1. General Information 1.1 Overview Thanks for choosing Jinko Solar PV modules. In order to ensure the PV modules are installed correctly, please read the following installation instructions carefully before modules are installed and used. Please remember that these products generate electricity and certain safety measures need to be taken to avoid danger.
Page 4
Do not use this module to replace or partly replace roofs and walls of living buildings. Do not install modules where flammable gas may be present. Do not remove any part installed by Jinko Solar or disassemble the module. All instructions should be read and understood before attempting to install, wire, operate and maintain the module.
Page 5
During all transportation situations, never drop the module from a vehicle, house or hands. This will damage module. Modules (glass, junction boxes, connectors, etc.) shall be protected from long-term exposure to environments containing sulfur, strong acid, strong alkaline, etc., which may pose a risk of corrosion to the product.
2. Installation 2.1 Installation Safety Always wear protective head gear, insulating gloves and safety shoes (with rubber soles) and other protective measures during installation. When installing or maintaining the photovoltaic system, please do not wear metal rings, watches and other metal products, so as not to cause electric shock danger and damage the modules. Keep the PV module packed in the carton until installation.
When installing modules on roof mounted structures, please try to follow the “from top to bottom” and/or “from left to right” principle, and don’t step on the module. This will damage the module and would be dangerous for personal safety. Modules will have thermal expansion and cold contraction effect.
from range, ensure the safety of personnel During loading and unloading, special command is required to avoid failure and making modules down; When using a forklift to move palletized packing boxes to the operation area, the forklift shall be slowly and steadily lifted and put down gently during loading and unloading, and the modules shall avoid turbulence and violent vibration during transportation.
prevent the goods from colliding with the top of the container, and ensure that the whole pallet module is safely removed from the container (Figure 6); If the modules need to be temporarily stored after unloading, it is recommended to keep sufficient space between each pallet to avoid scratching the carton or pallet during the second transfer.
Height of the container above the ground When the container is unloaded When using the fuel forklift, adjust the height of the forks from the ground, the forks into the short side of the pallet, after the forks into the bottom, lift the modules at an appropriate height (the tilt Angle required to lift the modules <2°), the smaller the distance from the ground when the forklift out of the container door, ensure that the height of the forks from the ground and the distance from the goods to the top of the container is not more than 80mm;...
Page 11
Figure 7 Figure 8 In order to minimize the impact of sling on the safety of goods in the process of hoisting, the modules without frame should be supported during loading and unloading. For example, wooden sticks, boards or other fixtures of the same width as the outer packing cases should be used on the upper part of the box to reduce the pressure of the contact position...
stacked modules with single support after dismounting in order to ensure the safe storage of the modules on site Only after cutting the outer packing belt of the connecting two brackets, separate the upper and lower brackets The double glass modules should be stored with single support after dismounting The modules should be stored in a complete outer package, and the storage area should be protected and pallets and packing cases from damp, direct sunlight and...
Page 14
modules and the shelf wall (Figure 14)); If the modules need to be spot tested, please refer to the unpacking instructions of this manual 3.3/3.4 to unbox the modules; During the unpacking process, supports are provided on one side of the assembly to prevent it from toppling over (Figure 15);...
2.2.2 Site Selection In most applications, Jinko solar PV modules should be installed in a location where they will receive maximum sunlight throughout the year. In the Northern Hemisphere, the module should typically face south, and in the Southern Hemisphere, the modules should typically face north.
Solar PV modules usually can be mounted by using the following methods: bolts and clamps. Note: 1) All installation methods herein are only for reference, and Jinko solar will not provide related mounting components, the system installer or trained professional personnel must be responsible for the PV system’s design, installation, and mechanical load calculation and security of the system.
The frame of each module has 8 mounting holes (Length* Width: 14mm*9mm) used to secure the modules to support structure. Always use all the eight mounting holes to secure the modules. The module frame must be attached to a mounting rail using M8 corrosion-proof bolts together with spring washers and flat washers in eight symmetrical locations on the PV module.
Page 18
Height of the frame mm Group 1 1650*992 & 1665*1002 Group 2 1665*992 & 1684*1002 Group 3 1650*992 & 1665*1002 Group 4 1665*992 & 1684*1002 Group 5 1650*992 & 1665*1002 Group 6 1665*992 & 1684*1002 Group 7 1650*992 & 1665*1002 Group 8 1665*992 &...
Page 19
Group 55 2008*1002 Height of the frame mm 2096*1039 & 2090*1039 & Group 63 2090*1038 Group 85 2061*1023 Height of the frame mm Group 24 1796*995 & 1796*998 Group 26 1822*1008 Group 28 1822*1008 Group 32 1840*998 & 1841*1002 Group 34 1868*1008 &...
