xStack DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual

Installation

Package Contents

Before You Connect to the Network

Installing the Switch without the Rack
Installing the Switch in a Rack
Mounting the Switch in a Standard 19" Rack
Power On (AC Power)
Power Failure (AC Power)
Connecting DC Power to the DES-3528DC
Package Contents
Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following
items:
®
One xStack stand-alone switch
One AC power cord*
Registration card
Mounting kit (two brackets and screws)
Four rubber feet with adhesive backing
RS-232 console cable
If any item is found missing or damaged, please contact your local D-Link Reseller for replacement.
*
Please Note the DES-3528DC Switch does not require an AC power cord therefore none is provided.
Before You Connect to the Network
The site where you install the Switch may greatly affect its performance. Please follow these guidelines for setting up
the Switch.
•
Install the Switch on a sturdy, level surface that can support at least 6.6 lbs (3 kg) of weight for DES-
3528/DES-3528DC, at least 13.2 lbs (6 kg) of weight for DES-3552/DES-3528P, at least 15.4 lbs (7 kg) of
weight for DES-3552P. Do not place heavy objects on the Switch.
•
The power outlet should be within 1.82 meters (6 feet) of the Switch.
•
Visually inspect the power cord and see that it is fully secured to the AC power port.
•
Make sure that there is proper heat dissipation from and adequate ventilation around the Switch. Leave at
least 10 cm (4 inches) of space at the front and rear of the Switch for ventilation.
•
Install the Switch in a fairly cool and dry place for the acceptable temperature and humidity operating ranges.
•
Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration, dust,
and direct exposure to sunlight.
•
When installing the Switch on a level surface, attach the rubber feet to the bottom of the device. The rubber
feet cushions help protect the casing from scratches and prevent it from scratching other surfaces.
Section 2
12
