O P E R A T I N G

M A N U A L

E M B E D D I N G C E N T E R S

M P S P I / M P S P I I

M P S P , W , C / C X

COMPACT AND MODULAR

PARAFFIN EMBEDDING CENTER,

DISPENSING MODULE,

PRE-WARMING MODULE,

COOLING MODULE

DE S I GN &

M A N UFACT UR I N G

M A DE I N GE R M A N Y

Table of Contents

Need help?

Do you have a question about the MPS P I and is the answer not in the manual?

Questions and answers

Summary of Contents for Slee MPS P I

Page 1 O P E R A T I N G M A N U A L E M B E D D I N G C E N T E R S M P S P I / M P S P I I M P S P , W , C / C X COMPACT AND MODULAR PARAFFIN EMBEDDING CENTER,...
Page 2 Manual_MPS_2024-10-023.00_EN.docx...
Page 3 The information, numerical data and notes contained in this document represent the current state of scientific knowledge and state-of-the-art technol- ogy as we understand it following thorough investigation in this field. SLEE medical GmbH is under no obligation to update the present manual periodi- cally and on an ongoing basis according to the latest technical developments, nor to provide our customers with additional copies, updates etc.
Page 4 Manual_MPS_2024-10-023.00_EN.docx...
Page 5: Table Of Contents
PARAFFIN TRIMMER (MPS P and MPS P I module) 7.14 PARAFFIN COLLECTION TRAY (MPS P and MPS P I module) 7.15 HEATED FORCEPS (MPS P and MPS P I module) [if device is equipped with this accessory] 7.16 HEATED CASSETTE / MOULD STORAGE AREA (MPS W module) 7.17 COOLED STORAGE AREA (MPS C / CX module) 7.18...
Page 6 SERVICE ____________________________________________________________ 29 WARRANTY _________________________________________________________ 29 DISPOSAL __________________________________________________________ 29 Manual_MPS_2024-10-023.00_EN.docx...
Page 7: Intended Use
-5 °C). Optionally heated forceps for orientation of the specimen during embedding are available. MPS P I consists of a heated paraffin container (capacity 3.8 liters; 30 – 80 °C), a heated working area (450 x 240 mm; 30 – 80 °C), two heated cassette and mould storage containers (30 – 80 °C) for 120 cassettes and 250 embedding molds and a cooled working area.
Page 8: Safety Notes
3 SAFETY NOTES Slee paraffin wax embedding centers are provided with the following safety features: MPS P MPS P I Hand heat protectors • The institution which owns the unit and the persons working with the unit, servicing or repairing it have the responsibility for a hazard-free use.
Page 9: Components
4 COMPONENTS The Slee paraffin wax embedding centers are provided with the following standard components: MPS P I MPS P II MPS P MPS W MPS C / CX Heated paraffin (wax) container • • Heated dispenser element • •...
Page 10: Specifications
5 SPECIFICATIONS MPS P MPS P I MPS W MPS C MPS CX 115 V 230 V 115 V 230 V 115 V 230 V 115 V 230 V 115 V 230 V Nominal sup- 115 V 230 V 115 V...
Page 11 Cooling gas R 134 a R 134 a Work area 270 x 370 mm, 270 x 570 mm, 80 cassettes, 250 120 cassettes, moulds 375 moulds Cassette bath, approx. 120 cas- approx. 320 cas- storage for settes, approx. settes, approx. moulds 250 moulds 30 –...
Page 12: Unpacking And Installation
6 UNPACKING AND INSTALLATION UNPACKING THE DEVICE Remove the upper cover and the upper supporting foams. Lift the device out of the wooden transportation case. The devices may only be lifted holding them at the sides of the base plate of the housing. For repacking use the original cases.
Page 13: Initial Operation
W and the second one for the MPS P version as shown below. The functions of the buttons are explained later in the re- spective part of this chapter. HMI MPS C, MPS CX & MPS W HMI MPS P, MPS P I Manual_MPS_2024-10-023.00_EN.docx...
Page 14: Initial State Of The Display
Paraffin >> Fr07:00 Timer settings for surface Surface >> Fr09:00 Cooling Spot status Cooling Spot Standby display for MPS P I: Explanation Date / Function Time / Settings Actual date / time 17.09.10 20:45:00 Timer settings for paraffin tank Paraffin >>...
Page 15 Standby display for MPS W: Explanation Date / Function Time / Settings Actual date / time 17.09.10 20:45:00 Timer settings for upper heating Upper >> Fr07:00 Timer settings for lower heating Lower >> Fr09:00 Standby display for MPS C and MPS CX: Explanation Date / Function Time / Settings...
Page 16: Main Menu
7.4 MAIN MENU The table Main Menu provides the possible settings of the MPS P and MPS P I software. The columns Cursor, Function and Settings are a representation of the characters shown on the display. As the display only shows 4 lines you can navigate to the other positions listed in the following tables by pressing .
