T R EL L E B O RG M A R I N E A N D I N F R A S T RU C T U R E
SafePilot P3
INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SafePilot P3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trelleborg SafePilot P3

  • Page 1 T R EL L E B O RG M A R I N E A N D I N F R A S T RU C T U R E SafePilot P3 INSTALLATION MANUAL...
  • Page 2 The SafePilot P3 is a fixed installed navigation built-in battery power backup which will power the system for Pilots. It is independent of the vessel system for a minimum of 5 hours.
  • Page 3 Contents SafePilot P3 What’s in the box Technical specifications System overview Installation...
  • Page 4: What's In The Box

    What’s in the box...
  • Page 5 10m Vulcanizing tape ....T 1 pc. SafePilot P3 positioning unit ..U 1 pc. iPad with SafeCaptain....V 1 pc.
  • Page 6: Gnss Receiver

    Technical specifications GNSS GNSS RECEIVER SafePilot P3 includes a dual-antenna GNSS Tracked Systems: GPS / QZSS, Galileo, receiver, able to compute a highly accurate GLONASS, BeiDou. heading and position. Below is the specification Frequencies: L1C/A, L2C, L1OF, L2OF, E1B/C, for the GNSS receiver and GNSS antennas.
  • Page 7: Ais Receiver

    NETWORK DGNSS CORRECTIONS (NTRIP) INERTIAL MOTION UNIT (IMU) Protocol: Networked Transport of RTCM via SafePilot P3 includes intelligent filtering, that can Internet Protocol (NTRIP) provide Heading, Rate of Turn and Dead Reckoning if GNSS signals are obstructed. UDP Port: 2102 Gyro Bias Instability: ≤...
  • Page 8: System Overview

    For a full description and guidelines on connecting to three antennas. The three antennas the installation of the system, look in are: 1 GNSS antenna(P) for computing the the following section. Figure 1 system overview of a SafePilot P3 system...
  • Page 9: Installation Instructions

    The dimension of the hole should be 13mm in diameter. 1. Locate a suitable place for the SafePilot P3 box inside the wheelhouse. d. It is crucial that the Wi-Fi antenna is placed centrally with no obstructions in near vicinity a.
  • Page 10 Below you find a step-by-step guide on installing the system. b. Two GNSS antennas are used with the SafePilot P3 to compute position and heading. One named “P” and another named “H”. c. Ensure there is a clear view of the sky where the antennas are installed.
  • Page 11: Installation

    Installation After doing a thorough planning of the installation, you are now ready to install the equipment. Please follow the instructions in this chapter very carefully! INSTALLING BRACKETS AND ANTENNAS: 1. At the suitable locations you have found Figure 3 for GNSS Antennas, mount the brackets for GNSS antenna (Part G).
  • Page 12 RUN THE COAXIAL CABLES 120m of coaxial cable (Part I) is delivered with the system which should be sufficient. This cable needs to be cut to length, one for each antenna and connected with a connector at both ends. A crimp tool (Part S) to do so are included in the system.
  • Page 13 9. Attach the Cable tag for POS antenna (Part N) on the cable at both ends. 10. Measure out the needed cable length for GNSS Antenna “H” (Part E) to the P3 unit inside the wheelhouse. Cut the coax cable (Part I) to that length.
  • Page 14 15. Measure out the needed cable length for AIS Antenna (Part F) to the P3 unit inside the wheelhouse. Cut the coax cable (Part I) to that length. a. Make sure to have 3-5 meters of slack cable per coax cable. 16.
  • Page 15 19. Run the cable through the ceiling of the wheelhouse to the location where the P3 unit is to be placed. 20. Attach the Cable tag for AIS antenna (Part O) on the cable at both ends. Figure 15 INSTALL THE P3 UNIT INSIDE THE WHEELHOUSE 21.
  • Page 16 22. Find the coax cable you have tagged with “POS” (Part N) a. Crimp TNC Connector (Part J) to the cable, following the guidelines in Appendix 2 and/or the video on the USB stick. b. Connect the TNC connector to the connector on the P3 Unit marked “P”.
  • Page 17 FINISHING UP 28. Check that cables has been secured with cable ties and that all connectors has been. 29. Inside the wheelhouse find the QR Code (Part Q) and mount it near the pilot plug in a position that is easy for the ACP pilot to find. a.
  • Page 18 APPENDIX 1 – MECHANICAL LAYOUT OF P3 UNIT...
  • Page 19 APPENDIX 2 – INSTRUCTION HOW TO MOUNT TNC CONNECTOR CABLE ASSEMBLY INSTRUCTION BODY CONTACT PIN FERRULE DIAGRAM ASSEMBLY INSTRUCTION Step 1: STRIP AS SHOWN. [.591] [.280] [.138] Step 2: SLIDE FERRULE " C " OVER CABLE. Step 3: PUT PIN " B " ON CENTER CONDUCTOR AND SOLDER OR CRIMP IN "...
  • Page 20 APPENDIX 3 – INSTRUCTION HOW TO MOUNT N CONNECTOR N-CON BODY FERRULE CONTACT PIN DIAGRAM ASSEMBLY INSTRUCTION Step 1: STRIP AS SHOWN. Step 2: SLIDE FERRULE " C " OVER CABLE. Step 3: PUT 0.4 MM GAGE IN PLACE , INSERT CABLE'S CENTER CONDUCTOR INTO CENTER PIN "...
  • Page 21 Register SafeCaptain by entering your email in SafeCaptain Settings. Connect the iPad to a WiFi with internet access and open SafeCaptain. Connect to the SafePilot P3 network. Start the SafeCaptain app. Check that you see GPS/SBAS (Arrow 1) in the quality indicator and that there is a heading (Arrow 2) derived.
  • Page 22: Appendix 6 - Maintenance

    To replace the internal battery email safepilotp3@trelleborg.com before this date APPENDIX 7 – ORIENTATION OF SAFEPILOT P3 UNIT INSIDE THE WHEELHOUSE The SafePilot Control Unit can be installed in eight different orientations. Below pictures are seen from above, upper left shows the default orientation.
  • Page 23 FURTHER INFORMATION & TROUBLESHOOTING GUIDANCE For step by step guidance and instructuctions on: For generic questions in relation to installation and SafePilot P3 please see our FAQs by visiting Registering SafeCaptain www.safepilotp3.com/support. Updating SafeCaptain License Pending (error message) Data Validation...
  • Page 24 Trelleborg is a world leader in engineered polymer solutions that seal, damp and protect critical applications in demanding environments. Its innovative solutions accelerate performance for customers in a sustainable way. WWW.TRELLEBORG.COM/MARINEANDINFRASTRUCTURE LinkedIn: Linkedin.com/company/trelleborg-marine-and-infrastructure YouTube: Youtube.com/c/TrelleborgMarineInfrastructure Facebook: TrelleborgMarineandInfrastructure Twitter: @TrelleborgMI Trelleborg Marine and Infrastructure...
