- Page 1 Nr 9972-306010 Sahlins Sweden AB www.sahlins.com Underground cablewinch 3060 Instructionmanual Oktober 2010 v. 39...
- Page 2 SAHLINS product SAHLINS product We want you to be satisfied with your 3060 winch, and this Instruction Manual has been written to help you handle and maintain it safely. Please read it carefully before operating the machine, so that you are aware of the safety measures you need to take when you use it.
-
Page 3: Table Of Contents
Instructionmanual Innehållsförteckning Innehållsförteckning Innehållsförteckning Innehållsförteckning Safetyregulations ............................. 4 Technical specifications ..........................6 Handling ..............................7 Fitting the drum ............................ 7 Fitting the wirerope on capstanwheels ....................7 Operation .............................. 8 Fit the drive unit ............................ 8 Operating .............................. 8 Pre-setting of pullingforce ........................8 Maintenance ............................. -
Page 4: Safetyregulations
Repair or replace damaged components, or any which are suspected of damage. Repair or replace damaged parts before starting and operating the equipment. Use only genuine SAHLINS parts. 20. Before starting and operating the equipment, it is essential to ensure that no persons, animals, tools, components or other foreign objects are in, on, under or around it. - Page 5 Instructionmanual 24. Watch out when starting and operating the equipment for any defective measuring instruments, visible defects, smells or unusual sounds wich may give a warning of a fault. Stop the equipment immediately if a fault is suspected. 25. Carry out all inspections, maintenance, lubrication and adjustments with great care, and in accordance with the manufacturer´s recommendations.
-
Page 6: Technical Specifications
Instructionmanual Description of underground cablewinch: The winch 3060 large-capacity underground winch. Driven with either combustion-, hydraulic- or electric engine. It’s equipped with two capstanwheels and a separate collectingdrum. When pulling undergroundcable a steelwirerope is used. Thanks to the capstan system you always have acess to the maximum pullingforce. -
Page 7: Handling
Instructionmanual Handling Fitting the drum The collectingdrum is equipped with a springcatch. Pull up the springcatch and fit the drum on the shaft Make sure that the springcatch hits the hole on the shaft. When pulling out line – fit the drum so that the springcatch hits the groove on the shaft. -
Page 8: Operation
Instructionmanual Operation Place the winch on a level surface, and make a straight line towards the object that is to be towed. Warning! Warning! Warning! Warning! Fix the winch with the anchoring bars (4pcs) through the anchoring eyes. Fix the winch with the anchoring bars (4pcs) through the anchoring eyes. Fix the winch with the anchoring bars (4pcs) through the anchoring eyes. -
Page 9: Maintenance
Instructionmanual Maintenance Drive unit: See instructionmanual for drive unit. Winch unit: The oillevel in the winchhousing is checked at the upper oilplug of the frontgable. If needed fill with gearboxoil SAE 90, fill at the breatherplug on the top of the winch. Change the oil once a year approx. -
Page 10: Drivechain
Instructionmanual Drivechain The tension of the drivechain for the collectingdrum is adjusted with the tensioner (see picture) Loosen the two bolts put a screwdriver and break until you get the right tension Tighten the two bolts again. Tensioner Frictioncoupling The frictioncoupling works to create tension between the collecting drum and capstanwheels. To reach the coupling release the topcover. -
Page 11: Frictionbrake
Instructionmanual Frictionbrake The frictionbrake that prevents the drum from Overrunning can be adjusted: Loosen the two locknuts and adjust the screws. Adjust equal on both screws to get the frictiondisc to maintain an even tension. The adjustment is performed with a full drum. Make sure that the drum doesn’t rotates to sluggish and that it stops instantly when you stop winching. -
Page 12: Accessories
2042- - - - 3000 3000 2042 2042 3000 3000 Accessories Wiredrum exkl.wire Part.no: 3060 3060 3060- - - - 0010 3060 0010 0010 0010 Steelwirerope (500 m / ø 5 mm) Part no:: 7540 7540 7540- - - - 001 7540... -
Page 13: Spareparts
Instructionmanual Spareparts Winch sid. 13 (19) - Page 14 Instructionmanual Sparepartslist ref. to page 12 Ref.No. Partnumber Partname 3060-5001 Winchhousing / Vinschhus 3060-5002 Bullwheel / Nockhjul 3060-5004 Bearinglid / Lagerlock 9462-30477 Sealing ring /Tätningsring 9201-6006-0 Ballbearing / Spårkullager 6006-0 9322-0840 Flat key / Plattkil 8x7x40 T 9321-0840 Flat key / Plattkil 8x7x40 R...
-
Page 15: Linespreader And Gauge
Instructionmanual Linespreader and gauge sid. 15 (19) - Page 16 Instructionmanual Sparepartlist ref. to page 14 Ref.No. Partnumber Partname 9511-3010 Black ball / Kula Ø30 3060-5020 3060-5021 Roller / Rulle 9254-0810 Slide bearing / Glidlager 9361-08060 Screw / Skruv M8x60 9449-013 Spacer / Bricka 9674-001 Breather / Andningsplugg MTSF 3060-5019 Cover / linespreaderattachment / Lock / linspridarfäste...
-
Page 17: Frictionunit / Drumholder
Instructionmanual Frictionunit / drumholder sid. 17 (19) - Page 18 Instructionmanual Sparepartlist ref. to page 16 Ref.No. Partnumber Partname 3062-5016 Drumholder frame / Trumhållarstativ 3062-5024 Chainguard / Kedjeskydd 3060-5047 Nut / Mutter 9485-001 Discspring / Tallriksfjäder 3060-5046 Clutch driveplate / Tryckplatta 9591-001 Frictiondisc / Friktionsbelägg 9229-001 Needle bearing / Nållager...
- Page 19 Instructionmanual If you have questions – don’t hesitate to contact us Sahlins Sweden AB Tel. +46320 20 93 30 Huvudkontor: Box 2103 / Hedbovägen 42 511 02 Skene Fax +46320 319 38 Lager och produktion: Företagsvägen 5 512 64 Holsljunga Fax +46325 333 02 www.sahlins.com...
