Fully Integrated Dishwasher
IMPORTANT NOTE:
Thank you for selecting a TECO quality Dishwasher.
Please read this manual carefully before installing or
operating your new appliance. Make sure to save this manual
for future reference.
The design and specifications are subject to change without
prior notice for product improvement.
MODEL:
TDW14FIAM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDW14FIAM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TECO TDW14FIAM

Summary of Contents for TECO TDW14FIAM

  • Page 1 Fully Integrated Dishwasher MODEL: TDW14FIAM IMPORTANT NOTE: Thank you for selecting a TECO quality Dishwasher. Please read this manual carefully before installing or operating your new appliance. Make sure to save this manual for future reference. The design and specifications are subject to change without...
  • Page 2 CONTENTS PAGE SAFETY INFORMATION QUICK USER GUIDE PRODUCT OVERVIEW USING YOUR DISHWASHER Preparing and loading dishes Function of the rinse aid and detergent Filling the rinse aid reservoir Filling the detergent dispenser Basket using tips PROGRAMMING THE DISHWASHER Starting a cycle wash Changing the program mid-cycle Forget to add a dish? MAINTENANCE AND CLEANING...

  • Page 3: Safety Information

    SAFETY INFORMATION WARNING When using your dishwasher, follow the precautions listed below: Installation and repair can only be carried out by a qualified technician. This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments;...

  • Page 4: Earthing Instructions

    Earthing Instructions This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of an electric shock by providing a path of least resistance of electric current. This appliance is equipped with an earthing conductor plug. The plug must be plugged into an appropriate outlet that i s i nstalled a nd earthed i n a ccordance with all local codes and ordinances.
  • Page 5 When loading items to be washed: 1) Locate sharp items so that they are not likely to damage the door seal; 2) Warning: Knives and other utensils with sharp points must be loaded in the basket with their points facing down or placed in a horizontal position.
  • Page 6 If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. During installation, the power supply must not be excessively or dangerously bent or flattened. Do not tamper with controls.
  • Page 7 Disposal For disposing of package and the appliance please go to a recycling centre. Therefore cut off the power supply cable and make the door closing device unusable. Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling.
  • Page 8 QUICK USER GUIDE Please read the corresponding content on the instruction manual for detailed operating method. Install the dishwasher (Please check page 27 “INSTALLATION INSTRUCTIONS ”). Inside Outside Loading the baskets Removing the larger residue on the cutlery Filling the dispenser Selecting a program and running the dishwasher...

  • Page 9: Product Overview

    PRODUCT OVERVIEW IMPORTANT: To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Inner pipe Lower spray arm Filter assembly Dispenser Cutlery rack Upper spray arm Cup rack Cutlery basket Upper basket Lower basket NOTE: Pictures are only for reference, different models may be different.

  • Page 10: Using Your Dishwasher

    USING YOUR DISHWASHER Control Panel Operation (Button) Press this button to turn on your dishwasher, the screen lights up. Power When you have about or less than 6 place setting dishware to wash, you can choose this function to save energy and water. (It Half-load can only be used with Intensive, Heavy, ECO, Glass and 90 min.) To dry dishes more completely.
  • Page 11 Heavy For heavily soiled loads, such as pots, plates, glasses and lightly soiled pans. For normally soiled loads, such as pots, plates, glasses Program and lightly soiled pans, standard daily cycle. indicator Glass For lightly soiled crockery and glass. 90 Min For lightly soiled plates and pans that need quick wash.

  • Page 12: Preparing And Loading Dishes

    Preparing And Loading Dishes Consider buying utensils which are identified as dishwasher-proof. For particular items, select a program with the lowest possible temperature. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended. For washing the following cutlery/dishes Are not suitable Cutlery with wooden, horn china or mother-of-pearl handles...

  • Page 13: Removing The Dishes

    Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that water cannot collect in the container or a deep base. Dishes and items of cutlery must not lie inside one another, or cover each other. To avoid damage, glasses should not touch one another.

  • Page 14: Loading The Upper Basket

    Loading the upper basket The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty). Position the dishes and cookware so that they will not get moved by the spray of water.

  • Page 15: Function Of The Rinse Aid And Detergent

    Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids. WARNING Only use branded rinse aid for dishwasher.

  • Page 16: Filling The Rinse Aid Reservoir

    Filling The Rinse Aid Reservoir Rinse-Aid indicator Remove the rinse aid reservoir cap Pour the rinse aid into the dispenser, by rotating it counterclockwise. being careful not to overfill. NOTE: Clean up any spilled rinse aid with an absorbent cloth to avoid excessive foaming during the next wash.

  • Page 17: Filling The Detergent Dispenser

    Filling The Detergent Dispenser Open the detergent dispenser flap by pushing the detergent dispenser release catch. Add detergent into the larger cavity (A) A) for the main wash cycle. For better cleaning result, especially if you have very dirt items, pour a small amount of detergent onto the door.

  • Page 18: Basket Used Tips

    Basket Used Tips Adjusting the upper basket The height of t he upper basket can be easily adjusted to accommodate taller dishes in either the upper or lower basket. To adjust t he height of t he upper rack, follow t hese steps: lower position Remove the upper basket.

  • Page 19: Folding Back The Cup Shelves

    Folding back the cup shelves To make room for taller items in the upper basket, raise the cup rack upwards. You can then lean the tall glasses against it. You can also remove it when it is not required for use. Folding back the rack shelves The spikes of the lower basket are used for holding plates and a platter.

  • Page 20: Programming The Dishwasher

    PROGRAMMING THE DISHWASHER Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. )Means: need to fill rinse into the Rinse-Aid Dispenser. Description Running Energy...

