Page 1 ZyPerUHD60 4K IP Video Distribution System —————————————————————————————————————————— User Manual Updated November, 2023...
Page 2 ZeeVee is the leading manufacturer of high-quality encoder/modulator/decoder products for video distribution over any type of transmission media; be it RF coax, ﬁber, or copper ethernet. Established in 2007, ZeeVee has been manufacturing industry-leading products while operating the company responsibly in compliance with the strictest levels of regulatory and environmental requirements.
Page 3: Table Of Contents
CONTENTS System Description ..................1 ZyPerUHD60 Features ...................2 ZyPerUHD60 Part Numbers ...................3 Package Contents ....................5 System Elements .....................6 Encoder Function .....................6 Decoder Function .....................7 ZyPer Management Platform ................8 ZyPer Management Platform Hardware ............9 Detailed Interface Descriptions ..............10 Triple Input Dual LAN Encoder (Rev 2E, 2EA and 2EMP) .......10 Enclosure .....................10...
Page 4 Wallplate Encoder (Rev 1WE) ................17 Enclosure ......................17 Ports (Wallplate Encoder Front) ..............18 USB-C Cable Requirements ..............19 Ports (Wallplate Encoder Back) ..............19 Dual LAN Decoder (Rev 2D and 2DA) ...............20 Enclosure .....................20 Ports (Decoder Back) ................20 Ports (Decoder Front) ................21 Single LAN Decoder (Rev 1D and 1DA) ..............22 Enclosure .....................22 Ports (Decoder Back) ................22 Ports (Decoder Front) ................23...
Page 5 Dual Ethernet Port Dante Commands .............48 Dual Port Dante Commands ..............49 Mounting Brackets ..................51 Power Save Mode ..................52 Switch Requirements ...................53 Setting up ZyPerUHD60 ................54 USB Details .....................55 Device Technical Speciﬁcations ..............56 Encoder and Decoder HDMI Video Speciﬁcations ......56 Physical and Environmental ..............57 General Safety and Care Instructions .............58...
Page 6 ZyPerMP Speciﬁc Cleaning Procedure ..........61 Important Siting and Application Considerations .........62 ZyPerUHD60 Equipment Type and Uses ............62 Installation Environment ..................63 Mounting Options ..................63 Ventilation ....................63 Water and moisture ..................64 AC Mains Connection ...................65 AC Power Cord ..................66 Responsibility and Stewardship ..............67 Reduction of Hazardous Substances (RoHS) ..........67...
Page 7: System Description
ZyPerUHD60 System Description The ZyPerUHD60 series of products from ZeeVee provide a means for transmitting and receiving audio-visual information across a standard IP network with outstanding quality at very low latencies. A minimal system consists of: • Video Source • ZyPerUHD60 Decoder device •...
Page 8: Zyperuhd60 Features
ZyPerUHD60 ZyPerUHD60 Features • Distributes and switches 4K UHD AV signals via standard gigabit Ethernet networks • Supports HDMI input and output resolutions up to 3840 x 2160@60Hz 4:4:4 • Supports USB-C Video input with resolutions up to 3840 x 2160@60Hz 4:4:4 •...
Page 9: Zyperuhd60 Part Numbers
Supports USB, IR, RS-232 (via phoenix), POE. Includes IR pigtail and wall mount brackets. Requires ZyPerUHD60 Encoder. Cables not included. ZyPerUHD60, HDMI 2.0 input Wall Plate Encoder with IP streaming via Gbit/copper. Supports HDMI 2.0a and USB-C video inputs capable of ZUHD60-1WE up to 4KP60 4:4:4 with embedded audio and HDCP 2.3 encrypQon,...
Page 10 Supports USB, IR, RS-232 (via phoenix), Dual LAN ports (1 supports POE). Includes IR pigtail and wall mount brackets. Requires ZyPerUHD60 Encoder. Cables not included. 6RU Rack mount chassis. Holds up to 10 ZyPerUHD60 encoders/ ZUHD60RACK decoders. Includes 4 blank panels.
Page 11: Package Contents
ZyPerUHD60 Package Contents Triple Input Dual LAN Encoder 1 x ZUHD60-2E or ZUHD60-2EA 1 x Phoenix Port (Male, 3.5mm, 3 pins) 1 x Phoenix Port (Male, 3.5mm, 5 pins) 1 x 940nm IR Emitter (3.9 ft - 1.2m) 150mA Peak.
Page 12: System Elements
System Elements Encoder Function The function of the ZyPerUHD60 Encoder Device (Encoder) is to accept audio and video data over a variety of interface types, and translate that data to a format suitable for transmission over a standard 1Gb Ethernet network.
Page 13: Decoder Function
1Gb Ethernet port (RJ45 with PoE) Decoder Function The function of the ZyPerUHD60 Decoder device (Decoder) is to accept 1Gb Ethernet trafﬁc that represents the information to be decoded and displayed. When the appropriate IP stream is received the Decoder unit will decompress it, reformat the video and audio information for display and play it out its HDMI video output.
