- Page 1 6 Pcs Sofa Set...
- Page 2 IMPORTANT Please make a decision which model you want to put modules together,because you have to use : Seat Part(6ST)+Back Part(6BK)+Side Part(6SD) can be assembled as the third armless :Seat Part(6ST)+Back Part(6BK)+Long Back Part(6LB),can be assembled as the corner...
- Page 3 Contact US: Service@alaulm.com www.alaulm.com Step 1 Step 2 Step 3 Step 4...
- Page 4 Catalog Important......................01 Care & Instruc�ons....................02 How to Cover Holes & Repair Broken Wicker............02 How to Assemble U-Shaped Connector..............04 How to Assemble End Cap..................04 Parts List of Box A ....................05 Parts List of Box C....................05 Parts List of Box B ....................06 Packing List ......................07 How to Assemble Armless Sofa ................08 How to Assemble Le�...
- Page 5 U-Shaped Connector How to Assemble End Cap...
- Page 6 Packing List of Box A and C Part Name Label No. 6 Pcs Seat Part 6 Pcs Back Part 6 Pcs Side Part Seat Cushion Foam Box A Long Back Cushion Short Back Cushion High L-Shaped Feet U-Shaped Connector Screw Set Seat Cushion Cover Box C Long Back Cushion Cover...
- Page 7 Packing List of Box B Part Name Label No. 6 Pcs Seat Part 6 Pcs Back Part 6 Pcs Long Back Part 6 Pcs Side Part Box B...
-
Page 8: Packing List
Packing List Right Arm Sofa x 1 Armless Sofa x 2 Armless Sofa or Corner Sofa x 1... - Page 9 Armless Sofa Do not use machine Two Persons together Need 25mins roughly Step 1:Assemble Back Part(6BK) And Seat Part(6ST). Tips:Do not 100% Tight. 6BK x 1 6ST x 1 M6x45(Q) x 3 Wrench(V) x 1 Spanner(W) x 1 Step 2:Assemble Side Part(6SD). Tips:Screws 100% Tight This Step.
- Page 10 Armless Sofa Do not use machine Two Persons together Need 25mins roughly Step 3:Assemble High L-Shaped Feet And Screw Feet. M6x60(L) M6x60:The Longest Screw High L-Shaped Feet x 4 Screw Feet(P) x 4 M6x60 x 8 Wrench(V) x 1 Spanner(W) x 1 Step 4:Put the Seat Cushion and Back Cushion on.
- Page 11 Do not use machine Two Persons together Need 25mins roughly Step 1:Assemble Back Part(6BK) And Seat Part(6ST). Tips:Do not 100% Tight. 6BK x 1 6ST x 1 M6x45(Q) x 3 Wrench(V) x 1 Spanner(W) x 1 Step 2:Assemble Arm Part(6AM) or Arm Part with PSWOOD(6AM-P). Tips:Screws 100% Tight This Step.
- Page 12 Do not use machine Two Persons together Need 25mins roughly Step 3:Assemble High L-Shaped Feet. M6x60(L) High L-Shaped Feet x 4 Screw Feet(P) x 4 M6x60 x 8 Wrench(V) x 1 Spanner(W) x 1 Step 4:Put the Seat Cushion and Back Cushion on.
- Page 13 Right Arm Sofa Do not use machine Two Persons together Need 25mins roughly Step 1:Assemble Back Part(6BK) And Seat Part(6ST). Tips:Do not 100% Tight. 6BK x 1 6ST x 1 M6x45(Q) x 3 Wrench(V) x 1 Spanner(W) x 1 Step 2:Assemble Arm Part(6AM) or Arm Part with PSWOOD(6AM-P). Tips:Screws 100% Tight This Step.
- Page 14 Right Arm Sofa Do not use machine Two Persons together Need 25mins roughly Step 3:Assemble High L-Shaped Feet. M6x60(L) M6x60:The Longest Screw High L-Shaped Feet x 4 Screw Feet(P) x 4 M6x60 x 8 Wrench(V) x 1 Spanner(W) x 1 Step 4:Put the Seat Cushion and Back Cushion on.
- Page 15 Corner Sofa Do not use machine Two Persons together Need 25mins roughly Step 1:Assemble Back Part(6BK) And Seat Part(6ST). Tips:Do not 100% Tight. 6BK x 1 6ST x 1 M6x45(Q) x 3 Wrench(V) x 1 Spanner(W) x 1 Step 2:Assemble Long Back Part(6LB). Tips:Screws 100% Tight This Step.
- Page 16 Corner Sofa Do not use machine Two Persons together Need 25mins roughly Step 3:Assemble High L-Shaped Feet. M6x60(L) M6x60:The Longest Screw High L-Shaped Feet x 4 Screw Feet(P) x 4 M6x60 x 8 Wrench(V) x 1 Spanner(W) x 1 Step 4:Put the Seat Cushion,Short Back Cushion and Long Back Cushion on.
- Page 17 Do not use machine Two Persons together Need 25mins roughly Step 1:Assemble CTL and CTS. CTL x 1 CTS x 2 M6x30(S) x 4 Spanner(W) x 1 Step 2:Assemble CTC CTC x 1 M6x30(S) x 4 Spanner(W) x 1...
- Page 18 Do not use machine Two Persons together Need 25mins roughly Step 3:Assemble CTL. Tips:Screws 100% Tight This Step. CTL x 1 M6x30(S) x 4 Spanner(W) x 1 Step 4:Assemble High L-Shaped Feet. M6x60(L) High L-Shaped Feet x 4 Screw Feet(P) x 4 M6x60 x 8 Wrench(V) x 1 Spanner(W) x 1...
- Page 19 Do not use machine Two Persons together Need 25mins roughly Step 5:Press in the Glass Pads. Glass Pad Glass Pad x 4 Step 6:Put on the Glass Top Glass Top x 1...
- Page 20 Two Persons together Need 25mins roughly Step 1:Tuck the prickly �e out of the seam at the bo�om of the sofa.Pull out the prickly �e from the surface of the sofa to spread out and adjust to the right posi�on. www.alaulm.com...
