Z8000WUNL
Specifications
Projection System
High-aperture Epson 3-chip, 3LCD technology
Projection Method
Front/rear/ceiling mount
LCD Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
2,304,000 pixels x 3LCDs
Native Resolution
WUXGA (1920 x 1200)
Aspect Ratio
Native 16:10, also supports 4:3, 16:9, 5:4
Pixel Arrangement
Cross stripe
Projection Lens
Type
Powered zoom/focus
F-number
1.65 – 2.51 (Standard lens), lens not included
Focal Length
36 mm – 57.35 mm (Standard lens)
Zoom Ratio
Optical zoom 1.0 – 1.61 (Standard lens)
Screen Throw Ratio Range
1.74" – 2.82" (Standard lens)
Size (projected distance)
60" – 500"
Lens Shift (powered)
Vertical: ±70%
Horizontal: ±20%
Keystone Correction
Vertical: -30 degrees to +30 degrees
Horizontal: -20 degrees to +20 degrees
Brightness (Normal Mode)
1
White light output — 6000 lumens
(ISO 21118 standard),
Color light output — 6000 lumens
Contrast Ratio
Up to 5000:1
Brightness Uniformity (typical)
90%
Color Reproduction
16.7 million colors
Specifications 28
Dual Lamps
Type
330 W x 2 UHE
Lamp Life
3
Up to 2500 hours (Normal Mode)
Up to 3500 hours (ECO Mode)
Dimensions (W x D x H)
Including Feet (with standard lens)
21.0" x 28.9" x 8.9"
Excluding Feet, Lens
21.0" x 28.9" x 6.6"
Weight
48.4 lb with standard lens
Effective Scanning Frequency Range
Pixel Clock
13.5 MHz to 162 MHz (up to UXGA 60 Hz)
Horizontal
15 kHz to 80 kHz
Vertical
24 Hz, 30 Hz, 50 Hz, 60 Hz (Digital)
50 Hz to 85 Hz (Analog)
Remote Control
Features
Brightness, Contrast, Tint, Saturation, Sharpness, Color
Mode, Input, Signal, Sync, Tracking, Position, Zoom, Focus,
Lens Shift, Shutter, ID, Source Search
Operating Angle
Front
Right/left ± 60 degrees
Upper/lower -45 to +15 degrees
Rear
Right/left ± 30 degrees
Upper/lower -45 to +15 degrees
Operating Distance
49.2'
Display Performance
Native
1920 X 1200
Resize
640 x 480
800 x 600
1280 x 1024
1400 x 1050
1600 x 1200
Video I/O
Display Performance
NTSC: 560 lines
PAL: 560 lines
(depends on observation of the multi-burst pattern)
Input Signal
NTSC / NTSC4.43 / PAL / M-PAL / N-PAL /
PAL60 / SECAM
SDTV: 480i / 576i / 480p / 576p
HDTV: 720p /1080i / 1080p
3D Y/C separation, noise reduction motion
compensated
Interlace progressive conversion
(2 – 2, 3 – 2 film detection)
Interfaces
Computer/component video: D-sub HD 15 pin x 1
5BNC component x1
HDMI x 1
DVI-D x 1
Hardwire remote jack x 1
S-video: mini DIN x 1
Composite video BNC x 1,
LAN networking: RJ-45 x 1, 10/100Mb
Serial: RS-232c x 1
Monitor out: mini D-sub 15 pin x 1

Other Features

Audio Output
None
Operating Temperature
32 ° to 113 °F (0 ° to 45 °C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption
942 W (Normal operation)
776 W (ECO operation)
11.2W Standby (Network On)
0.3 W Standby (Network Off)
Fan Noise
38 dB (Normal Mode)
32 dB (ECO Mode)
Security
Kensington ® - style lock provision, anchor
(metal) bar for security lock or cable, handles
attached to body for cable wrap
Support — The Epson Connection
SM
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Projector Service and Warranty Programs
Three-year projector limited warranty, 90-day limited lamp
warranty, Epson Road Service Program and
Epson PrivateLine dedicated toll-free support
®
(U.S. and Canada only)
Contents in Box
Power cable, computer cable, projector
remote control, batteries, cable cover, user manual CD,
Quick Setup Sheet, PrivateLine support card, password
protection sticker, monitor and control CD
Accessory Part Numbers
Lens Part Numbers
Standard zoom lens (ELPLS04) V12H004S04
Long throw zoom lens (ELPLL07) V12H004L07
Middle-throw zoom lens 1 (ELPLM06) V12H004M06
Middle-throw zoom lens 2 (ELPLM07) V12H004M07
Rear projection wide lens (ELPLR04) V12H004R04
Wide zoom lens (ELPLW04) V12H004W04
Mount Part Numbers
Flush ceiling mount bracket V12H003B25
Mount bracket with extended pipe V12H003B26
Other Accessories Part Numbers
Kensington security lock ELPSL01
Hardware remote control cable set V12H005C28
Replacement remote control 1512200
Genuine Epson Lamp Part Numbers
Single (ELPLP51) V13H010L51
Dual lamp kit (lamp x 2) (ELPLP52) V13H010L52
Projector Part Number
PowerLite Pro Z8000WUNL V11H266920
(lens not included)
Replacement Air Filter Set Part Number
Replacement air filter set V13H134A23
