MELBOURNE MIRROR ASSEMBLY
INSTRUCTIONS
BOX #1
A. MIRROR 1 PC
B. MIRROR SUPPORTS 2 PCS
1.ALLEN BOLT (M6X50) 8 PCS
!
OPTION 1: ATTACHING MIRROR TO WALL
THE MIRROR. MAKE SURE THE DISTANCE BETWEEN THE MOUNTING HARDWARE ON THE WALL
MATCHES THE DISTANCE BETWEEN THE MOUNTING HARDWARE ON THE MIRROR. TEST THE
NOTE! WE RECOMMEND INSTALLING THE MOUNTING HARDWARE INTO WALL STUDS OR A BOARD
THAT IS SECURED TO THE STUDS. CONSULT A PROFESSIONAL INSTALLER BEFORE MOUNTING TO
FRONT VIEW
PARTS AND PACKING DETAIL
CONTAINS
HARDWARE POUCH
B
A
2.SPRING WASHER (M6) 8 PCS 3.FLAT WASHER (M6) 8 PCS 4.ALLEN KEY 1 PC
WARNING: FOR YOUR SAFETY AND CONVENIENCE,
( SOLD SEPARATELY )
BOX #2
C. DRESSER 1 PC
BACK VIEW
C
Advertisement
Related Manuals for Modus Furniture MELBOURNE 8D6483
Summary of Contents for Modus Furniture MELBOURNE 8D6483
- Page 1 MELBOURNE MIRROR ASSEMBLY INSTRUCTIONS PARTS AND PACKING DETAIL ( SOLD SEPARATELY ) BOX #1 BOX #2 CONTAINS HARDWARE POUCH A. MIRROR 1 PC C. DRESSER 1 PC B. MIRROR SUPPORTS 2 PCS 1.ALLEN BOLT (M6X50) 8 PCS 2.SPRING WASHER (M6) 8 PCS 3.FLAT WASHER (M6) 8 PCS 4.ALLEN KEY 1 PC WARNING: FOR YOUR SAFETY AND CONVENIENCE, OPTION 1: ATTACHING MIRROR TO WALL THE MIRROR.
