IFP92UW
IFP105 Series
Commercial Touch Display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
Model No. VS20080 | VS19390
P/N: IFP92UW | IFP105S | IFP105G | IFP105UW | IFP105UW-N
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ViewSonic ViewBoard IFP105 Series
Summary of Contents for ViewSonic ViewBoard IFP105 Series
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
- Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
-
Page 3: Safety Precautions
Do not place any heavy objects on the device or connection cables. • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •... - Page 4 • Only use attachments/accessories specified by the manufacturer. • When a cart is used, use with caution when moving the cart/equipment combination to avoid injury from tipping over. • Disconnect the power plug from the AC outlet if the device is not being used for a long period of time.
- Page 5 Caution: Immediately unplug your device from the wall outlet and refer servicing to a qualified service personnel under the following conditions: • When the power supply cord or plug is damaged. • If liquid has been spilled onto or objects have fallen into the unit. •...
-
Page 6: Table Of Contents
Contents Safety Precautions ............3 Introduction .............. 11 Package Contents ....................11 IFP92UW ........................ 11 IFP105UW/IFP105UW-N ..................12 IFP105S/IFP105G ....................13 Wall Mount Kit Specifications (VESA) ..............14 IFP92UW ........................ 14 IFP105S/IFP105G/IFP105UW/IFP105UW-N ............15 Product Overview ....................16 Control Panel and Front I/O .................. 17 I/O Panel ........................ - Page 7 Using the ViewBoard ..........38 Turning On/Off the ViewBoard ................38 Initial Launch Setup ....................39 Home Screen ......................41 How to Sign Up ...................... 41 Use as Guest ......................42 Sign In ........................42 Home Screen Message ..................43 Toolbar .........................44 Toolbar Icons ......................45 Applications ......................46 Tools ........................47 Control Bar ......................48...
- Page 8 System Settings ............56 Network & Internet ....................56 Wi-Fi ........................57 Ethernet ........................ 58 Wireless Hotspot ....................59 Display ........................63 Wallpaper ......................64 Protection ......................65 HDMI Out ......................66 Preferences ......................67 Touch ........................68 Language ....................... 68 Keyboard & Input Method ..................69 Date &...
- Page 9 Pre-installed Applications and Settings ...... 90 myViewBoard .......................90 Screen Recorder ....................93 vCast ........................94 Display Group Settings ..................96 Synchronized Group Screen All the Time .............. 98 Share a Screen to the Display Group (One to Many Casting) ........ 98 Moderator Mode ....................99 Broadcast ......................
- Page 10 Appendix ..............140 Display Modes ....................140 HDMI 1 & DisplayPort Mode ................140 HDMI 2/3/4 & Type C Mode................141 Troubleshooting ....................142 Maintenance.......................144 General Precautions .................... 144 Cleaning the Screen ..................... 144 Cleaning the Case ....................144 Regulatory and Service Information ......145 Compliance Information ..................145 FCC Compliance Statement .................
-
Page 11: Introduction
Introduction Package Contents IFP92UW IFP92UW SLEEP DISPLAY P.MODE FREEZE VS20080 ViewBoard Series Compliance Statement IFP105UW ALT+TAB ALT+F4 SLEEP DISPLAY P.MODE FREEZE (VS19390) Compliance Statement ViewBoard Series -/-- Izjava o saglasnosti ALT+TAB ALT+F4 Izjava o saglasnosti SLEE D ISPLA Y P .MOD E F REEZ IFP105S (VS19390) -
Page 12: Ifp105Uw/Ifp105Uw-N
IFP105UW/IFP105UW-N IFP105UW SLEEP DISPLAY P.MODE FREEZE (VS19390) ViewBoard Series Compliance Statement IFP105UW ALT+TAB ALT+F4 SLEEP DISPLAY P.MODE FREEZE (VS19390) Compliance Statement ViewBoard Series Izjava o saglasnosti -/-- SLEE D ISPLA Y P .MOD E F REEZ ALT+TAB -/-- ALT+F4 Izjava o saglasnosti Compliance Statement IFP105S (VS19390) -
Page 13: Ifp105S/Ifp105G
IFP105S/IFP105G IFP105S/IFP105G SLEEP DISPLAY P.MODE FREEZE (VS19390) ViewBoard Series Compliance Statement SLEEP DISPLAY P.MODE FREEZE ALT+TAB ALT+F4 IFP105S (VS19390) Izjava o saglasnosti -/-- Compliance Statement ViewBoard series ALT+TAB ALT+F4 -/-- INPUT ASPECT MENU Izjava o saglasnosti Compliance Statement С а С... -
Page 14: Wall Mount Kit Specifications (Vesa)
Wall Mount Kit Specifications (VESA) IFP92UW NOTE: Please follow the instructions in the wall mount installation guide to install your wall mount or mobile mount bracket. If attaching to other building materials, please contact your nearest dealer. Model VESA Spec. (A x B) Standard Screw (C x D) Quantity IFP92UW... -
Page 15: Ifp105S/Ifp105G/Ifp105Uw/Ifp105Uw-N
IFP105S/IFP105G/IFP105UW/IFP105UW-N NOTE: Please follow the instructions in the wall mount installation guide to install your wall mount or mobile mount bracket. If attaching to other building materials, please contact your nearest dealer. Model VESA Spec. (A x B) Standard Screw (C x D) Quantity IFP105S IFP105G... -
Page 16: Product Overview
Product Overview Front Panel Control Panel and Front I/O Rear Panel... -
Page 17: Control Panel And Front I/O
Control Panel and Front I/O Number Item Description • Power indicator light. • Press to turn ON the device. • Press to turn OFF/ON the display backlight only. • Press and hold to turn off the device. Remote Control receiver. Ambient Light Sensor to monitor the ambient light. -
Page 18: I/O Panel
I/O Panel Figure 1 Number Item Description • USB Type A input • Connect USB devices such as hard disks, keyboard, USB 3.0 mouse, etc. • Automatically switches between PC and external PC. Touch signal output to external PC NOTE: •... - Page 19 Number Item Description • High-definition input. HDMI 2/3/4 • Connect to a PC with HDMI output, set-top box, or other video device. • USB Type C Power Delivery (65W, 20.0V~3.25A) USB Type C • DP 1.2 with USB 3.0 return •...