2.3.1.2 Mounting with Bolts four mounting holes Figure 3: PV module installed with bolt fitting method four mounting holes Max. Design Pressure: 3600Pa (positive ) &1600Pa (negative) mechanical load Module type Module dimensions(mm) Height of the frame mm Group 1 1650*992 &...
Page 21
Group 19 2031*1008 Group 21 2008*1002 Group 29 2031*1008 Group 45 2008*1002 Group 55 2008*1002 2274*1134 & Group 71 & 80 2335 1134 2278*1134& Group 72 & 81 2230*1134 Height of the frame mm Group 24 1796*995 & 1796*998 Group 26 1822*1008 Group 28 1822*1008...
2393*1130 & 2385*1122 & Group 73 & 82 2408*1132 & 2411*1134 Group 87 2465*1134 & 2525*1134 Table 2: Mechanical dimensions for bolt fitting method four mounting holes Note The installation method of bolt fitting four mounting holes is based on the internal results in Jinko. The load described in this manual is the design load.
The design of the NexTracker tracking bracket, the selection of accessories and the installation of modules should be completed by a professional system installer, which can refer to Jinko's mechanical load. The load described in this manual is the design load. When calculating the maximum test load, 1.5 times of safety factor should be considered.
Page 24
Middle modules installation Fringe modules installation Figure 5: PV module installed at the side with Clamp fitting method Composition Clamp type Dimension(mm) material End Clamp 39 x 50 x 42 (40 mm thickness) 39 x 60 x 42(For 1.5mm thickness frame) End Clamp 41.5 x 50 x 40 (35 mm thickness)
types and installation locations are shown in figure 8 and table 7. When installing modules using clamps on the long side of the frame, the applicable product types and installation locations (The without C transparent backsheet series module) are shown in figure 9 and table 8.
Page 26
Group 22 1684*1002 Group 30 1704*1008 Group 46 1684*1002 Group 57 1693*1029 Group 58 1693*1029 Group 59 1716*1032 Group 60 1716*1032 Group 56 1684*1002 1756*1039 & 1750*1039 & Group 64 1750*1038 Group 61 1693*1029 & 1692*1029 Group 62 1693*1029 & 1692*1029 1884*1122 &...
Page 27
1842*1021 & 1842*1024 & Group 40 1855*1029 & 1855*1032 Group 42 1868*1034 & 1878*1032 Group 44 1868*1034 & 1878*1032 1842*1021 & 1842*1024 & Group 48 1855*1029 & 1855*1032 1842*1021 & 1842*1024 Group 50 & 1855*1029 & 1855*1032 1842*1021 & 1842*1024 Group 52 &...
2.3.2.2 Clamp Mounting on Short Sides of the Frames Figure 7: Installation of clamps on short side of frames 1067Pa (positive ) 1067Pa (positive ) Max. Design Pressure: &1067Pa (negative) &1067Pa (negative) mechanical load mechanical load Module type Module dimensions(mm) Height of the frame mm Group 65 &...
Page 29
Group 11 1987*992 & 2008*1002 Group 12 1956*992 & 1979*1002 Group 13 1987*992 & 2008*1002 Group 14 1956*992 & 1979*1002 Group 15 1987*992 & 2008*1002 Group 16 1956*992 & 1979*1002 Group 17 1987*992 & 2008*1002 1987*992 & 2008*1002 & Group 18 2031*1008 Group 19 2031*1008...
2.3.2.3 Clamp Mounting on Long & Short Sides Figure 8: Installation methods of clamps on long and short sides Max. Design 1600Pa (positive ) &1600Pa 1600Pa (positive ) &1600Pa (negative) Pressure: (negative) mechanical load mechanical load Module type Module dimensions(mm) Height of the frame mm L/4±50mm Group 65...
Page 31
1672*992 & 1704*1008 Group 20 1704*1008 Group 22 1684*1002 Group 30 1704*1008 Group 46 1684*1002 Group 64 1756*1039 Group 67 & 1903*1134 Group 76 Height of the frame mm 1956*992 & Group 10 1979*1002 1987*992 & Group 11 2008*1002 1956*992 & Group 12 1979*1002 1987*992 &...
Page 32
1868*1034 & Group 42 1878*1032 1868*1034 & Group 44 1878*1032 1842*1021 & 1842*1024 & Group 48 1855*1029 & 1855*1032 Height of the frame mm 2113*995 & Group 23 2113*998 2130*1002 & Group 25 2139*1008 2130*1002 & Group 27 2139*1008 2163*995 & 2167*997 Group 31 2167*998 &...
2.3.2.4 Clamp Mounting on Long Sides of the Frames (The without C transparent backsheet series module) Figure 9: Installation methods of clamps on long sides 3600Pa (positive ) Max. Design Pressure: &1600Pa (negative) Module type mechanical load Module dimensions(mm) Height of the frame mm Group 19 2031*1008 Group 29...
