PRODUCT CATALOG
SEPTEMBER 2024
VX4 product profile
The Verdant VX4 Series Thermostat delivers optimal comfort and energy
efficiency by setting personalized temperature schedules in a sleek and
modern design with fingerprint resistant glass.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Verdant VX4 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Copeland Verdant VX4 Series

Summary of Contents for Copeland Verdant VX4 Series

  • Page 1 PRODUCT CATALOG SEPTEMBER 2024 VX4 product profile The Verdant VX4 Series Thermostat delivers optimal comfort and energy efficiency by setting personalized temperature schedules in a sleek and modern design with fingerprint resistant glass.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Table of contents Contents Page Overview Display HVAC equipment compatibility Unique compatibility 8-14 Interactions and features 15-18 Networking overview Optional accessories Best practices and general notes General specifications 22-24 Verdant accessories 25-XX Warranty Submittal...

  • Page 3: Overview

    OVERVIEW Overview The field-proven Verdant VX4 thermostat is robust, reliable, and offers unparalleled value for property owners. Trusted by thousands of hotels and MDU properties throughout North America, Verdant VX4 comes with all the great features that made Verdant a preeminent leader in guestroom energy management technology. Verdant VX Series Energy Management Thermostats deliver unprecedented energy savings without compromising the comfort of occupants.

  • Page 4: Display

    DISPLAY Display Faceplate SYSTEM MODE Use to cycle between system UP | DOWN mode & ON/OFF Increase | Decrease values SETTINGS Change F | C FAN MODE Enable SCHEDULER OCCUPANCY SENSOR...
  • Page 5 DISPLAY Standard display (typical) ROOM TEMPERATURE SYSTEM MODE Current operating mode FAN MODE AUTO: fan speed automatically adjusted according to demand HIGH|MEDIUM|LOW: user adjusted...
  • Page 6 DISPLAY Screen icons PROTOCOL ZigBee | Demand Response ROOM NUMBER SCHEDULER BATTERY STATUS DOOR | WINDOW STATUS...

  • Page 7: Hvac Equipment Compatibility

    HVAC EQUIPMENT COMPATIBILITY HVAC equipment compatibility The VX4 line of thermostats is capable of natively integrating with a number of manufacturer’s and equipment, allowing for unparalleled energy management with optomized controls with both standard and leading-edge HVAC systems. The VX4 line offers both a wired and wireless solution for 24 VAC controlled systems including PTAC, PTHP, VTAC, FCU, andUnitary equipment.

  • Page 8: Unique Compatibility

    UNIQUE COMPATIBILITIES Unique compatibilites Mitsubishi/Trane The MIE thermostats incorporate native connectivity with CITY MULTI(R) Indoor VRF units and M-, P-, and Nv- series mini- splits. The control card connects directly to the CN105/95 port of the compatible METUS unit. Wireless thermostats can be powered with 12 VDC via the J11 port in leui of AA batteries.
  • Page 9 UNIQUE COMPATIBILITIES The LG thermostats incorporate native connectivity with all LG indoor VRF units, inverter PTACs, and mini-splits. The control card connects directly to the CN_REMO port of the LG unit. The VX4 platform’s communication with the indoor LG unit will not interfere with the exitsing communciation and protocol between the indoor and outdoor units.The CN_REMO port on the LG indoor unit is capable or providing power to the VX4 control card.
  • Page 10 UNIQUE COMPATIBILITIES Carrier The CV12 thermostats incorporate native connectivity with Carrier 40VM* indoor VRF units. The control card connects directly to the compatible Carrier unit. The control card is capable of being powered by the Carrier indoor unit via the HA/HB ports on the unit.
  • Page 11 UNIQUE COMPATIBILITIES Toshiba Carrier The TCAB thermostats incorporate native connectivity with Toshiba Carrier indoor VRF and mini-split units. The control card connects directly to the compatible Carrier unit. The control card is capable of being powered by the Carrier indoor unit via the A/B ports on the unit.
  • Page 12 UNIQUE COMPATIBILITIES GE Appliances In addition to being compatible with standard GE PTAC and VTAC units with the standard VX4-TR and VX4-TW products, the VX4 platform is also capable of controlling the new V 12 (AZ9V*) series VTAC and the make-up air PTACs with the VX4- GEA line of product.
  • Page 13 UNIQUE COMPATIBILITIES Daikin & Airzone The AZA-* accessories allow for integration with Diakin, Fujitsu, and Hitachi VRF systems. The control card connects directly to the Airzone adapter, which then connects directly to the HVAC unit. Wireless thermostats can be powered with 12 VDC via the J11 port on the control card in leui of AA batteries.
  • Page 14 UNIQUE COMPATIBILITIES Fan coils and high-voltage The VX4 platform is capable of controlling high-voltage and/or modulating valve fan coils. Wiring diagram NOTE: Wireless VX4 only.

  • Page 15: Interactions And Features

    INTEGRATIONS & FEATURES Integrations and features The VX4 platform is capable of integrating with a number of different technology stacks including door lock management systems (DLMS), property management systems (PMS), building automation systems (BAS/BMS), and lighting circuits. The VX4 platform also offers 7-day schedling capability at the physcial thermostat or remotely. Demand response capability is also available.
  • Page 16 INTEGRATIONS & FEATURES Property management systems The VX4 platform is capable of integrating with a number property management systems, allowing property operators to seamlessly monitor and control multiple inputs and outputs of their HVAC system within the existing technology ecosystem of their property.
  • Page 17 INTEGRATIONS & FEATURES 7-day scheduler All VX4 thermostats come equipped with a 7-day programmable schedule. The schedule is able to be set at the physical device or via an online app. Each day may have up to six disctinct scheduling events. Demand response All VX4 thermostats with firmware version 1130 or later are capable of recieving demand response events.
  • Page 18 INTEGRATIONS & FEATURES Door lock management systems and smart locks The VX4 platform is capable of integrating with door lock management systems (DLMS) and smart locks, adding another layer of occupancy detection to an application. DLMS brand compatability and general application are shown in the table and diagram below.