-
Page 20: Remote Control
Remote Control SLEEP DISPLAY P.MODE FREEZE ALT+TAB ALT+F4 -/-- INPUT ASPECT MENU DESKTOP D.MENU D.TITLE START ENTER D.USB D.SETUP ESC/EXIT BACK CH.+ VOL+ PGUP SPACE CH.- VOL - PGDN... - Page 21 Number Item Description Power ON/OFF Mute/Unmute SLEEP Sleep Mode For Non-Android sources; display current input source DISPLAY information P.MODE Blank Screen FREEZE Freeze Screen Numeric input buttons ALT+TAB Slot-in computer space bar Alt+Tab -/-- ALT+F4 Slot-in computer, close program window INPUT Input source selection ASPECT...
- Page 22 Inserting Remote Control Batteries To insert batteries into the remote control: 1. Remove the cover on the rear of the remote control. 2. Insert two “AAA” batteries, ensuring the “+” symbol on the battery matches the “+” on the battery post. 3.
- Page 23 Remote Control Receiver Range The working range of the remote control is shown here. It has an effective range of ° 8 meters, 30 degrees left and right. Ensure there is nothing obstructing the remote control’s signal to the receiver. 30°...
-
Page 24: Using Gestures
Using Gestures Touch gestures allow the user to use pre-determined commands without using a keyboard or mouse. Using gestures on the ViewBoard, the user can select/deselect objects, change the location of an object, access settings, erase digital ink, and much more. Select and Deselect an Object (Clicking) Press and release the ViewBoard to select/deselect options or objects. - Page 25 Moving an Object Press and hold the object on the ViewBoard and slowly drag it with your finger to your desired location. Erasing Digital Ink Use your flattened hand, palm, or fist on the ViewBoard and move your hand across the area which you wish to erase.
-
Page 26: Making Connections
Making Connections Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the display. 2. Plug the power cord plug into a power outlet. -
Page 27: Connecting To External Devices And Enabling Touch
Connecting to External Devices and Enabling Touch USB Cable TOUCH DP Cable USB Cable TOUCH Computer HDMI Cable HDMI Type C Cable Type-C... -
Page 28: Displayport Connection
Your external device(s) can be connected in any of the following configurations: DisplayPort Connection To connect via DisplayPort: 1. Connect a DisplayPort cable from your external device to the DP IN port on the ViewBoard. 2. Connect a USB Type B to A cable to the external device from the TOUCH 1 port of the ViewBoard. -
Page 29: Rs-232 Connection
RS-232 Connection RS-232 Computer When you use a RS-232 serial cable to connect the display to an external computer or control system, certain functions can be controlled remotely such as: power on and off, volume adjustment, input select, brightness, and more. -
Page 30: Usb Connection
USB Connection Just like any PC, it is easy to connect various USB devices and other peripherals to your ViewBoard. USB Type A USB Device Plug the USB device or storage drive into a USB Type A port of the ViewBoard. USB Type C USB Device Plug the USB device or storage drive into the USB Type C port of the ViewBoard. -
Page 31: Network Connection
Network Connection Network To connect to a local network, connect an Ethernet cable to your network, then connect the other end to a LAN port of the ViewBoard. -
Page 32: Media Connection
Media Connection HDMI IN Media Source To connect to a media source: 1. Connect an HDMI cable to a HDMI port on your ViewBoard and peripheral device. Plug in the power cord of your ViewBoard, and turn on the power supply switch. Press the Power button on the ViewBoard to turn the screen on. -
Page 33: Audio Connection
Audio Connection The ViewBoard supports Audio In, Audio Out, and SPDIF. Audio In To play audio from your external device through the ViewBoard’s speakers, connect one end of an audio cable to your external device, and the other end to the ViewBoard’s AUDIO IN port. -
Page 34: Video Output Connection (Hdmi Out)
Video Output Connection (HDMI Out) HDMI OUT Projector To output video via a display device: 1. Connect an HDMI cable to the HDMI IN port of your display device, and the other end to the HDMI OUT port of the ViewBoard. Plug in the power cord of the ViewBoard, and turn on the power supply switch. -
Page 35: Optional Connections
Optional Connections The ViewBoard comes with an OPS Slot as well as a Wi-Fi Slot for optional add-ons such as a slot-in PC (e.g., VPC3X Series/VPCF5) or Wi-Fi card (e.g., VB-WIFI-004). Slot-in PC (OPS Slot) Installation 1. Remove the OPS Slot cover of the display. 2. -
