Summary of Contents for SPECIAL T patriot
- Page 1 PECIAL Patriot Height Adjustable Table User Guide...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS Parts Diagram Parts Diagram Full Length Independent Independent Three-Leg Independent with HAT Channel Three-Leg Safety Information Safety Information Assembly Instructions 8-11 Assembly Instructions 10-13 Operations 12-13 Initialization and Reset Operation 14-15 Handswitch Operation Initialization and Reset Programmable Handswitch Operation Handswitch Operation -Adjust Height Display... -
Page 3: Parts Diagram Parts Diagram
PARTS DIAGRAM User Guide: OV1000 PARTS DIAGRAM User Guide: OV1000 PECIAL PARTS DIAGRAM Patriot Height Adjustable Table PARTS DIAGRAM INDEPENDENT User Guide: OV1000 Parts Diagram Parts Diagram For tables 60" or Less PARTS DIAGRAM PARTS DIAGRAM User Guide: OV1000 ITEM... -
Page 4: Three-Leg
PARTS DIAGRAM User Guide: OV1000 PECIAL Patriot Height Adjustable Table Parts Diagram Parts Diagram THREE-LEG PARTS Qty/Package 1. Independent Beam 2. Column 3. Top Support 4. Foot 5. M8x1.25 12mm Screw 6. M10x1.5 50mm Screw Handswitch 8. Control Box 9. Power Cord... -
Page 5: Safety Information
SAFETY INFORMATION User Guide: OV1000 PECIAL Patriot Height Adjustable Table Safety Information SAFETY INFORMATION To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product. Do not change or Special-T. - Page 6 SAFETY INFORMATION User Guide: OV1000 PECIAL Patriot Height Adjustable Table Safety Information Safety Information DO NOT OVERLOAD DESK To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability and lead to tip over.
- Page 7 ASSEMBLY INSTRUCTIONS User Guide: OV1000 ASSEMBLY INSTRUCTIONS User Guide: OV1000 PECIAL Patriot Height Adjustable Table ASSEMBLY Assembly Instructions ASSEMBLY INSTRUCTIONS INSTRUCTIONS The assembly of the table frame to be made in accordance with this manual. The assembly of the table frame to be made in accordance with this manual.
- Page 8 ASSEMBLY INSTRUCTIONS User Guide: OV1000 PECIAL Patriot Height Adjustable Table Assembly Instructions ASSEMBLY INSTRUCTIONS User Guide: OV1000 ASSEMBLY INSTRUCTIONS User Guide: OV1000 Column Male Hex ASSEMBLY INSTRUCTIONS User Guide: OV1000 Motor Female Hex Column Male Hex Motor ASSEMBLE THE COLUMN TO THE BEAM...
-
Page 9: Full Length
User Guide: OV1000 User Guide: OV1 PECIAL ASSEMBLE THE TOP SUPPORT TO THE BEAM Patriot Height Adjustable Table AND COLUMN Assembly Instructions Assemble using the M8x1.25 x 12mm length screws (4 per column). The maximum tightening torque for these screws i 24Nm (18 lbs-ft). - Page 10 ASSEMBLY INSTRUCTIONS User Guide: OV1000 ASSEMBLY INSTRUCTIONS PECIAL Patriot Height Adjustable Table Assembly Instructions ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS User Guide: OV1000 User Guide: OV1000 FASTEN THE CONTROL BOX AND HANDSWITCH FASTEN THE TABLE FRAME ONTO THE TABLE TOP TO THE TABLE TOP Be sure to use approved screws per the table top supplier.
-
Page 11: Programmable Handswitch Operation
OPERATION INFORMATION User Guide: OV1000 PECIAL Patriot Height Adjustable Table Operation Information OPERATION INFORMATION INITIALIZATION/RESET The desk may need to be initialized/reset after any of the following: - After assembly - After disconnection from the power supply - After any impact on the table top. -
Page 12: Programmable Handswitch Operation
PECIAL Patriot Height Adjustable Table Operation Information PROGRAMMABLE HANDSWITCH OPERATION (continued) CHANGE THE HEIGHT UNIT (inches or centimeters) The height display of the handset can display either centimeters or inches. With the help of the S5-menus, the unit can be changed. If the display was originally set to centimeters, then after the procedure noted below it will change to inches or vice versa. -
Page 13: Troubleshooting
TROUBLESHOOTING User Guide: OV1000 PECIAL Patriot Height Adjustable Table Troubleshooting TROUBLESHOOTING UNIT ERROR CODE SOURCE SOLUTION No power supply Plug in the power cord or check the connection Table does not on the control box move No connection or a loose... - Page 14 TROUBLESHOOTING User Guide: OV1000 PECIAL Patriot Height Adjustable Table Troubleshooting Troubleshooting HANDSWITCH DISPLAY ERROR CODE SOURCE SOLUTION The control box monitors the duty cycle (time-controlled) and its max Wait until the “HOT” display goes out - the table is working properly again temperature.
-
Page 15: Technical Data
TECHNICAL DATA User Guide: OV1000 PECIAL Patriot Height Adjustable Table Technical Data TECHNICAL DATA GENERAL Power supply 120 VAC ±10% / 60 Hz Standby power consumption, primarily <0.3 W Operating temperature 0-35°C Protection class IP 20 Maximum duty cycle 10% (2 min. on / 18 min. off) -
Page 16: Standards & Certifications
The drive system is tested according to the following standards: CUSTOMER SERVICE CONTACT YOUR SALES REPRESENTATIVE FOR WARRANTY INFORMATION Patriot Electric table bases are warranted to the original purchaser for a period of 10 years from the date of CUSTOMER SERVICE UL 962 delivery. - Page 17 PECIAL TABLES & BASES 888.705.0777 www.specialt.net...
