INSTALLATION AND USER MANUAL
To avoid any risk of fire, these dev ices m ust be installed in accordance w ith the rules of the art
(D.T.U. 2 4.2.2 .) and in accordance w ith the technical rules recalled in the instructions that m ust
be attached to the devices. Their installations m ust be carried out by a professional or a
qualified person.
"All local and national regulations, as w ell as European standards in
m ust be respected during the installation and use of the appliance".
1
N-BE-0443-03-791-3V
Advertisement
Related Manuals for Cheminees Philippe 791-3V
Summary of Contents for Cheminees Philippe 791-3V
- Page 1 Insert Bois 791-3v INSTALLATION AND USER MANUAL To avoid any risk of fire, these dev ices m ust be installed in accordance w ith the rules of the art (D.T.U. 2 4.2.2 .) and in accordance w ith the technical rules recalled in the instructions that m ust be attached to the devices.
- Page 2 You have just acquired a wood-burning fireplace . We congratulate you for trusting our brand. It is important to follow the advice in this leaflet. This manual should be kept for the duration of use. N-BE-0443-03-791-3V...
- Page 3 Operation ............... 4.5. Air Intake Adjustment ..............4.6. Charging – Pow er ............Intended for 4.7. Reloading precautions ............. 4.8. The user W arning................4.9. 4.11. Advice in case of abnormal operation ......MAINTENANCE ..............SPARE PARTS ..............GUARANTEE ................ N-BE-0443-03-791-3V...
-
Page 4: Device Environment
1.1. Characteristics: For walls made of non-combustible material, special insulation must be Insert 791-3V: applied to the entire interior width of the chimney and the entire height. See table 2nd case, and sketch n°2. - Page 5 D.T.U. 24.2.P1 also specifies that the inside of the hood must be visible in order to allow the connection duct to be checked. The access hatch allows this visibility (nevertheless possible by the diffusers), but in addition, leaves the possibility of intervening, for example, when the chimney is working. N-BE-0443-03-791-3V...
- Page 6 Do not burn household waste, plastics (bottles) or derivatives, rubber, greasy products (cloths soaked in oil) etc. which pollute the environment and cause the risk of chimney fire by clogging the flue. N-BE-0443-03-791-3V...
- Page 7 For special cases, please contact us. (vacuum, tightness flue, connection and insert). CHEMINEES PHILIPPE – Little heating but the fire that - Check the seal of the insert. gets carried away. - Load preferably with large logs.
- Page 8 791-3V Footprint: Closed Door (/)273 r--... ""I' ; £ Filter Centre oids Ma" nfroid fem,efure orte N-BE-0443-03-791-3V...
- Page 9 791-3V Footprint: Door Open N-BE-0443-03-791-3V...
- Page 10 When the air damper is opened, we have the starting air (under the fire grates) coming into the combustion chamber. And when the air damper is closed, only the secondary air arrives in the combustion chamber. (Decoration plate and window sweeping) N-BE-0443-03-791-3V...
-
Page 11: Door Opening
Top position: Flap closed Lower position: Flap open When opening the door, open the flapper Disassembling the valve 3: Swivel flapper to the right 1: Open the flapper (Figure 3b) 2: Raise the flapper 4: Lower flapper into the insert N-BE-0443-03-791-3V... - Page 12 2: Check the direction of the anti-bistre fitting outlet 3: Setting up the filter 4: Pay attention to the direction of the rake Air channel installation 1: Insert the air channel into the 2: Insert Air Channel Supplement insert N-BE-0443-03-791-3V...
- Page 13 Setting up the ash tray FIG. N°3c: 2 : Place ashtray on the bottom of the insert. 1: Insert ashtray. Setting up foyère sole FIG. N°3d : 1 : Insert foyere grids 2 : Place the hay grids on the base N-BE-0443-03-791-3V...
- Page 14 1: Insert the decoration plate into the heating element 2: Place the decoration plate on the stops of the base plate Installing the inner sides: 2: Screw the left side 1: Insert on the inside insert 3: Screw the right side N-BE-0443-03-791-3V...
- Page 15 Setting up the deflector: FIG. N°3f: 1: Insert the baffle into the device 2: Mount the baffle inside the drain 3: Place the deflector on the set plate and tilt the deflector forward N-BE-0443-03-791-3V...
- Page 16 Disassembly of the filter rake for chimney sweeping 1: Remove the deflector 2: Remove the flapper (see fig 3b P11) 4: Rotate the Rake 3: Raised the rake slightly using the handle 5: Remove the rake through the heating element 6: Chimney Sweep Ready N-BE-0443-03-791-3V...
- Page 17 Side gaskets: ø9.5mm ref 06 2 09 2 B Facade glass gasket: 7x3 adhesive flat ref 06307 Fixed door seal: ø10mm ref FD3276D 8 18 Side side glass seal: 8x1 adhesive flat ref 06308 Steel deflector gasket: ø9.5mm ref 06 2 09 2 B N-BE-0443-03-791-3V...
- Page 18 Fixed door seal: ø9.5mm ref 06 2 09 2 B Hood design and ceiling insulation FIG. N°4 : N-BE-0443-03-791-3V...
- Page 19 ECLATEE 791-3V Designation Code Designation Code 18T Sprocket S10837 Fixed frame underneath joint l_l FD3276D818 Left Upright S11448 Fixed frame side joint l_l 062092B Amount 019866 Joint ossature mobile l_l 062112B Output ø230mm 705.3268 Sheet metal deflector gasket l l...
- Page 20 ("Stirring"). As a result, they may present changes in appearance over time which are completely normal and can in no way give rise to a claim of any kind whatsoever. Similarly, for all the products in our catalogue, we cannot guarantee N-BE-0443-03-791-3V...
- Page 21 Verification of registers Checking the instructions Serial and warranty number: Checking Decal Warning Verification of the nameplate Cold-hand verification CHEMINEES PHILIPPE - Z.I. A - Avenue du Président Kennedy - 62401 BETHUNE CEDEX Date: 10/2022 N-BE-0443-03-791-3V...