Page 36: Wi-Fi Card (Wi-Fi Slot) Installation
Wi-Fi Card (Wi-Fi Slot) Installation 1. Remove the Wi-Fi Slot cover of the display. 2. Carefully insert the slot-in Wi-Fi card into the Wi-Fi Slot of the display. 3. Secure the slot-in Wi-Fi card to the display. -
Page 37: Umb202 Camera Plate Installation
UMB202 Camera Plate Installation Rubber Washer Screw (M16 x 14 mm) UMB202 Camera Plate Screw (CM3 x 6 mm) -
Page 38: Using The Viewboard
Using the ViewBoard Turning On/Off the ViewBoard 1. Ensure the power cord is connected, plugged into a power outlet, and the power switch is in the “On” position. NOTE: The Power Switch is located at the bottom of the ViewBoard. 2. -
Page 39: Initial Launch Setup
Initial Launch Setup When you first turn on your ViewBoard, an initial setup wizard will launch. 1. Choose your preferred Language. 2. Setup and connect to a network. 3. Set and adjust the Date and Time as needed. - Page 40 4. Select your preferred System Mode. 5. Setup the Power Saving Plan. 6. Accept or decline the Privacy and Copyright Protection Terms.
-
Page 41: Home Screen
Home Screen On the Home Screen select from Use as Guest and Sign In. How to Sign Up Select the How to Sign Up button at the bottom of the screen, then scan the QR code and follow the directions to log in. -
Page 42: Use As Guest
Use as Guest Select the Use as Guest button to log in with a guest account. NOTE: Please note that user settings cannot be saved when logging in with a guest account. Sign In Select the Sign In button to log in with various accounts. -
Page 43: Home Screen Message
Home Screen Message The Home Screen message can be edited by selecting it directly on the Home Screen. Additionally, a password can be set by selecting the Set Up Password button. -
Page 44: Toolbar
Toolbar The Toolbar is where applications and tools can be found. Trigger icons are on the right, left, and bottom edge of the screen for quick access. To launch an application or tool: 1. Tap a Toolbar trigger icon. 2. Tap on the application or tool. NOTE: ... -
Page 45: Toolbar Icons
Toolbar Icons Description Icon Return to the previous operation screen. NOTE: Only for the ViewBoard source. Return Return to the Home Screen. Home Display all currently open applications. Recent View all installed applications. Applications Browse and open files. File Folder Quickly view and adjust various frequently used tools. -
Page 46: Applications
Description Icon myViewBoard Display Wirelessly mirror screens to a larger display. myViewBoard Manager Remotely manage multiple installations of ViewSonic devices. myViewBoard Whiteboard A digital whiteboarding application. Settings Access the System Settings. vCast Working with ViewBoard Cast software, receive vCastSender laptop screens (Windows/Mac/Chrome) and mobile (iOS/Android) users’... -
Page 47: Tools
Tools Various tools can be accessed from the Toolbar, directly from the Home Screen via shortcuts, or by selecting the Tools icon ( Description Icon Freezer Convert the currently displayed content into a still image; then you can zoom in, zoom out, go back to full screen, and exit. Spotlight Highlight the focus content zone. -
Page 48: Control Bar
Control Bar Frequently used settings and tools can be accessed quickly through the Control Bar. Control Bar Icons Description Icon Learn the basics of ViewBoard online by scanning the QR code that appears after tapping the icon. Online Guide If a USB storage device is connected, the USB icon will be visible. Tapping the icon will open the USB storage device’s folder. -
Page 49: On-Screen Display (Osd) Menu - General Settings
On-Screen Display (OSD) Menu - General Settings Access Input Source, Display, and other general settings through the OSD Menu. Input Source Menu Display Menu Open the OSD Menu by pressing INPUT on the remote control, touching the Input Source icon ( ) on the Home Screen or the Input Source icon ( ) in the Toolbar. -
Page 50: Input Source
Input Source To select an input source: 1. Press INPUT on the remote control, touch the Input Source icon ( ) on the Home Screen or the Input Source icon ( ) in the Toolbar to display the Input Source menu. Press on the remote control to select the input source you want. - Page 51 To adjust the volume: 1. Press INPUT on the remote control, touch the Input Source icon ( ) on the Home Screen or the Input Source icon ( ) in the Toolbar to display the Input Source menu. Touch and drag the volume slider directly to adjust the value, or press VOL +/ VOL - on the remote control to adjust.
