Kamar L1845 User Manual

User manual
L1845
Tail lamp LED 25 right 12/24V
Technical data
• Product dimensions: 106x99mm
• Cable: 150mm, 4x0,5mm2
• Working voltage: 12/24V
• Approvals, certificates:
ECE R4, R6, R7, R10
• LED quantity: 25pcs
• Material of execution:
Housing: ABS
Lens: PMMA
• Working temperature: from -30°C to + 60°C
Functions
• Rear lamp LED
• For automo ve use only
• The lamp has road approval ECE R4, R6, R7, R10 authorizing it to be used on public roads
• The lamp is intended for vehicles with 12/24V installation
• Reverse polarity protection
Mounting method
• Installation only in specialized workshops or professional service
• Lamps must be installed only in accordance with the UNECE regulations
Wire connection
FUNCTION
Ground
Position
Indicator
The connection between the lamp and vehicle's installation should be isolated with heat-shrink
tube, to avoid getting water and moisture to the copper wire of the lamp, which can damage
electronic components and flood the lamp with water.
Warnings
• Use as intended
• Use in airly places
• Do not touch the lamp during operation and immediately after it is turned off, the lamp may get warm
Any unauthorized interference with the lamp (associated with its depressurization, interference with the electronic system, etc.) is associated with the loss of
•
warranty
• The device must be installed and keeped out of reach of children
• Do not cut off tinned ends.
We reserve the right to change technical data and possible errors. Photos/drawing and
technical data are only illustrative, and given product may slightly differ from them. Coping
the part or the entire package without the written authorization is forbidden. All rights
reserved.
WIRES COLOR
White
Black
Yellow
Red
STOP
Important! Do not look directly in the light. It can cause the the eye damage
Importer: KAMAR Knapkiewicz S.K.A.
Terms of warranty:
- we provide a guarantee for a period of 24 months from the date of sale,
- any unauthorized interference with the item entails the loss of the guarantee.
al. Armii Krajowej 254
85-689 Bydgoszcz, Poland
Country of origin: PRC
www.myKAMAR.com
