Impact Drill
A
Column Assembly
(1)
A
B
C
888.705.0777
#3 Phillips Bit
PARTS & HARDWARE LIST
B
Aluminum Feet
(4)
D
Lectern Top
(1)
MOUNTING
PIN
TOOLS
#2 Phillips Screwdriver
C
Glides
(4)
E
PET Support Brackets
(2)
F
PET Brace
(2)
1.
Ensure that all mounting pins are secure
on the Column Assembly (A). If necessary,
use a 14mm wrench to tighten them.
2.
Place (4) Aluminum Feet
3.
Tighten (4) Aluminum Feet
using the 5mm Hex Key.
4.
Attach (4) Glides
(B).
Feet
FOR MISSING PARTS OR QUESTIONS,
PLEASE CALL CUSTOMER SERVICE AT 888-705-0777.
1
A S S E M B LY I N S T R U C T I O N S
5mm Hex Key
G
PET Shroud
(1)
ASSEMBLY STEPS
(B)
onto pins.
(B)
(C)
to (4) Aluminum
ZIA
Lectern
14mm Wrench
H
Flat Head
Wood Screws
(4)
I
Phillips Pan Head
PET Screws
(16)
J
M6 Nylon Lock Nut
(4)
onto pins
www.specialt.net
