- Page 1 No. 9972-2060010 LINE MACHINE 2060 USER MANUAL...
-
Page 2: Table Of Contents
Content THANK YOU FOR CHOOSING A SAHLINS PRODUCT! ..............3 SAFETY RULES ..........................4 INTRODUCTION ..........................6 TECHNICAL DATA ........................... 7 COMPONENTS ..........................8 MOUNTING ............................. 9 MANOEUVRING ..........................12 MAINTENANCE ..........................15 SPARE PARTS ..........................16 LIST OF SPARE PARTS ........................18... -
Page 3: Thank You For Choosing A Sahlins Product
THANK YOU FOR CHOOSING A SAHLINS PRODUCT! We want you to be happy with your Line Machine 2060. This instruction manual has been written to facilitate its safe handling and maintenance. Please read the manual thoroughly before using the equipment so that you are aware of the safety measures you need to take when using it. -
Page 4: Safety Rules
SAFETY RULES General safety rules 1. Read and acquaint yourself with all of the warnings, precautionary measures and instructions in the user and care manual, and read and learn the importance of all the signs on and around the equipment. In case of any doubt, ensure that you have answers to all your questions before starting the work. - Page 5 20. Before starting and operating equipment, ensure that no people, animals, tools, spare parts or other foreign objects are present in, on, under or around it. Check that all protective and safety equipment is correctly installed and in satisfactory condition. 21.
-
Page 6: Introduction
INTRODUCTION Line machine 2060 is a portable overhead cable winch for running overhead cable and bare wire on a front rope drum or demolition and replacement using a split drum. The winch is constructed in three manageable base units: engine with gearbox, pole and drum holding frame and a drum. -
Page 7: Technical Data
TECHNICAL DATA LINE MACHINE Model 2060 Dimensions L x W x H 550 x 220 x 340 mm Pulling speed Approx. 0-29 m/min (controlled with the engine throttle.) Pulling force 400 kp Winch line 6 mm synthetic winch line Compatible drums... -
Page 8: Components
COMPONENTS Name Line spreader Exhaust hose Capstan wheel Petrol engine Front rope drum Drive belt Rotatable input wheel Pole bracket Drum arm... -
Page 9: Mounting
MOUNTING Work with line machine: SAHLINS line machine is reliable in design to provide safety. It can help you to perform your work easily and facilitate your work. However, it is important that you follow these instructions carefully as improper handling can be hazardous. - Page 10 - Lock the drum holder with the lock screw on the inside of the bracket. Line spreader and exhaust hose - Install the line spreader on the attachment for the input roller. Always use the line spreader for line pulling. - Fasten the exhaust hose with the spring clamp and place the outlet at a suitable distance from the operator.
- Page 11 WARNING! Before tightening the rope, make sure that the latch on the drum is locked properly.
-
Page 12: Manoeuvring
Drive shaft The drive shaft is intended for mounting and driving the capstan wheel or demolition drum when operating the Line Machine 2060 and some cable drum trolleys. V-belt wheel On the “inside” there is a V-belt wheel which drives the front rope... - Page 13 Using the demolition drum - Remove the capstan wheel from the output shaft and mount it on the wind wheel. - Secure the latch making sure that the claw coupling engages the shaft. - Make sure that the tension grip on the drum end is tightened before winding in the rope.
-
Page 14: Starting And Stopping The Engine
3-stroke Polynite with a min. breaking load of 800 kp. (6 mm L 550 m or. 1,100 m) For any other ropes, contact Sahlins Sweden AB for approval before use. Use swivels between the traction rope and the single-ended cable grip. The jointing should be done through approved splicing. -
Page 15: Maintenance
MAINTENANCE Engine maintenance See the operating instructions for the Honda GX 160. General maintenance If necessary, lubricate the tension grip on the belt tensioner and the tension screw on the eccentric lock. Check and lubricate the shaft coupling and drum locks on the drums. Check the tow line regularly for signs of damage. -
Page 16: Spare Parts
SPARE PARTS... -
Page 18: List Of Spare Parts
LIST OF SPARE PARTS Ref. Name Amount Tension spring Heat protection Plug VSTI 16 x 1.5 ED Screw Washer 8.4x26x5 Left-hand threaded screw Spring washer FBB 8.2 Spring washer FBB 6.1 Screw M6S M8X25 Screw M6S M8X40 Screw M6S M6X20 Insex screw MF6S M6X20 Stop screw S6SS M4X6 Screw M7 SPEC... -
Page 19: Ec Declaration Of Conformity
(SV) EG-FÖRSÄKRAN OM ÖVERENSSTÄMMELSE (EN) EC DECLARATION OF CONFORMITY (FR) EC DÉCLARATION DE CONFORMITÉ (DE) EG-KONFORMITÄTSERKLÄRUNG (IT) DICHIARAZIONE CE DI CONFORMITÀ... - Page 20 Sahlins Sverige AB Företagsvägen 2 512 64 Holsljunga Sweden<r/> +46(0)320 209 330 | sales@sahlins.com 20/04/2021...
