- Page 1 INcsa005_UK 853-020V70 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
- Page 2 PRODUCT CHARACTERISTICS Easy to use Plug on power supply, and the machine immediately starts heating process. When it heats to specified temperature, press the steam button, and steam will be sprayed out slowly. So the machine is easy to operate. With complete cleaning accessories supplied, the machine can be assembled and disas- sembled easily.
- Page 3 SAFETY PRECAUTIONS This icon represents “Prohibition” This icon represents “Warning” Cleaning and user maintenance shall not be made by children without supervision. To prevent electrical shock, do not immerse power cord or power plug in water or other liquids. The mains lead of this appliance is not replaceable by the user. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Page 4 Before refilling water, ensure to unplug the power cord to disconnect power supply. It is necessary to unplug the power cord after the machine is used, before it is cleaned and while it is repaired. Do not add any rust remover, odor counteracting agent, alcohol and detergent into the tank, which will possibly cause damage to the tank.
- Page 5 TECHNICAL SPECIFICATION Rating of power supply: AC 220-240V, 50/60Hz, Tank capacity:350ml Max capacity of water cup: 250ml Rated power:900-1050W Steam pressure:0.25MPa～0.32 Mpa Injected steam capacity: 28g/min Temperature controller: functioning temperature: 132℃; fuser: functioning temperature:169℃ Overall dimension: 300×150×210mm OPERATING INSTRUCTIONS Operation Procedures 1.Unpack the product, check the accessories and documents supplied with the product and make sure that the product and accessories are not damaged.
- Page 6 (II) 2.Install spray cup with round brush or bent spray cup For direct installation on short spray nozzle, aim the spray cup with round brush or bent spray cup at the top of spray nozzle, as shown in Figure 3, and push the spray cup upwards until it is in position.
- Page 7 Refill water during operation 1.Unplug the power cord and disconnect the power supply 2.Press down the steam button to release the pressure until no steam is injected out. 3.Slowly unscrew the safety cap but do not remove it, and residual steam will be discharged slowly until no steam comes out.
