React Health Luna G3 BPAP 25A Quick Setup Manual

Luna
1. Button Functions
Home Button: Return to the previous menu or main interface
Knob: Adjust device settings
Start / Stop Button: Start / Stop delivering air
2. Setting up the Device
A. Connect one end of the tube to the assembled mask.
B. Connect one end of the tube to the air outlet of the device, as shown in the figure above. Or
Connect the heated tubing joint to the air outlet of the device, and then insert the power plug of
the heated tubing into the heated tubing port on the back of the device.
Note: To apply the tubing elbow adapter, connect the tubing elbow adapter between the device
air outlet and the tubing (heated or standard tubing) as shown in the figure above. The 90
degree elbow helps to direct the tubing.
C. Connect the power adapter to the DC inlet of the main device.
D. Connect the power cord to the power adapter.
E. Plug the power cord into the power outlet.
F. If the disposable ultra-fine filter is used, place the reusable air filter first, the reusable air filter
should be closest to the filter cap and the disposable ultra-fine filter should be closest to the
device. Install the filter cap containing the reusable air filter / disposable ultra-fine filter to the
device.
Note:
The reusable air filter should be replaced at least every 6 months and the disposable ultra-fine
filter should be replaced at least every 2 weeks. Replace the filters more often if there are any
holes or blockages by dirt or dust.
The disposable ultra-fine filter is not washable or reusable.
Luna ® G3 BPAP 25A (LG3700) Patient Quick Set-Up Guide
G3 BPAP 25A (LG3700)
®
Patient Quick Set-Up Guide
1 / 4