Page 17 Main Menu display for MPS P I: Explanation Cursor Function Settings Manual activation of Standby mode > Standby Manual activation of Operation mode Operation Timer MPS P I Timer Tank heating function On / Off Paraffin Adjustment of tank heating temperature Paraffin Temp.
Page 18 Switch to configuration menu (Configuration per SLEE Configuration medical GmbH authorized technician) With (for MPS P and MPS P I ) you can move the cursor (column Cursor) to the appropriate menu item (column Function). By pressing (for MPS P II ) you can activate the setting, and the value begins to flash.
Page 19: Actual Date And Time
The items marked with an asterisk (*) guide the user to the submenu Timer, which is explained in chapter 7.6 TIMER. To leave the menu and get into the next higher level just push . This will not make any changes to the device’s current settings.
Page 20: Timer
7.6 TIMER All devices of the MPS series and the cooling unit in the MPS C and MPS CX can be switched on and off via an automatic time switch. A total of three switch-on and switch-off phases can be defined. The respective time switch intervals can be set via the main menu.
Page 21: Heated Paraffin (Wax) Container (Mps P And Mps P I Module)
To assure a rapid flow, please refill the paraffin container before it empties completely. The design of the MPS P and MPS P I allows two ways of working with your device. The first common one is using the timer, which is explained in chapter 7.6 TIMER. This allows you to have a ready to use unit in the morning with liquid paraffin in it.
Page 22: Heated Working Area (Mps P And Mps P I Module)
As mentioned in chapter 7.7 HEATED PARAFFIN (WAX) CONTAINER you can heat the working surface of your MPS P or MPS P I to allow you to place and align your tissue sample while the paraffin keeps liquid. Even the temperature can be influenced in the Main Menu.
Page 23: Illuminated Working Area (Mps P And Mps P I Module)
(MPS P and MPS P I module) For optimized visibility of your work there is a light in- cluded in the MPS P and MPS P I device which you can switch on and off with . Additionally, you can adjust the light module in the front by turning the black tube as shown in the picture to the right.
Page 24: Magnifier (Mps P And Mps P I Module)
7.15 HEATED FORCEPS (MPS P and MPS P I module) [if device is equipped with this accessory] The device can also be equipped with electrically heated forceps. The forceps will be activated by plugging into the connection for heated forceps at the front of the paraffin wax dispenser (MPS P and MPS P I module).
Page 25: Heated Cassette / Mould Storage Area (Mps W Module)
7.16 HEATED CASSETTE / MOULD STORAGE AREA (MPS W module) The MPS W has two areas where you can store and preheat your steel and plastic cassettes. Usually, the upper area is for preheating the steel cassettes and the lower area is used for the plastic cassettes. Both areas can be regulated separately in the Main Menu by going down to the items Upper, upper Temp.
Page 26: Maintenance
Paraffin is flammable and therefore must be handled with care. Avoid spillage of liquid paraffin. All components of the Slee embedding center MPS P I and MPS P II that come into contact with paraffin and the interior of the devices are carefully sealed to prevent wax from entering. Nevertheless, if paraffin is spilled, it should always be re- moved carefully.
Page 27: Optional Accessories
9 OPTIONAL ACCESSORIES Description MPS P I MPS P II MPS C Heated Forceps • • #10196000 (2.5 mm) #10196001 (1.25 mm) Anatomic Forceps, 130 mm, stainless steel • • #30030090 (pointed) #30030091 (blunt) Heated Forceps straight • • #10196012 (0.5 mm)
Page 28 Base moulds (stainless steel) • • #30030050 7 mm x 7 mm x 7 mm #30030051 30 mm x 24 mm x 7 mm #30030052 15 mm x 15 mm x 7 mm #30030053 24 mm x 24 mm x 7 mm #30030054 37 mm x 24 mm x 7 mm #30030056...
Page 29: Warranty
If the device or parts thereof are sent back in a dirty or non-disinfected condition, SLEE medical GmbH reserves the right to return the parts to the debit of the customer without carrying out repairs or maintenance.
Page 30 Notes Manual_MPS_2024-10-023.00_EN.docx...
Page 31 Notes Manual_MPS_2024-10-023.00_EN.docx...
Page 32 SLEE medical GmbH • Am Neuberg 14 55268 Nieder-Olm • Germany www.slee.de T: +49 (0) 6136 76997-0 E: mail@slee.de www.slee.de YouTube LinkedIn Instagram Manual_MPS_2024-10-023.00_EN...
