- Page 1 DC50 MAX Precision Digital Dispenser Operating Manual info@fisnar.com www.fisnar.com...
-
Page 2: Table Of Contents
DC50 MAX Digital Dispenser Operating Manual Table of Contents Machine Overview Product Safety Statements Specifications Accessories External Controls Machine Setup Dispense Setup Dispense Modes Manual Mode • Timed Mode • External Machine Actuation Spare Parts List Technical Drawing © 2023 Fisnar... -
Page 3: Machine Overview
OVERVIEW Model DC50 MAX Digital Dispenser The DC50 MAX is a reliable and easy to use precision digital dispenser with a bright 4-digit timer control display and digital pressure gauge for precise & repeatable dispensing. The simple user-friendly programming enables a dispense cycle to be quickly created and automatically displayed. -
Page 4: General Precautions
DC50 MAX Digital Dispenser Operating Manual SAFETY General Precautions Do not operate the machine in excess of its maximum ratings / settings. Make sure that the input air supply is clean and dry. A 5 micron air filter/regulator (560567) is recommended to ensure the input air supply is clean and dry. -
Page 5: Inappropriate Use
Immediately disconnect power if any sparking or smoke appears. Do not expose the machine directly to sunlight. Maintenance The DC50 MAX is generally a maintenance free machine. However, to ensure smooth operation please follow the below instructions. Only use non-woven cleaners on the machine. -
Page 6: Specifications
DC50 MAX Digital Dispenser Operating Manual SPECIFICATIONS Dimensions (W x D x H): 7.56” x 5.04” x 3.00” (192 x 128 x 76 mm) Weight: 2.14 lbs (0.97 kg) Input AC to Power 100 – 240 VAC, 50 / 60 Hz... -
Page 7: External Controls
DC50 MAX Digital Dispenser Operating Manual EXTERNAL CONTROLS FRONT REAR FIG. 1: External Controls - Overview Item Illustration Item Illustration Item Illustration Vacuum Control Scroll Buttons Air In Port Exhaust Port Air Out Port Air Pressure Regulator Air Pressure Gauge... - Page 8 DC50 MAX Digital Dispenser Operating Manual EXTERNAL CONTROLS FIG. 2: External Controls – Front Keeps a negative air pressure in the syringe barrel when not Suck Back dispensing. Required to prevent low viscosity fluids dripping from the Control dispense tip in between dispense cycles.
- Page 9 FIG. 3: External Controls - Back The foot pedal switch is connected here. Or it can be used for Foot Switch connecting to an external device (e.g. Fisnar dispense robot) that will Connector send the dispense start signal to the machine.
- Page 10 DC50 MAX Digital Dispenser Operating Manual EXTERNAL CONTROLS FIG. 4: Control Buttons Press the button to switch between the two different dispense modes Switch Modes (MANUAL or TIMED). A green LED light will light up next to the text “MANUAL”...
-
Page 11: Machine Setup
The DC50 MAX is not able to be remotely calibrated in the field. As such, it has been designed to achieve a pressure accuracy of +/- 5 psi / 0.35bar, which accounts for this small variation in atmospheric and environmental condition, in addition to the performance specification of the pressure regulator. -
Page 12: Dispense Setup
Connect the syringe barrel adapter head assembly to the “Air Out” port on the front of the machine. (4) See FIG. 5. Fisnar adapter head assemblies are fitted with a green colored push to connect fitting (5606038) that can be inserted directly into the “Air Out” port on the front of the machine. - Page 13 DC50 MAX Digital Dispenser Operating Manual When not being used, the syringe barrel should be placed in the syringe barrel stand provided, to prevent the dispense tip from being accidentally damaged or having fluid inside the syringe barrel flow back into the machine.
-
Page 14: Dispense Modes
DC50 MAX Digital Dispenser Operating Manual DISPENSE MODES FIG. 7: Dispense Modes MANUAL MODE Use the button to switch to MANUAL mode. MANUAL mode allows the operator to actuate the machine on demand whenever the dispense signal is activated (i.e. foot pedal is pressed). -
Page 15: Timed Mode
DC50 MAX Digital Dispenser Operating Manual DISPENSE MODES FIG. 8: Dispense Modes TIMED MODE Use the button to switch to TIMED mode. TIMED mode allows the operator to dispense for a set period, regardless of how long the foot pedal is pressed. - Page 16 DC50 MAX Digital Dispenser Operating Manual Press the button again to move to the next digit to the right of the one that was previously flashing. Adjust accordingly to the correct numerical value using the buttons. Continue to press the button to scroll through the digit positions, adjusting the numerical values as required.
- Page 17 DC50 MAX Digital Dispenser Operating Manual SETTING A DISPENSE TIME GREATER THAN 9.999 SECONDS. Use the button to scroll to the first digit position. use button to increase the numerical value upwards. Once the numerical value “9” is displayed, press the button again.
- Page 18 DC50 MAX Digital Dispenser Operating Manual REDUCING A DISPENSE TIME FROM GREATER THAN 10.00 SECONDS Use the button to scroll to the first digit position. use button to decrease the numerical value downwards until the numerical value “1” is displayed.
-
Page 19: External Machine Actuation
DC50 MAX Digital Dispenser Operating Manual EXTERNAL MACHINE ACTUATION Pin # Description NO (Normally Open) COM (Common) Not Used FIG. 9: External Machine Actuation A dry contact closure (0 Volt) between the Input (Pin #1) and Common (Pin #2) Input pins will trigger a dispense signal. -
Page 20: Spare Parts List
DC50 MAX Digital Dispenser Operating Manual SPARE PARTS LIST Ref. Item Number Description 5601900 Air Out Module 5601901 Vacuum Control Valve (inc. fittings) 5601972 Pressure Gauge (inc. fittings) 5601891 Pressure Regulator (inc. fittings) 5601904 Solenoid Module (inc. fittings) 5601905 Timer Board 5601887-10FT Ø6mm Transparent PU Tubing (10ft) - Page 21 DC50 MAX Digital Dispenser Operating Manual SPARE PARTS LIST Ref. Item Number Description 5601970 Purge Tray (50 per pack) 5601971 Bottle Kit (10 per pack) © 2023 Fisnar - 21 - DC50 MAX Rev 01...
-
Page 22: Technical Drawing
DC50 MAX Digital Dispenser Operating Manual TECHNICAL DRAWING © 2023 Fisnar - 22 - DC50 MAX Rev 01... - Page 23 DC50 MAX Digital Dispenser Operating Manual NOTES © 2023 Fisnar - 23 - DC50 MAX Rev 01...
-
Page 24: Limited Warranty
In no event shall manufacturer be liable for consequential or incidental damages. A return authorization is required prior to shipping a defective machine to the factory. Manufacturer reserves the right to make engineering or product modifications without notice. info@fisnar.com www.fisnar.com...
