Casio DQS-20 User Manual

MA0212-A
• A sticker is affixed to the glass of this clock when you purchase it. Be sure to remove the sticker before using the
clock.
• Before using this clock for the first time, note the insulation sheet sticking out of the battery compartment. Pull out
the insulation sheet in the direction indicated by the arrow before using the clock.
• After removing the insulation sheet, press the RESET button (5 5 5 5 5 ).
• Depending on the clock model, the configuration of your clock may differ somewhat from that shown in the
illustration.
DATE (month - date)
PM indicator
USER'S GUIDE DQS-20
Alarm Off Alarm On
Day of the week Alarm time Snooze on indicator
Alarm on indicator
Current time
(Hour, minutes, seconds)
GENERAL GUIDE
1 1 1 1 1 SNOOZE button
Pressing this button while the alarm is sounding stops the alarm.
2 2 2 2 2 LIGHT button
Press to turn on the backlight.
3 3 3 3 3 Alarm Time Set buttons
Use these buttons to set the alarm time or current time.
4 4 4 4 4 SET button
Use this button when setting the current time.
5 5 5 5 5 RESET button
Press to reset the clock after replacing the battery.
6 6 6 6 6 Alarm Switch
Use this switch to turn the alarm on and off, and to turn on the snooze alarm.
7 7 7 7 7 Solar panel
8 8 8 8 8 Insulation sheet
Pull out the insulation sheet in the direction indicated by the arrow before using the clock.
After removing the insulation sheet, press the RESET button (5 5 5 5 5 ).
SETTING THE TIME
1. Press the SET button (4 4 4 4 4 ) to cycle through the setting screens as shown below.
Normal Timekeeping Screen
Year Setting Screen
Month and Day Setting Screen
12-hour/24-hour Timekeeping Screen
Time Setting Screen
1
