Eco Stage ONE-WW+O User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ONE-WW+O
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONE-WW+O and is the answer not in the manual?

Questions and answers

Related Manuals for Eco Stage ONE-WW+O

Summary of Contents for Eco Stage ONE-WW+O

  • Page 1 ONE-WW+O User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Before you work ....................2 acking instructions ..........................1.2 AC Power ..............................1.3 Safety nstruction ............................2. Specification ..............................3. Accessories ..............................4. How to set up the unit ..........................4.1 Rear panel ..............................4.2 Main function ............................

  • Page 3: Before You Work

    1. Before you work Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING 1.1 Packing instructions : When you get this product, please take it from carton carefully to make sure whether all the accessories are in and damaged or not.

  • Page 4: Specification

    2. Specification: ⚫ Input voltage： AC 100~240V, 50/60Hz ⚫ Power consumption： WW/100W O/100W ⚫ Rated power: 100W COB 100W(warm white)+100W ⚫ Light source： (Orange) ⚫ Life of LED: 50000 hours ⚫ Field angle： 60° ⚫ Dimming: 0-100% linear dimming ⚫ Dimming curve: 4 kinds of dimming curves ⚫...

  • Page 5: Main Function

    1. Buttons MENU Go to menu selection DOWN Go to the next option Go back to the previous option ENTER Confirm the selected function Display: OLED 1.3 inch display, show menu and selected functions. 4.2. Main function Turn on the light, press the MENU button to enter the menu mode, use the UP and DOWN buttons to find the menu, when the preset menu is displayed on the display screen, press the ENTER button to confirm, use the UP and DOWN buttons to select the sub menu, press the ENTER button to save the settings or automatically return to the previous menu.
  • Page 6 Dimming bit 16bt/08bt Dimming bit default（16) bit Refresh rate 2-14K Refresh rate default（14） Dimming Linear/square/anti-square/S- Dimming curve select default（linear） curve line ℉/℃ Thermomet ℉/℃ default（℃） Reset Determine/give up default（give up） DMX Address Select the DMX address, press ENTER to confirm, and the current DMX address will be displayed on the display.

  • Page 7: How To Control

    Auto Test Select the Auto Test, press ENTER to confirm, The light will be automatically detected. Press the MENU button to return to menu mode. 5. How to control You can operate the unit in three ways: 1. By master/slave built-in preprogramed function 2.

  • Page 8: Dmx512 Configuration

    DMX512 configuration(CH3) Function Specification 1 CH Dim all 2 CH warm white 3 CH orange DMX512 configuration(CH6) Function Specification 1 CH Dim all 2 CH strobe all 3 CH warm white dimming 4 CH orange dimming 5 CH Effect DTR 000-255 001-020 orange, 021-255 warm white，two colors up to 255...

  • Page 9: Troubleshooting

    The DMX output and input connectors are pass-through to maintain the DMX circuit when one of the units’ power is disconnected. 3. At last fixture, the DMX cable has to be terminated with a terminator to reduce signal errors. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 5-pin XLR-plug and plug it in the DMX-output of the last fixture.
  • Page 10 ⚫ Always dry the parts carefully. ⚫ Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
