AUTUMN DINING CHAIR
ASSEMBLY INSTRUCTIONS
A. CHAIR BACK : 1 PC
C. LEFT LEG
: 1 PC
D. RIGHT LEG
: 1 PC
STRETCHER : 1 PC
TOOL REQUIRED PHILLIPS HEAD SCREW DRIVER
(NOT PROVIDED)
B. CHAIR SEAT : 1 PC
E. LEFT
STRETCHER : 1 PC
Description
No.
1
ALLEN BOLT (1/4"x40mm)
2
ALLEN BOLT (1/4"x70mm)
3
FLAT WASHER (1/4")
4
LOCK WASHER (1/4")
5
HEX NUT (1/4")
6
WOOD SCREW (4x40mm)
7
8
00:15
MODUS
F U R N I T U R E
F. RIGHT
G. MIDDLE
STRETCHER : 1 PC
HARDWARE LIST:
SPANNER
ALLEN KEY
Quantity
1 PC
4 PCS
9 PCS
9 PCS
4 PCS
6 PCS
1 PC
1 PC
Advertisement
Table of Contents
Related Manuals for Modus Furniture AUTUMN 8FJ866
Summary of Contents for Modus Furniture AUTUMN 8FJ866
- Page 1 MODUS AUTUMN DINING CHAIR ASSEMBLY INSTRUCTIONS F U R N I T U R E B. CHAIR SEAT : 1 PC A. CHAIR BACK : 1 PC C. LEFT LEG D. RIGHT LEG E. LEFT F. RIGHT G. MIDDLE : 1 PC : 1 PC STRETCHER : 1 PC STRETCHER : 1 PC...