-
Page 52: Display
Display To adjust the display settings: 1. Press INPUT on the remote control, touch the Input Source icon ( ) on the Home Screen or the Input Source icon ( ) in the Toolbar to display the Input Source menu. Then select the Display tab. -
Page 53: Display Menu Options
Display Menu Options Description Item Automatic brightness adjustment. Adjusts maximum brightness Auto Brightness according to ambient light levels. Energy Saving Enable to reduce power consumption. Adjusts the filter that blocks high-energy blue light for a more Eye Care comfortable viewing experience. Select a predefined picture setting. -
Page 54: Low Blue Light Filter And Eye Health
Low Blue Light Filter and Eye Health The Blue Light Filter blocks high-energy blue light for a more comfortable viewing experience. Calculating Breaks When viewing screens for extended periods, it is recommended to take periodic breaks from viewing. Short breaks of at least 10 minutes are recommended after one (1) hour of continuous viewing. - Page 55 Eye and Neck Exercises Eye Exercises Eye exercises can help minimize eye strain. Slowly roll your eyes to the left, right, up, and down. Repeat as many times as needed. Exercises for the eyes (1) Keep the body and the (2) Move the eyes le and (3) Move the eyes to look head upright.
-
Page 56: System Settings
System Settings When the display is in the ViewBoard input source, press MENU ( ) on the ) to enter the Settings menu. remote control or tap the setting icon ( Network & Internet Check current network connection status and set up and manage Wi-Fi, Ethernet, Wireless Hotspot, Bluetooth, and VPN. -
Page 57: Wi-Fi
Wi-Fi Setup and manage wireless access points. • Tap the toggle button to turn Wi-Fi On or Off. • Once On, you can: Add a Network, view Saved Networks, Refresh the network list, or view Advanced settings. • In Advanced settings, you can toggle Network notifications On or Off and view Network card info. -
Page 58: Ethernet
Ethernet Set the local network and proxy. • Tap the drop down menu to connect/disconnect the Ethernet. • You can adjust Local network and Proxy settings as well. -
Page 59: Wireless Hotspot
Wireless Hotspot Set and share your internet connection with other devices. • Tap the toggle button to turn Wireless hotspot On or Off. • Tap Set up to set the Network name, Security, and Password. - Page 60 Bluetooth Manage Bluetooth connections, set the device name and discoverability. • Touch the toggle to turn Bluetooth on or off. Once on, users can select a listed device to pair and connect to, rename their device, remove a device, or receive files.
- Page 61 Setup and manage Virtual Private Networks. To create a VPN profile: 1. Go to: Settings > Network & Internet > VPN and tap Add VPN. 2. Key in the Name.
- Page 62 3. Select the VPN Type. 4. Choose to enable/disable PPP encryption (MPPE) and/or show Advanced options.
-
Page 63: Display
Display Adjust the Wallpaper, Protection, and HDMI Out settings. -
Page 64: Wallpaper
Wallpaper Users can change their wallpaper with default images, or use their own by tapping the add icon ( ) and selecting the image file. -
Page 65: Protection
Protection Set HDCP & Copyright on or off. -
Page 66: Hdmi Out
HDMI Out Adjust the HDMI Out Resolution setting, enable video output, and mute/unmute the display speaker when connected via HDMI Out. NOTE: The disable ViewBoard speakers option box is not selected by default. -
Page 67: Preferences
Preferences View and adjust Touch, Language, Keyboard & Input, Date & Time, Boot Mode & Advanced, Start up & Shut down, Toolbar, Multi-Window Mode, and Sound settings. -
Page 68: Touch
Touch Adjust Touch Settings and toggle Touch Sounds and Windows Ink On/Off. Language Adjust and choose the preferred language from the available languages. -
Page 69: Keyboard & Input Method
Keyboard & Input Method Enable/disable the visual keyboard and/or change the default input method. Tap on Settings to adjust the advanced keyboard settings. NOTE: When an external USB keyboard is connected, the menu will display the physical keyboard settings option. -
Page 70: Date & Time
Date & Time Set the system time and format. Item Description Automatic Date & When enabled, the ViewBoard will automatically synchronize Time the date and time via the Internet. Time Zone Select the appropriate time zone. Choose from 12-hour or 24-hour time format. Simply toggle 24- Time Format hour format On/Off. -
Page 71: Boot Mode & Advanced Settings
Boot Mode & Advanced Settings Adjust the preferred boot up mode and set/reset a password. Item Description Normal Mode The embedded screen sharing Apps will run normally. Secured Mode The embedded screen sharing Apps will be removed. The system will automatically reboot, and then the Disable Embedded OS Embedded OS will not appear. - Page 72 Item Description ViewBoard Settings Toggle to lock/unlock the ViewBoard Settings. Access Password Modify the Boot mode and ViewBoard Settings entry Password for Protection password. Local File Protection Choose how long to keep local storage files in the Folder Policy application. Color Correction Color correct the ViewBoard display screen.
