HOW TO INITAL CONFIGURATION OF
NORDAC PRO SK 550P

Advertisement

loading
Need help?

Need help?

Do you have a question about the NORDAC PRO SK 550P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for nord NORDAC PRO SK 550P

Summary of Contents for nord NORDAC PRO SK 550P

  • Page 1 HOW TO INITAL CONFIGURATION OF NORDAC PRO SK 550P...
  • Page 2 • USB-C cable (SK CE-USB-C-PC-USB-3m) Modbus-Adapter with RJ12 plug (SK_TIE4_RS232_USB) INITIAL THE CONFIGURATION Please follow step by step to initial the configuration of NORDAC PRO SK 550P. 1. POWER ON FREQUENCY CONVERTER On X6 connect 24 V. 40: GND 41: 24 V 2.
  • Page 3 MODBUS CONNECTION • connect the RJ12 connector to the marked communication interface X14 • connect the USB with the PC. 3. START “NORDCON” SOFTWARE 4. COMMUNICATION SETTINGS • Click on “Communication settings” under Extras to setup connection • Select the desired port in the combo box "Port" (information about available com ports see "Device Manager") 5.
  • Page 4 6. PARAMETER TRANSFER T O DEVICE • Select in the device list NORDAC/Serial USS/ [00] 55xP 750W/230V/1 • Choose under Device "Parameter transfere to device” • In the File Open dialog choose the "ASPEN_LEX80x3_NordAC_550P.ndbx" file. The transferring process starts automatically. Please wait until the transferring process is successfully finished How to do initial configuration of NORDAC PRO SK550P...