  • Page 21: Starting A Cycle Wash

    NOTE: AS/NZS 2007.1 This program is the test cycle. The information for comparability test in accordance with AS/NZS 2007.1. Starting A Cycle Wash 1. Draw out the lower and upper basket, load the dishes and push them back. It is commended to load the lower basket first, then the upper one. 2.

  • Page 22: Forget To Add A Dish

    Forget To Add A Dish? A forgotten dish can be added any time before the detergent dispenser opens. If this is the case, follow the instructions below: 1. Open the door a little to stop the washing. 2. After the spray arms stop working, you can open the door completely. 3.

  • Page 23: Maintenance And Cleaning

    MAINTENANCE AND CLEANING External Care The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door.These surfaces are outside the wash cabinet and are not accessed by water from the spray arms.
  • Page 24 Coarse filter Coarse filter Main filter Main filter Fine filter Open Open Hold the coarse filter and rotate it The fine filter can be pulled off the anticlockwise to unlock the filter. bottom of the filter assembly. Lift the filter upwards and out of The coarse filter can be detached the dishwasher.

  • Page 25: Spray Arms

    Spray arms It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arms, follow the instructions below: To remove the upper spray arm, To remove the lower spray arm, pull hold the nut in the center still and out the spray arm upward.

  • Page 26: Caring For The Dishwasher

    Caring For The Dishwasher Frost precaution Please take frost protection measures on the dishwasher in winter. After every wash, please operate as follows: 1. Cut off the electrical power to the dishwasher at the supply source. 2. Turn off the water supply and disconnect the water inlet pipe from the water valve. 3.

  • Page 27: Installation Instruction

    INSTALLATION INSTRUCTION WARNING Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. Attention The installation of the pipes and electrical equipments should be done by professionals. About Power Connection WARNING For personal safety: Do not use an extension cord or an adapter...

  • Page 28: Water Supply And Drain

    Water Supply And Drain Cold water connection Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear.

  • Page 29: Built-In Installation

    How to drain excess water from hoses If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink.

  • Page 30: Step 2. Levelling The Dishwasher

    2. If dishwasher is installed at the corner of the cabinet, there should be some space when the door is opened. Dishwasher Cabinet NOTE: Door of dishwasher Depending on where your electrical outlet is, you may need to cut a hole in the opposite Minimum space cabinet side.

  • Page 31: Step 3. Aesthetic Panel's Dimensions And Installation

    Step 3. Aesthetic panel's dimensions and installation The aesthetic wooden panel could be installed according to the installation drawings. model Full-integrated Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of dishwasher (see figure A). After positioning of the panel, fix the panel onto the outer door by screws and bolts (See figure B).

  • Page 32: Step 5. Dishwasher Installation Steps

    Step 5. Dishwasher installation steps Please refer to the specified installation steps in the installation Please refer to the specified installation steps in the installation drawings. drawings. 1. Affix the condensation strip under the work surface of cabinet. Please ensure the condensation strip is flush with edge of work surface.

  • Page 33: Troubleshooting Tips

    TROUBLESHOOTING TIPS Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. start circuit break tripped. Remove any other appliances sharing the same circuit with the dishwasher.
  • Page 34 Problem Possible Causes What To Do Spilled rinse-aid. Always wipe up rinse-aid spills immediately. Stained tub interior Detergent with Make sure that the detergent has no colourant may colourant. have been used. White film on Hard water minerals. To clean the interior, use a damp inside surface sponge with dishwasher detergent and wear rubber gloves.
  • Page 35 Problem Possible Causes What To Do The filter combination Clean and/or fit the filter correctly. The dishes is not clean or is not Clean the spray arm jets. are not clean. correctly fitted in the base of wash cabinet. This may cause the spray arm jets to get blocked.

  • Page 36: Technical Information

    TECHNICAL INFORMATION Height (H) 815mm 598mm Width (W) Depth (D1) 550mm (with the door closed) Depth (D2) 1150mm (with the door opened 90°)

  • Page 37: Loading The Baskets

    LOADING THE BASKETS ACCORDING TO AS/NZS 2007.1: 1.Upper basket: Number Item Cups Saucers Glasses Dessert dishes Rack Forks knives NOTE: Please place the light flat wares on the rack. The total weight is less than 1.5kg. Item Number Dinner plates Soup plates Cutlery besket...

  • Page 38: Cutlery Basket

    3.Cutlery basket: Number Item Soup spoons Forks Knives 4 4 4 Teaspoons Dessert spoons Information for comparability tests in accordance with (*AS/NZS 2007.1 ) Capacity: 14 place settings Position of the upper basket: lower position Program: ECO Rinse aid setting: 6 Detergent(Pre/main): 5g/27.5g Door is open at the end of the drying cycle for the drying performance test (Door position: Open 50 mm)

  • Page 39: Specification

    SPECIFICATION TECO Manufacturer TDW14FIAM Type / Description Standard place settings Energy efficiency class Water consumption class Standard cleaning cycle Energy consumption of the standard cleaning cycle 0.8 kWh Water consumption of the standard cleaning cycle 12.5 liter Program duration of the standard cleaning cycle...
  • Page 40 If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST) For warranty details please visit www.teco.com.au Service Email : had.service@teco.com.au...
  • Page 41 Did you know? TECO Australia’s product range also includes: Top Load Clothes Washers Front Load Clothes Washers Twin Tub Clothes Washers Auto Sensing Vented Clothes Dryers Refrigerators Chest and Vertical Freezers Bar Fridges Televisions Air Curtains and Air Conditioners Visit www.teco.com.au for our full range.

  • Page 42: Warranty Information

    Teco's warranty information for the product purchased is available at www.teco.com.au. A copy of the warranty may also be obtained by contacting Teco's Warranty and Service Department on 1300 660 037 during business hours (Mon - Fri 8.30am - 4pm AEST).
