TDW15WCG/ TDW15SCG
15 place settings
Alt function

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDW15WCG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TECO TDW15WCG

Summary of Contents for TECO TDW15WCG

  • Page 1 TDW15WCG/ TDW15SCG 15 place settings Alt function...
  • Page 2 For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Open the door, p ress the On/Off button to switch on the appliance. Compartment A: For each wash cycle. Compartment B: Fill the detergent dispenser For programs with pre-wash only.

  • Page 3: Table Of Contents

    Dear Customer, Control Panel...........2 This appliance is intended to be used in household Dishwasher Features........2 and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential A.
  • Page 4 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of an electric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.

  • Page 5: Control Panel

    To get the best performance from your dishwasher, read all operating instructions before using it for the first time. 9 11 13 Dry+ 1 Power switch: To turn on/off the power supply. 9 Dry+ indicator: An increased temperature during the final rinse 2 Delay button: The START DELAY will allow you to delay the stage will improve the drying process The indicator will be start time of any cycle automatically up to 24hours.

  • Page 6: Rinse Aid Dispenser

    Before using your dishwasher for the first time: Rinse aid dispenser Detergent Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.

  • Page 7: Adjusting Rinse Aid Dispenser

    Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser set on "4". If spots and poor drying are a problem, increase the amount of rinse aid dispensed by removing the dispenser lid and rotating the dial to "5". If the dishes still are not drying properly or are showing spots, adjust the dial to the next higher level until your dishes are spot-free.

  • Page 8: Amount Of Detergent To Use

    Amount of Detergent to Use If the lid is closed: press release button. The lid will spring open. Always add the detergent just before starting each wash cycle. Only use branded detergent and rinse aid for dishwasher. Dishwasher detergent is corrosive! Take care to keep it out of reach of children. Proper Use of Detergent Use only detergent specifically made for the use in dishwashers.

  • Page 9: Attention Before Or After Loading The Dishwasher Baskets

    5 Loading the Dishwasher Baskets Loading the baskets according to (*AS/NZS 2007.1) for best performance of the dishwasher, Features and appearance of baskets and Cutlery tray may vary from your model. Attention before or after Loading the Dishwasher Baskets 1. Scrape off any large amounts of leftover food. It is not necessary to rinse the dishes under running water.
  • Page 10 Upper position Lower position Loading the Lower Basket We recommend that you place large items which are most difficult to clean in to the lower basket: pots, pans, lids, serving dishes and bowls, as shown in the figure below. It is preferable to place serving dishes and lids on the side of the baskets in order to avoid blocking the rotation of the top spray arm.
  • Page 11 Cutlery tray Arrange the cutlery in the tray as shown. Cutlery should be placed to ensure that water runs off freely. Cutlery tray Type Item Tea spoons Dessert spoons Soup spoons Forks Knives For washing in the dishwasher the following cutlery/dishes Are not suitable WARNING! Cutlery with wooden, horn china or...

  • Page 12: Loading Cutlery And Dishes

    NOTE: Please do not overload your dishwasher. There is only space for 15 standard dishes. Do not use dish that is not suitable for dishwashers. This is important for good results and for reasonable energy consumption. Loading Cutlery and Dishes Before loading the dishes, you should: Remove large left-over Soften remnants of burnt food in pans...

  • Page 13: Wash Cycle Table

    6. Starting a Washing Programme Wash cycle table Running Description Energy Water Cycle Selection Detergent Program Time of Cycle (kWh) Information Pre/main (min) Pre-wash(40 ) For the heaviest soiled loads, Main wash(55 ) such as pots, pans, casserole Rinse 1 5/29g 1.35 16.0...

  • Page 14: Change The Programme

    NOTE: A click could be heard when the door is closed perfectly. When the washing is over, you can shut off the switch by pressing "Power" button. Change the Programme. Premise: A cycle that is underway can only be modified if it has only been running for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water.

  • Page 15: At The End Of The Wash Cycle

    When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher. Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they are still hot and more susceptible to breakage.

  • Page 16: Filtering System

    The filter prevents larger remnants of food or other objects from getting inside the pump. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). Main filter Food and soil particles trapped in this filter are pulverized by a special jet on the lower spray arm and washed down to drain.

  • Page 17: Caring For The Dishwasher

    Remarks: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water. The entire filter assembly should be cleaned once a week. Cleaning the Filter To clean the coarse filter and the fine filter, use a cleaning brush.

  • Page 18: Positioning The Appliance

    After Every Wash When not in Use for a Long Time It is recommend that you run a wash cycle with the After every wash, turn off the water supply to the dishwasher empty and then remove the plug from the appliance and leave the door slightly open so that socket, turn off the water supply and leave the door of moisture and odours are not trapped inside.

  • Page 19: Aqua Stop Hose / Water Connection

    Improper connection of the equipment earthing conductor can result in the risk of an for personal safety: electric shock. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE. Check with a qualified electrician or service representative if you are in doubt whether the DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING appliance is properly earthed.

  • Page 20: Start Of Dishwasher

    How to Drain Excess Water From Hoses If the sink is 1000mm higher from the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink.

  • Page 21: Before Calling For Service

    Fuse blown, or the home Replace fuse or reset circuit breaker. Remove any other circuit breaker has been appliances sharing the same circuit with the dishwasher triggered. Make sure the dishwasher is turned on and the door is Power supply is not closed securely.
  • Page 22 The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.

  • Page 23: Error Codes

    When some malfunctions happen, the appliance will display error codes to warn you. Meanings Codes Possible Causes The door is opened when the Door open dishwasher is operating Water inlet Water inlet malfunction Water drainage Water drainage malfunction Temperature sensor Temperature sensor malfunction Overflow/leakage Overflow occurs/Water leakage occurs...
  • Page 24 Did you know? TECO Australia’s product range also includes:  Top Load Clothes Washers  Front Load Clothes Washers  Twin Tub Clothes Washers  Auto Sensing Condenser and Vented Clothes Dryers  Refrigerators  Chest and Vertical Freezers  Bar Fridges ...
  • Page 25 If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia Service Department on 1300 660 037 (9am to 4pm AEST Mon to Fri) Email: had.service@teco.com.au For warranty details please visit www.teco.com.au Complete and retain the following information:...
