Kamar L3412 User Manual

User manual
L3412
Head lamp LED + position LED TL 12/24V
Technical data
• Product dimensions: 245x139,4mm
• Cable: 350mm
• Working voltage: 12/24V
• Approvals, certificates:
ECE R7, ECE R10, ECE R112, IP67
• Power consumption: 55W+8W
• LED quantity: 18szt
• Material of execution:
Housing: AL.
Lens: PC
• Working temperature: from -40°C to +60°C
Functions
• LED headlight
• Position LED
• For automo ve use only
• LED Headlight is intended for vehicles with 12/24V installation
• Reverse polarity protection
Mounting method
• Installation only in specialized workshops or professional service
• Lamps must be installed only in accordance with the UNECE regulations
Wire connection
FUNCTION
High beam
Warnings
• Use as intended
• Use in airy places
• Do not touch the lamp during operation and immediately after it is turned off, the lamp may get warm
Any unauthorized interference with the lamp (associated with its depressurization, interference with the electronic system, etc.) is associated with the loss of
•
warranty
• The device must be installed and kept out of reach of children
Marking on the product or in the related texts indicates that it should not be disposed of with other household waste at the end of its useful life. To avoid damaging the environment and human health by uncontrolled disposal,
please separate the product from another type of waste and recycle it responsibly to promote the reuse of material resources as a permanent practice. For information on where and how to safely recycle this product, household
users should contact the retailer where they purchased the product. Users in companies should contact their supplier and check the terms of the purchase agreement.The product should NOT be disposed of with other
We reserve the right to change technical data and possible errors. Photos/drawing and
technical data are only illustrative, and given product may slightly differ from them. Coping
the part or the entire package without the written authorization is forbidden. All rights
reserved.
WIRES COLOR
Black
Ground
Red
Yellow
Position
Important! Do not look directly at the light. It can cause the eye damage
Correct disposal of the product (used electrical and electronic equipment)
commercial waste.
Terms of warranty:
- we provide a guarantee for a period of 24 months from the date of sale,
- any unauthorized interference with the item entails the loss of the guarantee.
Importer: KAMAR Knapkiewicz S.K.A.
al. Armii Krajowej 254
85-689 Bydgoszcz, Poland
Country of origin: PRC
