until desired setting is settings: 01 (slowest), 02 (Medium), 03 reached. Display shows the setting. (fastest). SPEED The Default setting is 02 (medium speed) Flame color button: Makes the color 1.
- Page 12 BUTTON FUNCTION ACTION & INDICATION ON: Enables control panel functions and 1. Press once. Indicator light turns on. remote control. Turns on flame effect. Power turns on. All functions enabled. OFF: Disables control panel functions and 2. Press again. Flame effect turns off. Unit remote control.
- Page 13 FLAME button: Makes flame 1. Press once. Flame brightness effect dimmer and brighter. effect gets changing. NOTE: Flame effect stays on until 2. Press again. until desired setting power button is turned off. Flame effect is reached. must be on for heater to turn on. FLAME BRIGHTNESS LED Ember light button: Makes the...
-
Page 14: Care And Maintenance
Remote Control Battery Information • Remote control uses CR2025 batteries (Included) NOTE: Remote control battery used depends on the remote control type which selected above. NEVER dispose of batteries in fire. Failure to observe this precaution may result in an explosion. - Page 15 Storage: • Store heater in a clean dry place when not in use. WARNING! NO SERVICING of the internal or electrical parts should be performed by the consumer. Do not service the unit yourself. WEEE： Meaning of crossed –out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
- Page 16 info@sunteck.ca...