-
Page 73: Startup & Shutdown
Startup & Shutdown Set the Startup Input, Standby Mode, EnergyStar Mode, Black Screen After Startup, Power off Reminder timer and Schedule settings. Item Description Startup Input Adjust the Startup Input preference. Startup Application Automatically launch an application at startup. Decide what happens when you press the Power button while Standby Mode the ViewBoard is On. - Page 74 Item Description Enable to automatically initiate Sleep Mode when the screen is Energy Star idle for one hour. Black Screen After When enabled, the ViewBoard will turn off the backlight Startup automatically after booting up. Sign-in Page Launched Choose to skip the Sign-in page after startup. Upon System Startup Schedule Schedule a Boot and Shut off time.
-
Page 75: Toolbar Settings
Toolbar Settings Adjust the Side toolbar settings. Multi-Window Mode Display more than one app at the same time on screen when turned on. Sound Setting Adjust Touch Sound Output Settings. -
Page 76: Input Source
Input Source Adjust the input source names and settings, as well as the side toolbar settings. -
Page 77: Label Input Source
Label Input Source Set labels for each input source that will be easily recognized when displayed. -
Page 78: Source
Source Toggle Wake up by active HDMI input, Auto search signal, and HDMI CEC and select Auto switch input ports, Energy saving, and OPS 5K detect preferences. Item Description Wake Up by Active The screen will turn on automatically after plugging in an HDMI Input HDMI cable when the screen is off. -
Page 79: Apps
Apps The user can view application information and force stop, uninstall, move to USB storage, clear data, clear cache, and clear defaults. NOTE: • Pre-loaded apps cannot be uninstalled. • Not all apps support the move to USB storage feature. •... -
Page 80: Apps
Apps View any running or installed applications. Tap on them for more detailed information and options. • By tapping on a running application, you can see more information, stop, or report the application. - Page 81 • Selecting All will list all installed applications. • Tapping on any application will display further information and options. • Selecting Download will list all installed applications that can be uninstalled.
-
Page 82: System
System View and adjust Storage, Clone to USB, Display ID, Security, System Update, and About device settings. -
Page 83: Storage
Storage Check the storage space status of the display (internal) and any connected external storage devices. -
Page 84: Clone To Usb
Clone to USB Copy settings to an external USB drive. -
Page 85: Display Id
Display ID Assign a number to remote control the display by RS-232. • To assign or change the Display ID, tap Edit ID and input a number. NOTE: The Display ID is for RS-232 users, and the range is 01~98. -
Page 86: Security
Security Review Certificates, Trusted Credential storage, and Unknown sources install settings. • Tap on Install certificate from storage to add additional certificates. • Selecting Clear Credentials will remove all manually installed credentials. NOTE: Pre-loaded credentials cannot be cleared. • Under Trusted Credentials view and edit all trusted and installed CA certificates. •... - Page 87 • Allow the installation of applications from unknown sources by selecting the box under Unknown source security. NOTE: Applications from unknown sources may not be compatible or work properly.
-
Page 88: System Update
System Update The ViewBoard automatically searches for software updates whenever connected to the Internet (OTA). With just one click, users can update their version of ViewBoard software. Item Description Online Update Manually check online for a new software version. Local Update Update the software manually with a local file. -
Page 89: About Device
About Device Display Embedded Player information, Legal information, and Asset Tagging. • By selecting Edit, the asset information can be adjusted. • Tap on Legal information to check open source licenses. -
Page 90: Pre-Installed Applications And Settings
Pre-installed Applications and Settings NOTE: Installed applications are subject to change (install, uninstall, update) without notice when the system is updated. Please contact your local customer service if you have any questions. myViewBoard A digital whiteboarding application. NOTE: To learn more about myViewBoard Whiteboard, visit: https://myviewboard.com/kb/getting-started-whiteboard/overview- whiteboard. - Page 91 Main Toolbar Item Description Enable and manage wireless presentations by casting Wireless your session to other devices or receiving a feed from Presentation other devices. Screen Screenshot, video, and audio recording. Capture Select and hold to move the toolbar to the left side, right Move side, or bottom of the screen.
-
Page 92: Background Management
Background Management Item Description Sign In Sign in to a myViewBoard account. Background Change the canvas background. Management FollowMe Display custom images uploaded to a cloud storage Setting account. Color Palette Choose from solid or gradient colors as the background. Choose backgrounds that come pre-installed with Pre-installed Whiteboard. -
Page 93: Screen Recorder
Screen Recorder Capture everything that is displayed on screen in a video format. To launch the Screen Recorder application: 1. Select the Screen Recorder icon in the application drawer. 2. Tap the record icon and select the preferred recording configurations. Then tap the check mark. -
Page 94: Vcast
vCast Working with ViewBoard® Cast software (vCast, vCast Pro, and vCastSender), the vCast application will allow the ViewBoard to receive laptop screens (Windows/ Mac/Chrome) and mobile (iOS/Android) users’ screens, photos, videos, annotations, and camera(s) that are using the vCastSender application. - Page 95 ͫ UDP 48689, 25123 (Device searching and broadcast & client device audio transfer) ͫ UDP 5353 (Multicast search device protocol) • Port and DNS for Activation: ͫ Port: 443 ͫ DNS: https://vcastactivate.viewsonic.com • OTA Service ͫ Server Port: TCP 443 ͫ Server FQDN Name: https://vcastupdate.viewsonic.com...
