SPECIAL T ZIA Hospitality Assembly Instructions

TOOLS
#3 Phillips
Screwdriver
Impact Drill #3 Phillips Bit
5mm Hex Key
PARTS & HARDWARE
A
Tabletop
(1)
B C
Mounting Steel Column
Plate w/mounting pins
(1) (1)
D
Aluminum
Feet
(4)
F E
M6 Phillips ZIA
Flat Head Bolts Glides
(4) (4)
G H
M8 Phillips Flat Wood
Head Bolts Screws
(1) (8)
FOR MISSING PARTS OR
QUESTIONS, PLEASE CALL
CUSTOMER SERVICE
AT 888-705-0777.
888.705.0777
Round, Square, or Soft Square Fixed Top Table
ASSEMBLY STEPS
C
F
C
B
H
A
B
4. Attach mounting plate (B) onto the
bottom of the table top (A) using (8)
Phillips wood screws (H).
5. Ensure that all mounting pins are
secure on the column. If necessary,
use a 14mm wrench to tighten.
E
D
8. Attach (4) glides (E) to (4)
aluminum feet (D).
9. Ensure all feet are fully attached
to the column and carefully flip the
table upright.
1. Lay the tabletop
(A) upside down on
a piece of cardboard
or a carpeted
surface.
2. Install (4) M6
flat head bolts
(F) through steel
column (C) into
mounting plate (B).
6. Place (4) aluminum feet (D) onto pins.
7. Tighten (4) aluminum (D) feet onto pins
using the 5mm Hex Key.
(Mounting hardware comes pre-installed in
foot.)
ZIA HOSPITALITY | SOFT-SQUARE TOP
1
ZIA Hospitality
A S S E M B LY I N S T R U C T I O N S
B
G
C
3. Install (1) M8 flat head bolt (G)
through mounting plate (B) into
steel column (C).
D
www.specialt.net