3. Electrical 3.1 Electrical Safety If the PV modules are connected in series, the total voltage is equal to the sum of the individual module voltages. If PV modules are connected in parallel, the total current is equal to the sum of the individual module currents.
Page 35
e) All module frames and mounting racks must be properly grounded in accordance with local and national electrical codes. Attach the equipment grounding conductor to the module frame using the hole and hardware provided. Note that a stainless-steel star washer is used between the groundingwire and module frame (see Figure 10.2 below).
Page 36
Temperature coefficient of open circuit voltage (refer to product label or data sheet) Tmin Minimum ambient temperature j) For floating projects, please contact local technical support. k) Connectors and bybass diodes from different manufacturers should not be mated together. If such replacement is needed, please contact Jinko Solar.
4. Maintenance and Care It is required to perform regular inspection and maintenance of the modules, especially during the warranty period. To ensure optimum module performance, Jinko recommends the following maintenance measures: 4.1 Visual Inspection Inspect the modules visually to find if there are any visual defects, If there are, the following items should be evaluated: a) If modules are observed having slight cell color differences at different angles, this is a normal phenomenon of modules with anti-reflection coating technology.
module backside regularly when necessary, and follow the requirements in 4.2 a) – e). Please wear insulated gloves and pay special attention to the cables and electrical connections during the backside cleaning. 4.3 Inspection of Connector and Cable It’s recommended to implement the following preventive maintenance every 6 months: a) Check the sealing gels of the junction box for any damage.
Page 39
JKMxxxPP-60-V JKMxxxPP-60(Plus) -V JKMSxxxPP-60-V JKMSxxxPP-60-V-J JKMxxxPP-60B (xxx=260~290,in increment of 5) Group 2 JKMxxxPP-60H JKMxxxPP-60H-V JKMxxxPP-60HB (xxx =260~315,in increment of 5) Group 3 JKMSxxxPP-60-V-MX3 JKMSxxxPP-60B-V-MX3 JKMSxxxPP-60-MX3 JKMSxxxPP-60B -MX3 JKMSxxxPP-60L-V-MX3 JKMSxxxPP-60BL-V-MX3 JKMSxxxPP-60L -MX3 JKMSxxxPP-60BL -MX3 (xxx =260~290,in increment of 5) Group 4 JKMSxxxPP-60H-V-MX3 JKMSxxxPP-60HB-V-MX3 JKMSxxxPP-60H-MX3...
Page 40
JKMxxxN-60H-TV JKMxxxN-60HL-TV JKMxxxN-60H-T JKMxxxN-60HL-T (xxx =315~355,in increment of 5) Group 10 JKMxxxPP-72 JKMxxxPP-72(Plus) JKMSxxxPP-72 JKMSxxxPP-72-J JKMxxxPP-72-V JKMxxxPP-72(Plus)-V JKMSxxxPP-72-V JKMSxxxPP-72-V-J JKMxxxPP-72B (xxx =320~355,in increment of 5) Group 11 JKMxxxPP-72H JKMxxxPP-72H-V JKMxxxPP-72HB (xxx =330~380,in increment of 5) Group 12 JKMSxxxPP-72-V-MX3 JKMSxxxPP-72B-V-MX3 JKMSxxxPP-72-MX3 JKMSxxxPP-72B-MX3 JKMSxxxPP-72L-V-MX3 JKMSxxxPP-72BL-V-MX3...
Page 41
Group 18 JKMxxxM-72H-TV JKMxxxM-72HL-TV JKMxxxM-72H-T JKMxxxM-72HL-T (xxx =375~425,in increment of 5) JKMxxxN-72H-TV JKMxxxN-72HL-TV JKMxxxN-72H-T JKMxxxN-72HL-T (xxx =375~425,in increment of 5) Group 19 JKMxxxN-72H-MBB-TV JKMxxxN-72H-MBB-T (xxx =390~420,in increment of 5) Group 20 JKMxxxN-60H-MBB-TV JKMxxxN-60H-MBB-T (xxx =330~350,in increment of 5) Group 21 JKMxxxM-72H-MBB JKMxxxM-72H-MBB-V JKMSxxxM-72H-MBB-TI...
Page 42
Group 31 JKMxxxM-78H-V JKMxxxM-78H JKMSxxxM-78H-V-TI JKMSxxxM-78H-TI (xxx =405-465,in increment of 5) Group 32 JKMxxxM-66H-V JKMxxxM-66H JKMSxxxM-66H-V-TI JKMSxxxM-66H-TI (xxx =340-390,in increment of 5) Group 33 JKMxxxM-78H-TV JKMxxxM-78H-T (xxx =405-455,in increment of 5) Group 34 JKMxxxM-66H-TV JKMxxxM-66H-T (xxx =340-385,in increment of 5) Group 35 JKMxxxN-78H-T JKMxxxN-78H-TV...
