cias MICRO-RAY100-1M-1 Installation Manual

Multi rays microwave barrier
Hide thumbs Also See for MICRO-RAY100-1M-1:
Table of Contents

Advertisement

Quick Links

Download this manual
MICRORAY
Multi Rays Microwave Barrier
Installation Manual
Edition 2.5
20MACIE0538

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MICRO-RAY100-1M-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for cias MICRO-RAY100-1M-1

Summary of Contents for cias MICRO-RAY100-1M-1

  • Page 1 MICRORAY Multi Rays Microwave Barrier Installation Manual Edition 2.5 20MACIE0538...

  • Page 2: Table Of Contents

    © CIAS Elettronica S.r.l. Ed. 2.5 INDEX DESCRIPTION ................................3 ................................. 3 ESCRIPTION INSTALLATION ................................4 TOWER BASE ........................4 OLUMN ASSEMBLY ON THE ...................5 ASE TEMPLATE OF THE COLUMN AND COLUMN FOOTPRINT ..............................5 OLUMN COMPOSITION ..............................7 OLUMN DIMENSIONS ............................

  • Page 3: Description

    © CIAS Elettronica S.r.l. Ed. 2.5 1 DESCRIPTION Description The innovative MICRO-RAY is a multi-ray microwave barrier (1, 2, 3 or 4 rays) for external perimeter protections up to 100m. The microwave rays have a diameter of about 40/50 cm similar to an infrared barrier but with all the following advantages: ➢...

  • Page 4: Installation

    © CIAS Elettronica S.r.l. Ed. 2.5 2 INSTALLATION Column assembly on the TOWER BASE Once the column cover is open (removing the top cover, after unscrewed the two closing screws), align the lower part with the plug of the TOWER-BASE steel base that will be fixed to the ground (see Fig.

  • Page 5: Base Template Of The Column And Column Footprint

    © CIAS Elettronica S.r.l. Ed. 2.5 Base template of the column and column footprint Figure 6 File eventually available in 1:1 scale Column composition All microwave rays are assembled in the factory at preset heights (based on the model chosen), but then they can be moved according to the needs of the field.
  • Page 6 © CIAS Elettronica S.r.l. Ed. 2.5 Column “A” Column “B” R4-B (TX) 4 R4-A (RX) R3-A (RX) R3-B (TX) 3 R2-B (RX) 2 2 R2-A (TX) 1 R1-A (TX) R1-B (RX) 1 Figure 7 Page 6 of 31 Installation Manual...

  • Page 7: Column Dimensions

    © CIAS Elettronica S.r.l. Ed. 2.5 Column dimensions The columns are available in 3 heights: • 1m • 2m • 3m Their diameter is 180mm Ray orientation/rotation The angle of rotation of each individual ray is about + 11° horizontally and + 11° vertically.
  • Page 8 © CIAS Elettronica S.r.l. Ed. 2.5 Figure 8b Note: Do not place the columns at a distance less than 50cm from the fence or 35cm from the wall. (These distances are referred from the center of antenna). Warning: With PARALLEL installation (fig. 8a), in some exceptional cases (normally...

  • Page 9: Connections

    © CIAS Elettronica S.r.l. Ed. 2.5 Corners The positioning in the corners is carried out side by side by placing the type A or type B columns as shown in figure 10. Figure 10 3 CONNECTIONS Terminal blocks, Connectors and Functionality of the TX circuit...

  • Page 10: Function Selector

    © CIAS Elettronica S.r.l. Ed. 2.5 TERMINAL BLOCK MS2 – local connections to PC / SW Term. Symbol Function Block 13.8V Positive Power supply Input (+13.8 V ) Negative Input for Power Supply and for Data (0 V ) + RS-485 High Data Line - RS-485 Low Data Line J1 TRANSMITTER CONNECTOR –...

  • Page 11: Erminal Blocks Onnectors And Unctionality Of The Rx Circuit

    © CIAS Elettronica S.r.l. Ed. 2.5 Terminal blocks, Connectors and Functionality of the RX circuit Figure 12 Topographic arrangement of the components in the circuit with and without cover TERMINAL BLOCK MS1 Symbol Function Term.Block Alarm Relay Contact (C) Alarm Relay Contact (NC)
  • Page 12 © CIAS Elettronica S.r.l. Ed. 2.5 JUMPERS Symbol Function Default Serial Line Termination (Jp1 position 1/2 = -- (*) termination NOT inserted) LEDS Symbol Function Default Indication of Alarm Indication of Tampering Indication of Fault Alignment and Adjustment Functions Alignment and Adjustment Functions...

  • Page 13: Terminal Blocks, Of The Micro-Ray Interface Circuit

    © CIAS Elettronica S.r.l. Ed. 2.5 Terminal blocks, of the MICRO-RAY Interface circuit The MICRO-RAY modules are all pre-wired in the factory and connected to the relative KIMR1, KIMR2, KIMR3, KIMR4 terminal of the interface circuit (positioned approximately in the middle of the column), by shielded FLAT cable.

  • Page 14: Power Supply

    © CIAS Elettronica S.r.l. Ed. 2.5 TERMINAL BLOCK MS4 Term. Symbol Function Block Power Presence (column internal connection) SHLD Cable screen (*) SHLD Cable screen (*) TERMINAL BLOCK J1, J2, J3, J4 – MICRORAY INTERNAL CONNECTION Term. Block Function KIMR1...