-
Page 96: Display Group Settings
Display Group Settings To adjust the Display Group Settings, select the Display Group icon ( ) located in the lower-right corner of the screen. 1. Toggle the “Turn On/Off Display Group” ON to enable the Display Group feature. NOTE: Other preinstalled ViewBoard Cast devices in the same network will be listed. - Page 97 3. If you frequently connect to the same device, you can select the Star icon ( next to the device to add it to your frequently connected devices list, “My List of Devices in Group”, for easier Display Group setup and management.
-
Page 98: Synchronized Group Screen All The Time
Synchronized Group Screen All the Time When the “Synchronized group screen all the time” function is toggled ON, it will display a synchronized group screen continuously. If it is toggled OFF, it will work on vCast mirroring only. NOTE: Select the devices to group first, then toggle the “Synchronized group screen all the time”... -
Page 99: Moderator Mode
Moderator Mode Moderator Mode allows the moderator to take control of the devices connected to the ViewBoard or display. To enter Moderator Mode, select the Moderator Mode icon ( ) located in the lower-right corner of the screen. When enabled, the moderator can view a list of all connected screens in the left floating window and can preview each participant’s screen and then select any of participant’s screen and cast to the ViewBoard’s or display’s main screen for presentation. -
Page 100: Broadcast
Broadcast When enabled, the ViewBoard’s screen will be broadcasted to all of the participant’s connected screens simultaneously. The participants can only view the presentation contents until the moderator disables the Broadcast function. Multiple Screen Sharing By default, vCast is set to allow multiple screen sharing, but can also be set to single screen sharing. -
Page 101: Casting From Windows, Macbook, And Chrome Devices
Casting from Windows, MacBook, and Chrome Devices 1. Ensure the client device (e.g., laptop) is connected to the same network as the ViewBoard. NOTE: The network name can be found under Room Network. 2. On the client device, visit the address that is shown on the ViewBoard to download and install the vCastSender application. - Page 102 4. To connect to the ViewBoard, input the PIN code and click OK. NOTE: The PIN code can be found as highlighted below: 5. Additionally, you can connect to the ViewBoard by clicking Device List then the Device Name listed. NOTE: ...
-
Page 103: Casting From Android Devices
Casting from Android Devices 1. Ensure the client device (e.g., Android phone or tablet) is connected to the same network as the ViewBoard. NOTE: The network name can be found under Room Network. 2. On the Android client device, scan the QR code shown on the ViewBoard to directly download the vCastSender application, or download the application from the Google Play Store. - Page 104 3. After installing, launch the vCastSender application. 4. To connect to the ViewBoard, input the PIN code and select OK. NOTE: The PIN code can be found as highlighted below: 5. You can also connect to the ViewBoard by selecting Device List then the Device Name listed.
- Page 105 6. Additionally, you can connect to the ViewBoard or by selecting Scan then placing the on-screen QR code into the box to automatically connect.
-
Page 106: Casting From Apple Ios Devices
Casting from Apple iOS Devices Apple AirPlay® is compatible with vCast for screen mirroring and content streaming under the same subnet environment only. An “AirPlay Password” will be generated on-screen for connection when using AirPlay to cast to a ViewBoard. 1. - Page 107 2. On the iOS client device, directly open AirPlay and select the Device Name of the ViewBoard to connect. NOTE: The Device Name can be found as highlighted below: 3. Input the generated on-screen AirPlay Password on the client device to connect. NOTE: ...
- Page 108 4. You can also connect to the ViewBoard by selecting Scan then placing the on- screen QR code into the box to automatically connect.
-
Page 109: Connecting To A Viewboard From A Mobile Device
Connecting to a ViewBoard from a Mobile Device Once connected, select Receive. The ViewBoard will appear on the mobile device with an on-screen toolbar. Users can interact with the ViewBoard with annotations, file sharing, etc. Item Description Toggle Hide or display the toolbar. Home Return to the Home interface. -
Page 110: Casting With Chromecast
Casting with Chromecast vCast supports native Chromecast screen sharing via the Chrome browser casting when the Chromecast feature is enabled. NOTE: Chromecast does not support password protection or multiple-screen casting. 1. Ensure the client device (e.g., laptop) is connected to the same network as the ViewBoard. - Page 111 3. In the Chrome browser, go to: Settings > Save and share > Cast... > Select the screen to cast to.
-
Page 112: Casting With Miracast
Casting with Miracast vCast supports native Miracast to cast content from Windows and Android devices to a ViewBoard when the Miracast feature is enabled. NOTE: • Miracast does not support password protection or multiple-screen casting. • Miracast sharing is only available over Wi-Fi. •... - Page 113 3. Please follow the below steps to cast: For Windows devices: 1. On the Windows device, press Win + K and select the display to cast to. 2. Select the checkbox “Allow mouse, keyboard, touch, and pen input from the device”...