  • Page 19: Networking Overview

    NETWORKING OVERVIEW Networking overview A mesh network is a group of connectivity devices that act as a single network, so there are multiple sources of connectivity instead of just a single router. Mesh networks broadcast from each point around the facility rather than from a single location, thereby providing better coverage over a wider space.

  • Page 20: Optional Accessories

    OPTIONAL ACCESSORIES Optional accessories ZX-OL-U: online connection kit/gateway Mesh network end-point device responsible for aggregating all thermostats connected for feedback, access, and control. Requires “-XMF” thermostats. ZX-AOS: remote occupancy sensor Remote occupancy sensor for multi-room application. Also used for entry occupation status for quicker feedback for lighting (in leui of door lock integration).

  • Page 21: Best Practices And General Notes

    BEST PRACTICES & GENERAL NOTES Best practices and general notes Location • Do not install on an exterior wall. • Do not install behind a door. • Do not install in areas with a direct heat source or sunlight. • Do not install near any air discharge grill. •...

  • Page 22: General Specifications

    GENERAL SPECIFICATIONS General specifications Interface • The simplified VX4 user interface provides ease-of-use for the occupant. The interface includes five physical buttons: cycles through system modes (COOL, HEAT, OFF, AUTO) changes temperature display between farenheit and celsius and/or enables or disables scheduler. cycles through available fan speeds and modes (high, medium, low, auto, continuous).
  • Page 23 GENERAL SPECIFICATIONS Energy management routines, definitions, and settings Routines and definitions • Automatic temperature changeover (system mode): thermostat automatically activates heating or cooling to maintain the desired room temperature. • Automatic fan control mode: fan runs only when there is an active demand for heating or cooling. •...
  • Page 24 GENERAL SPECIFICATIONS Settings cont... • Temperature setback delay: operator can set the length of time for which the room that is in the occupied mode needs to be unoccupied before setback mode is initiated. • Incidental occupancy threshold: operator can set the minimum period of time (in minutes) for which occupancy needs to be detected in order to enter the “guest occupancy”...

  • Page 25: Verdant Accessories 25-Xx

    VX4-TR-XXX Thermostat Specs Mechanical Electicial 5.60” x 3.46” x 0.91” Operating Voltage Operating Range 12-27 VAC/VDC Case dimensions (142mm x 88mm x 23mm) Screen dimensions 2.60” x 1.65” (66mm x 42mm) Communications Operating temperature 32-105°F (0 - 41°C) Wireless Frequency 902-928MHz (NA) 863-870MHz (EU) Display temperature range 32-99°F (0-41°C)
  • Page 26 VX4-TW-XXX Thermostat Specs Wireless Control Card Specs Mechanical Mechanical 5.60” x 3.46” x 0.91” 4.08” x 2.76” x 1.02” Case dimensions Case dimensions (142mm x 88mm x 23mm) (123mm x 70mm x 26mm) (3) Analog Screen dimensions 2.60” x 1.65” (66mm x 42mm) Inputs 12VDC Operating temperature...
  • Page 27 VX4-NTR-XXX Thermostat Specs Mechanical Electicial 2 x 1.5VDC AA Alkaline Non- 5.60” x 3.46” x 0.91” Case dimensions Operating Voltage rechargeable Batteries - Field Supplied (142mm x 88mm x 23mm) 24VAC or 12VDC Screen dimensions 2.60” x 1.65” (66mm x 42mm) Communications Operating temperature 32-105°F (0 - 41°C)
  • Page 28 VX4-NTW-XXX Thermostat Specs Wireless Control Card Specs Mechanical Mechanical 5.60” x 3.46” x 0.91” 4.08” x 2.76” x 1.02” Case dimensions Case dimensions (142mm x 88mm x 23mm) (123mm x 70mm x 26mm) (3) Analog Screen dimensions 2.60” x 1.65” (66mm x 42mm) Inputs 12VDC Operating temperature...
  • Page 29 VX4-TVF-XXX Thermostat Specs Mechanical Electicial 5.60” x 3.46” x 0.91” Operating Voltage Operating Range 12-27 VAC/VDC Case dimensions (142mm x 88mm x 23mm) Screen dimensions 2.60” x 1.65” (66mm x 42mm) Communications Operating temperature 32-105°F (0 - 41°C) Wireless Frequency 902-928MHz (NA) 863-870MHz (EU) Display temperature range 32-99°F (0-41°C)
  • Page 30 VX4-NTVF-XXX Thermostat Specs Mechanical Electicial 5.60” x 3.46” x 0.91” 2 x 1.5VDC AA Alkaline Non- Case dimensions (142mm x 88mm x 23mm) Operating Voltage rechargeable Batteries - Field Supplied 24VAC or 12VDC Screen dimensions 2.60” x 1.65” (66mm x 42mm) Communications Operating temperature 32-105°F (0 - 41°C)

  • Page 31: Warranty

    WARRANTY Warranty Refer to www.verdant.copeland.com/verdant-warranty. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
