- Page 1 — I N S T R U C T I O N G U I D E RGM8000 meter Quickstart guide...
- Page 3 — Table of contents Introduction Mechanical installation Electrical installation 07– 12 Program settings...
- Page 4 R G M 8 0 0 0 M E T E R Q U I C K S TA R T G U I D E — Introduction Installation of the RGM8000 meter must be User manual: https://www.electroind.com/ performed only by qualified personnel who follow products/shark-250-power-meter/ standard safety precautions during all procedures.
-
Page 5: Mechanical Installation
M e c h a n i c a l i n s ta l l at i o n — Mechanical installation — 01 ANSI installation — 02 DIN installation ANSI studs 4.0" round form — DIN mounting brackets 96 mm square form Remove (unscrew) ANSI studs for DIN installation... -
Page 6: Electrical Installation
3 phase, 4 wire 3 phase, 4 wire Delta with PTs, Delta direct, 3 phase, 3 wire 3 phase, 3 wire Other wiring configurations are available. Refer to the RGM8000 meter user manual (see page 4 for the download link). -
Page 7: Program Settings
P r o g r a M s e t t i n g s — Program settings 2. Press the DOWN ARROW once. CFG (Configuration) moves to the top of the display. 3. Press the ENTER button. You will see the Configuration menu, shown below. - Page 8 R G M 8 0 0 0 M E T E R Q U I C K S TA R T G U I D E 5. Press the ENTER button to go to the CT Pt-n is dictated by primary voltage; denominator screen (CT-d).
- Page 9 If you do not want to save your settings, press the RIGHT ARROW. YES changes to NO. Press the ENTER button. For additional programming instructions for the faceplate buttons, see chapter 2 in the RGM8000 meter installation and operation manual.
- Page 10 R G M 8 0 0 0 M E T E R Q U I C K S TA R T G U I D E Connect to the meter through the USB port: 5. The Device Status screen opens, displaying The RGM8000 meter has a standard USB port information about the meter. that makes connection between the meter and a laptop PC simple.
- Page 11 P r o g r a M s e t t i n g s Program CT, PT ratios E. Total Demand Distortion (TDD Setting): This 1. The first Device Profile screen is the CT, PT setting of the Device Profile allows you to set Ratios and System Hookup.
- Page 12 R G M 8 0 0 0 M E T E R Q U I C K S TA R T G U I D E Program communications settings Program communications settings 1. From the Device Profile screen, click General To enter a name/ID for the meter: Settings>Communications.