-
Page 114: Other Default Applications
Other Default Applications Browser Web browser for surfing the Internet. -
Page 115: Finder
Finder Manage files and folders. 1. Storage Device Display Select the appropriate storage device. 2. Icons Description Item Grid Display files by grid List Display files by list Sort Sort the files Select Select a file Create Create a new folder Copy Copy a file Paste... -
Page 116: Office
Office Create, edit, and view documents, spreadsheets, presentations, and PDFs. -
Page 117: Pip (Picture-In-Picture)
PIP (Picture-in-Picture) Split the screen into two parts, a main window and an inset window. NOTE: PIP only works between an Android application (browser, media player, vCast) and an external source. • To open PIP, select: All Apps > PIP. •... - Page 118 • To change PIP input source select HDMI 1, HDMI 2, HDMI 3, HDMI 4, Type C 1, Type C 2, or DP. • To control the connected external device’s volume, select Sound. • Select Enter to switch to the PIP input source.
-
Page 119: Visualizer
Visualizer Display video from a connected camera. -
Page 120: Vsweeper
vSweeper Clear unnecessary data and unwanted files. -
Page 121: Rs-232 Protocol
RS-232 Protocol This document describes the hardware interface spec and software protocols of RS- 232 interface communication between ViewSonic LFD and PC or other control units with RS-232 protocol. The protocol contains three command sections: • Set-Function • Get-Function • Remote control pass-through mode NOTE: ... -
Page 122: Lan Hardware Specification
LAN Hardware Specification ViewSonic LFD communication port on the rear side: 1. Connector type: 8P8C RJ45 2. Pin Assignment: Pin # Signal Remark Output from Display Output from Display Input to Display BI_D3+ For 1G case BI_D3- For 1G case... -
Page 123: Protocol
Protocol Set-Function Listing The PC can control the Display for specific actions. The Set-Function command allows you to control the Display behavior at a remote site through the RS-232 port. The Set-Function packet format consists of 9 bytes. Set-Function Description: Length: Total Byte of Message excluding “CR”... - Page 124 Example 1: Set Brightness as 76 for Display (#02) and this command is valid Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38 0x73 0x24 0x30 0x37 0x36 0x0D 0x32 Reply (Hex Format) Name Length Command Type 0x30 0x34 0x2B...
- Page 125 Set-Function Table A. Basic Function Set Function Length ID Command Command Value Range Comments Code Code (Three ASCII Type (ASCII) (ASCII) (Hex) bytes) 1. The Power-on via LAN control may works only under specific mode. To Power on/ off 000: STBY see display UG for (standby) 001: ON...
- Page 126 000: Unlock Button lock *See note in details 001: Lock 000: Unlock Menu lock > *See note in details 001: Lock Number 000~009 *3.1.1 000: UP 001: DOWN 002: LEFT 003: RIGHT Key Pad *3.1.1 004: ENTER 005: INPUT 006: MENU/(EXIT) 007: EXIT Disable: RCU will be no function...
-
Page 127: Optional Function
B. Optional Function Set Function Length ID Command Command Value Range Comments Code Type (ASCII) Code (Hex) (Three ASCII bytes) (ASCII) Contrast 000 ~ 100 Sharpness 000 ~ 100 Color & 000 ~ 100 Tint ‘ 000 ~ 100 000: Off Backlight On_Off 001: On 000: Normal... - Page 128 000: OFF Tiling-Mode 001: ON (for video wall) 000: OFF (for video wall) Tiling-Compen- 001: ON Bezel width com- sation pensation (for video wall) 01x~09x: H 1. 2nd digital for H Tiling-H by V 0x1~0x9: V monitors Monitors 2. 3rd digital for V monitors (for Video wall) Copy the screen...
-
Page 129: Get-Function Listing
Get-Function Listing The PC can interrogate the LFD for specific information. The Get-Function packet format consists of 9 bytes which is similar to the Set-Function packet structure. Note that the “Value” byte is always = 000. Get-Function Description: Length: Total Byte of Message excluding “CR”. TV/DS ID Identification for each of TV/DS (01~98;... - Page 130 Example 1: Get Brightness from TV-05 and this command is valid. The Brightness value is 67. Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38 0x67 0x62 0x30 0x30 0x30 0x0D 0x35 Reply (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38...
- Page 131 Get-Function Table A. Basic Function Response Get Function Length ID Command Command Comments Range Code Code (Three ASCII Type (ASCII) (ASCII) (Hex) bytes) Get-Brightness 000 ~ 100 1. For Android platform whose main mode is controlled by backlight and the other sources are 000 ~ 100 Get-Backlight...
- Page 132 (for the model with LAN) Get-MAC address Reply in new 32-byte format *3.2.0 (for the model with LAN) Get-IP address *3.2.0 Reply in new 32-byte format*3.2.0 Reply in new 32-byte Get-Serial number format *3.2.0 *3.2.0 Reply in new 32-byte Get-FW version *3.2.0 format *3.2.0 NOTE: ...