Page 43
Group 44 JKMxxxN-6RL3-T JKMxxxN-6RL3-TV-J JKMxxxN-6RL3-T-J JKMxxxN-6RL3-TV (xxx = 355~400,in increment of 5) Group 45 JKMxxxN-72H-MBB-V JKMSxxxN-72H-MBB-TI JKMSxxxN-72H-MBB-V-TI JKMxxxN-72H-MBB (xxx = 385~425,in increment of 5) Group 46 JKMxxxN-60H-MBB-V JKMSxxxN-60H-MBB-TI JKMSxxxN-60H-MBB-V-TI JKMxxxN-60H-MBB (xxx = 320~350,in increment of 5) Group 47 JKMxxxN-7RL3 JKMxxxN-7RL3-V-J JKMxxxN-7RL3-J JKMxxxN-7RL3-V JKMSxxxN-7RL3-V-TI...
Page 44
(xxx = 380-400,in increment of 5) Group 56 JKMxxxN-60H-MBB-B JKMxxxN-60H-MBB-B-V JKMxxxN-60H-MBB-B-TI JKMxxxN-60H-MBB-B-V-TI (xxx = 315-330,in increment of 5) Group 57 JKMxxxM-6TL3-V JKMxxxM-6TL3 JKMSxxxM-6TL3-V-TI JKMSxxxM-6TL3-TI (xxx = 335-380,in increment of 5) Group 58 JKMxxxN-6TL3-V JKMxxxN-6TL3 JKMSxxxN-6TL3-V-TI JKMSxxxN-6TL3-TI (xxx = 335-375,in increment of 5) Group 59 JKMxxxM-6TL3-TV (xxx = 325-365,in increment of 5)
Page 45
JKMxxxM-54HL4-B-V JKMxxxM-54HL4-B (xxx = 380-400,in increment of 5) JKMxxxM-54HL4-TV (xxx = 360-410,in increment of 5) Group 66 JKMxxxM-5RL4-V JKMxxxM-5RL4 (xxx = 375-405,in increment of 5) JKMxxxM-5RL4-B-V JKMxxxM-5RL4-B (xxx = 375-395,in increment of 5) JKMxxxM-5RL4-TV (xxx = 365-405,in increment of 5) Group 67 JKMxxxM-60HL4-V JKMxxxM-60HL4...
Page 46
Group 71 JKMxxxM-72HL4-V JKMxxxM-72HL4 JKMxxxM-72HL4-V-J JKMxxxM-72HL4-J (xxx = 475-585,in increment of 5) JKMxxxM-72HL4-B-V JKMxxxM-72HL4-B (xxx = 510-535,in increment of 5) JKMxxxM-72HL4-TV JKMxxxM-72HL4-TV-J (xxx = 475-580,in increment of 5) Group 72 JKMxxxM-7TL4-V-J JKMxxxM-7TL4-J JKMxxxM-7TL4-V JKMxxxM-7TL4 (xxx = 495-570,in increment of 5) JKMxxxM-7TL4-B-V JKMxxxM-7TL4-B (xxx = 495-530,in increment of 5)
Page 47
(xxx = 405-510, in increment of 5) JKMxxxN-60HL4-B-V JKMxxxN-60HL4-B (xxx = 425-470, in increment of 5) JKMxxxN-60HL4-TV (xxx = 400-480,in increment of 5) Group 77 JKMxxxN-6TL4-V JKMxxxN-6TL4 (xxx = 415-450,in increment of 5) JKMxxxN-6TL4-B-V JKMxxxN-6TL4-B (xxx = 415-440,in increment of 5) JKMxxxN-6TL4-TV (xxx = 405-450,in increment of 5) Group 78...
Page 48
JKMxxxN-7TL4-TV JKMxxxN-7TL4-TV-J (xxx = 480-570,in increment of 5) Group 82 JKMxxxN-7RL4-V-J JKMxxxN-7RL4-J JKMxxxN-7RL4-V JKMxxxN-7RL4 (xxx = 535-590,in increment of 5) JKMxxxN-7RL4-B-V JKMxxxN-7RL4-B (xxx = 540-575,in increment of 5) JKMxxxN-7RL4-TV JKMxxxN-7RL4-TV-J (xxx = 520-585,in increment of 5) Group 83 JKMxxxM-78HL4-V (xxx = 565-605,in increment of 5) Group 84 JKMxxxM-78HL4-TV (xxx = 555-595,in increment of 5)
L4: 182 large cell series module TI: module with RSD Junction Box Jinko Cell Junction Wafer type Technology Module Type Cell Module Number STC condition: Normal mono- 158 5BB Mono- p-type Mono: M Full cell: 1 60: A Normal: A facial: A facial: A BSTC...