  • Page 15: Power Supply With Optional Ip-Doorway Kits

    IP-DOORWAY. It is a RS-485 - Ethernet line converter expressly designed to be inserted, in addition to the MICRO-RAY product, also on all CIAS digital devices. It is available in the Standard PoE version (PoE 802.3 af - code IP-DOORWAY-S), able to be powered by a Standard PoE SWITCH, and in the version 13.8 V (code IP-DOORWAY-C), able...

  • Page 16: Connection To The Central Control Panel

    © CIAS Elettronica S.r.l. Ed. 2.5 Connection to the central control panel The connections to the central control panel must be made using shielded cables, twisted and low-capacity cable (<70 pF/m) e.g. "Belden 9842". Output contacts: Alarm, Fault, Tamper For the TX, the outputs of the devices consist of two normally closed potential-free relay contacts, while for RX they are three.

  • Page 17: Connections For Rs-485 Serial Line

    © CIAS Elettronica S.r.l. Ed. 2.5 Connections for RS-485 serial line The serial connection between the various columns must be made using a shielded. The network architecture must be of the "BUS" type, with a maximum bus length of 1200 m. If it is necessary to use a star architecture, or the maximum length of the bus is greater than 1200 m, one or more line-repeaters model "BUSREP"...

  • Page 18: Operations On Rx Rays

    © CIAS Elettronica S.r.l. Ed. 2.5 4.1.1.2 Read/Write Channel (Optional) Only in case of disturbance or difficult in the alignment, change the automatic assignment of the channel number, due to the barrier number settings, by rotate the function switch SW1 to position 1 it is possible to read and/or set one of the 8 modulation channels available.
  • Page 19 © CIAS Elettronica S.r.l. Ed. 2.5 f) If during orientation, the intermittent sound frequency increases, it means that the received signal has increased compared to the previous situation. Press the S3 button and when the intermittent sound frequency returns to the 1 Hz frequency (due to the signal recovery), proceed with the next antenna orientation operations.

  • Page 20: Installation Examples

    © CIAS Elettronica S.r.l. Ed. 2.5 If the quality of the alignment is poor (or worse) repeat the entire alignment procedure, making sure that there are no obstacles or disturbances in the protection field in alignment condition adjust the height of the RX to get the best signal received (if necessary, check the height of the Tx).

  • Page 21: Application Type

    © CIAS Elettronica S.r.l. Ed. 2.5 Installation example C Barrier in narrow corridors (between 1m and 2m) bordered on both sides by fixed obstacles (fence, wall, building, car, etc) Installation example D Open spaces with the possibility to run through from inside or outside...
  • Page 22 © CIAS Elettronica S.r.l. Ed. 2.5 All the rays can be set with all 6 applications. The most suitable one with respect to the ray position is recommended below: Setting Recommended Application Type Number for the Ray Anti-crawling Basic Anti-crawling Advanced Corridors delimited on one side only 2;...

  • Page 23: Factory Default

    © CIAS Elettronica S.r.l. Ed. 2.5 Number Time (ms) 1000 ➢ FACTORY DEFAULT The factory settings assigned to each ray are shown in the table below: Application Vegetation Interruption Type Application Type description Filter Times number Birds Presence 1 = ENABLED...
  • Page 24 © CIAS Elettronica S.r.l. Ed. 2.5 4.1.2.3 Read/Write Masking threshold Carrying the function switch SW1 to position 6, it is possible to read and/or set masking. Select Masking: • Select a number from 00 to 02 on the appropriate switches SW2 (tens) and SW3 •...

  • Page 25: Maintenance & Assistance

    © CIAS Elettronica S.r.l. Ed. 2.5 5 MAINTENANCE & ASSISTANCE Ray Replacement MICRO-RAY-RTV13-KIM and MICRO-RAY-RRV13-KIM codes shall be used to replace ray 1 (Default) or ray 3, respectively on column A and B (see table with RAY REPLACEMENT CODES at page 29).

  • Page 26: Troubleshooting

    © CIAS Elettronica S.r.l. Ed. 2.5 Troubleshooting In case of false alarms, check the parameters found during the Installation and if any variations exceed the indicated limits, review the relative points in the chapter 4 "Setting of the Rays". Defect...

  • Page 27: Features

    +65 °C Performance level 4° Degree of enclosure protection IP55 Antenna Manufacturer / Name / Part Number CIAS Elettronica – Microray frnd Tx - 20FEFTC0047 Antenna Frequency / Peak Gain 24.125GHz – 29dBi Antenna Type Rectangular Microstrip Patch Antenna TOWER HT1-MR...
  • Page 28 MEMORANDUM FOR SETTINGS: Name of the System: Address: TYPE OF APPLICATION VEGETATION FILTER INTERRUPTION TIME RAY 4 RAY 3 BARRIER 1 RAY 2 RAY 1 RAY 4 RAY 3 BARRIER 2 RAY 2 RAY 1 RAY 4 RAY 3 BARRIER 3 RAY 2 RAY 1 RAY 4...
  • Page 29 NOTES:...
  • Page 30 NOTES:...
  • Page 31 NOTES:...
  • Page 32 (if applicable). NOTICE: Changes or modifications made to this equipment not expressly approved by CIAS Elettronica may void the FCC authorization to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This manual is also suitable for:

Micro-ray100-1m-2Micro-ray100-2m-2Micro-ray100-2m-3Micro-ray100-2m-4Micro-ray100-3m-3Micro-ray100-3m-4
