F&F CZF-334 TRMS Manual

Phase loss sensor with adjustment, without n-wire

Advertisement

Quick Links

CZF-334 TRMS
Phase loss sensor
with adjustment,
without N-wire
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collecti on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
The CZF-334 phase loss microprocessor sensor without neutral
wire is designed to protect electric motor powered from the
3-phase network in following cases:
» voltage loss in at least one phase;
» voltage drop in at least one phase below 320 V;
» voltage increase in at least one phase above 480 V;
» voltage unbalance between phases above a preset vlalue.
The sensor correctly measures the true rms value of the
voltage (TrueRMS), even when the power supply voltage
is (disturbed) distorted.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the CZF-334 TRMS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for F&F CZF-334 TRMS

  • Page 1 F&F Filipowski L.P. Konstantynowska 79/81, 95-200 Pabianice, POLAND phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71 www.fif.com.pl; e-mail: biuro@fif.com.pl CZF-334 TRMS Phase loss sensor with adjustment, without N-wire Do not dispose of this device in the trash along with other waste!
  • Page 2: Front Panel

    Functioning A correct supply voltage is signalled by the lighting of the green LED. A voltage drop below 320 V, or a rise above 480 V on at least one, any phase, or a voltage asymmetry above the set value is signalled by the green LED not being lit.
  • Page 3 Signalling Signalling Description Correct network parameters, the relay is on. Countdown to switching on or deactivation of the relay (depending on the current state of the output). Asymmetry or voltage threshold exceeded. Relay switched off (voltage value of either phase below 320 V or above 480 V or asymmetry above the set value).
  • Page 4 Voltage waveforms Legend: T1 = 1÷10 s T2 = 1÷60 s - 4 -...
  • Page 5 If a voltage drop below 320 V or a rise above 480 V is detec- ted, the relay will be switched off with a delay of 1 s. The diode corresponding to the phase that exceeded the voltage threshold will be extinguished. If the phase voltages return to the correct values, the relay will be switched on after time T2.
  • Page 6 Wiring diagram Contacts configuration - 6 -...
  • Page 7 Changeover contact of the relay allows to connect a vi- sual or audible signalling system that informs about the relay activation, which means switching off the motor. Technical data power supply 3×400 V contact separated 2×NO/NC maximum load current (AC-1) 2×6 A signalling of correct power supply 2×LED...
  • Page 8: Warranty

    Warranty The F&F products are covered by a warranty of the 24 months from the date of purchase. Effective only with proof of purchase. Contact your dealer or directly with us. CE declaration F&F Filipowski L.P. declares that the device is in conformity with the essential requirements of The Low Voltage Directive (LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC) Directive 2014/30/UE.
