PREPARATIONS BEFORE USE

Unpack the product
♦ Open the packing box
♦ Read the User Manual carefully and keep it in good condition
♦ Check the accessories and documents supplied with the machine

TECHNICAL SPECIFICATION

Rating of power supply: AC 220-240V 50/60Hz, with earthed jack, and allowed current is
greater than 5 A.
Tank capacity: 350ml
Optiona Capacity: 250ml
Rated power: 900-1050W
Steam pressure: 3bar
Injected steam capacity: 28g/min
Temperature controller: functioning temperature: 135°C ;
Fuser: functioning temperature: 167°C
Overall dimension: 300x 150x210mm
Net weight: 1.5kg
FUNCTIONS
■ Disinfection and sterilization:
Install the long spray cup on the short spray nozzle and aim the spray cup at the position
that needs disinfection, and then press down the steam button. High- temperature steam
can kill bacteria.
■ Cleaning the clothes
Install the spray cup with hairbrush on the short nozzle, and then mount the towel sleeve.
Aim the spray cup at the hung clothes, and press down the steam button and move the
hairbrush up and down as well as to the left and to the right at the same time. Then stains
can be removed from the clothes.
■ Cleaning doors and windows
Install the spray cup with hairbrush on the short spray nozzle, and then install the spray
cup for door/window on it. Aim the spray cup at the door/window, and press down the
steam button and move the hairbrush up and down as well as to the left and to the right at
the same time. Then stains can be removed from the door/ window.
■ Cleaning the floorboards
Install the extended spray cup on the short spray nozzle or do not install it. Then install
bent spray cup or round spray cup. Aim the spray cup at the floor board, and press down
the steam button to remove the dirt and stains in wall comers and on the floor.
13