- Page 133 6. Get FW version example Assumed the FW version is 3.02.001 Send: 0x 38 30 31 67 38 30 30 30 0D (Get FW version) Reply: 0x 32 30 31 72 38 33 2E 30 32 2E 30 30 31 00 00…00 00 0D...
- Page 134 B. Optional Function Response Get Function Length ID Command Command Comments Range Code Type (ASCII) Code (Hex) (Three ASCII bytes) (ASCII) Get-Contrast 000 ~ 100 Get-Sharpness 000 ~ 100 Get-Color 000 ~ 100 Get-Tint 000 ~ 100 000: Off Get-Backlight 001: On On_Off 000: OFF...
- Page 135 2. Get Time example Assumed the current time of display#01 as below: Time: 16:27:59 Send: 0x 38 30 31 67 33 48 30 30 0D (Get Time:Hour) Reply: 0x 38 30 31 72 33 48 31 36 0D (“H16”) Send: 0x 38 30 31 67 33 4D 30 30 0D (Get Time:Min) Reply: 0x 38 30 31 72 33 4D 32 37 0D (“M27”)
- Page 136 C. Auto Reply *3.2.1 The display will send out the updated data/status automatically without getting a query from the host whenever the following data/status is changed by the user through any of the available ways like: remote control unit, front keys, or touch screen.
-
Page 137: Remote Control Pass-Through Mode
Remote Control Pass-through Mode When the PC sets the Display to Remote Control Pass through mode, the Display shall send a 7-byte packet (followed by “CR”) in response to remote control unit (RCU) button activation. In this mode the remote control shall have no effect on the Display function. - Page 138 VOLUME DOWN (-) MUTE CHANNEL/PAGE UP (+)/ BRIGHTNESS+ CHANNEL/PAGE DOWN (-)/ BRIGHTNESS- POWER SOURCES (INPUTS) SLEEP MENU DOWN LEFT (-) RIGHT (+) OK (ENTER, SET) EXIT (F1) ■ GREEN (F2) ■ YELLOW (F3) ■ BLUE (F4) ■ NOTE: This IR-pass-through code is different from the RCU key code. Special control sequence for POWER key under IR-pass through mode.
- Page 139 2-2. When Display is ON and receives the IR POWER code: Display will forward the POWER code to the host via RS-232, then turn off itself. 2-3. When SET-POWER LOCK is enabled, the Display will not respond to POWER key pressing. The VOLUME UP and VOLUME DOWN code will repeatedly output when you press and hold the keys.
-
Page 140: Appendix
Appendix Display Modes HDMI 1 & DisplayPort Mode Resolution Refresh Rate (@) 640 x 480 30 Hz, 60 Hz 720 x 480 30 Hz, 60 Hz 720 x 576 30 Hz, 50 Hz, 60 Hz 800 x 600 30 Hz, 60 Hz 1024 x 768 30 Hz, 60 Hz 1152 x 864... -
Page 141: Hdmi 2/3/4 & Type C Mode
HDMI 2/3/4 & Type C Mode Resolution Refresh Rate (@) 640 x 480 60 Hz 720 x 480 60 Hz 720 x 576 60 Hz 800 x 600 60 Hz 1024 x 768 60 Hz 1152 x 864 60 Hz 1280 x 600 60 Hz 1280 x 720... -
Page 142: Troubleshooting
Troubleshooting This section describes some common problems that you may experience when using the ViewBoard. Problem or Issue Possible Solutions 1. Check whether something is obstructing the display’s remote control receiver. Remote Control is not 2. Check whether the batteries in the remote control working are installed correctly. - Page 143 Video Not Working Properly Problem or Issue Possible Solutions 1. Check the Power status. 2. Check the signal cable. No picture/ No sound 3. Check that the internal PC is installed correctly. 1. Check the signal cable. Picture is unclear or cuts in and out 2.
-
Page 144: Maintenance
Some chemical cleaners have been reported to damage the screen and/or case of the device. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. NOTE: If condensation appears between the glass and the panel, keep the... -
Page 145: Regulatory And Service Information
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. ViewSonic is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. -
Page 146: Declaration Of Rohs2 Compliance
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law. -
Page 147: Energy Star Statement
U.S. Environmental Protection Agency. As an ENERGY STAR Partner, ViewSonic is determined to meet the Energy star Guidelines and mark all certified models with the ENERGY STAR logo. -
Page 148: Indian Restriction Of Hazardous Substances
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®... -
Page 149: Copyright Information
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic® and the three birds logo are registered trademarks of ViewSonic® Corporation. VESA is a registered trademark of the Video Electronics Standards Association. -
Page 150: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/ Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/... -
Page 151: Limited Warranty
ViewSonic® Smart White Board What the warranty covers: ViewSonic® warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, and as your sole remedy, repair or replace the product with a similar product. - Page 152 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
- Page 153 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
-
Page 154: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 155 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
- Page 156 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
Need help?
Do you have a question about the ViewBoard IFP105 Series and is the answer not in the manual?
Questions and answers
