Required materials:
Nutkey nr. 8
Screwdriver (phillips head / PH2)
Materials supplied:
M5*40 stainless steel pan head screw (h-cross) (4 x)
Flat washer stainless steel (8 x)
M5 hexagon nut stainless steel (4 x)
Flat washer nylon (4 x)
Washer nylon with insert (4 x)
Cover cap nylon (8 x)
Version 2.0 – 02.2023
Installation guide replacement pane
Toyota Troop Carrier LHS
1
Advertisement
Related Manuals for Explore TAIL-MOL-PANE-TOY-70
Summary of Contents for Explore TAIL-MOL-PANE-TOY-70
- Page 1 Installation guide replacement pane Toyota Troop Carrier LHS Required materials: Nutkey nr. 8 Screwdriver (phillips head / PH2) Materials supplied: M5*40 stainless steel pan head screw (h-cross) (4 x) Flat washer stainless steel (8 x) M5 hexagon nut stainless steel (4 x) ...
- Page 2 We strongly recommend that you read the manual in advance. It is important that the Explore Glazing products are assembled correctly and safely. Careless assembly can lead to accidents and serious damage and / or injury to you or others. If you have no technical experience or are not familiar with the general assembly instructions, we recommend that you have our products assembled by a professional company.