Page 14: Zyper Management Platform
Operation of the ZMP, the management application, and the ZyPer-API are beyond the scope of this manual and are documented separately in far greater detail in the ZyPer Management Platform User Manual. Documentation can be downloaded from the ZeeVee website. https://www.zeevee.com/documentation-all-products...
Page 15: Zyper Management Platform Hardware
ZyPerUHD60 ZyPer Management Platform Hardware The ZyPer Management Platform (ZMP) is available from ZeeVee in two different hardware options. NUC and Rack Mount Server. Both versions have two network interfaces. It is important that the port labeled “Video Network” is connected to the LAN containing the ZyPerUHD60 encoder/decoder endpoints. ...
Page 16: Detailed Interface Descriptions
1Gb Ethernet over Cat6 (or better) cabling. RJ45 with PoE. Important Note: (PoE) If using PoE with ZyPerUHD60 units; the ZyPerUHD60 must have a path to the ground. This grounding can be accomplished by using a shielded network cable (F/UTP) Ethernet 1Gb Ethernet over Cat6 (or better) cabling.
Page 17: Usb-C Cable Requirements
8. Must have built in E-Mark IC Please see Appendix 1 near the end of this document for a list of known good USB-C cables. ZeeVee is not responsible for damage to any equipment caused by poor or incorrect USB-C cables.
Page 18: Ports (Encoder Front)
Analog audio input can be routed independently from any video input that is present on the HDMI port. Also note that it is not a requirement for HDMI video input to be present. The ZyPerUHD60 encoder analog audio input can be routed to the analog audio output of any ZyPerUHD60 decoder.
Page 19: Single Input Single Lan Encoder (Rev 0E And 0Ea)
1Gb Ethernet over Cat6 (or better) cabling. RJ45 with PoE. Important Note: (PoE) If using PoE with ZyPerUHD60 units; the ZyPerUHD60 must have a path to the ground. This grounding can be accomplished by using a shielded network cable (F/UTP) HDMI Input HDMI 2.0a input port capable of up to 4KP60 4:4:4 with embedded audio and...
Page 20: Ports (Encoder Front)
Analog audio input can be routed independently from any video input that is present on the HDMI port. Also note that it is not a requirement for HDMI video input to be present. The ZyPerUHD60 encoder analog audio input can be routed to the analog audio output of any ZyPerUHD60 decoder.
Page 21: Single Input Single Lan Encoder (Rev 1E And 1Ea)
1Gb Ethernet over Cat6 (or better) cabling. RJ45 with PoE. Important Note: (PoE) If using PoE with ZyPerUHD60 units; the ZyPerUHD60 must have a path to the ground. This grounding can be accomplished by using a shielded network cable (F/UTP) HDMI Input HDMI 2.0a input port capable of up to 4KP60 4:4:4 with embedded audio and...
Page 22: Ports (Encoder Front)
Analog audio input can be routed independently from any video input that is present on the HDMI port. Also note that it is not a requirement for HDMI video input to be present. The ZyPerUHD60 encoder analog audio input can be routed to the analog audio output of any ZyPerUHD60 decoder.
Page 23: Wallplate Encoder (Rev 1We)
Wallplate Encoder (Rev 1WE) The function of the encoder is to accept raw video images, encode, encrypt and format them for transmission. Enclosure There is one size of the ZyPerUHD60 Wallplate Encoder unit enclosure Input Function Box Size HDMI and USB-C Video Inputs Standard 2-Gang box (90mm Wide x 105.6mm High x 47mm Deep)
Page 24: Ports (Wallplate Encoder Front)
ZyPerUHD60 Ports (Wallplate Encoder Front) Cover plates removable. White and Black versions included in the box. White shown installed below: Port Name Index Description USB-C Full featured USB-C port supporting both Video and USB Host functionality. Video Can support device charging only if 20V source connected to unit. Cannot charge if UHD60 using PoE power only.
Page 25: Usb-C Cable Requirements
8. Must have built in E-Mark IC Please see Appendix 1 near the end of this document for a list of known good USB-C cables. ZeeVee is not responsible for damage to any equipment caused by poor or incorrect USB-C cables.
Page 26: Dual Lan Decoder (Rev 2D And 2Da)
ZyPerUHD60 Dual LAN Decoder (Rev 2D and 2DA) The function of the ZyPerUHD60 Decoder is to accept a 1Gb IP feed containing the video information to be displayed. It decodes and formats the video and audio information for display on the attached viewing device.
Page 27: Ports (Decoder Front)
ZyPerUHD60 Port Name Index Deﬁnition Ethernet 1Gb Ethernet over Cat6 (or better) cabling. RJ45. Dedicated port for Dante or Utility. Should not be used to “daisy chain” ZUHD60 units together. HDMI Out HDMI 2.0a output port capable of up to 4KP60 4:4:4 with embedded audio and HDCP 2.3 encryption.
Page 28: Single Lan Decoder (Rev 1D And 1Da)
ZyPerUHD60 Single LAN Decoder (Rev 1D and 1DA) The function of the ZyPerUHD60 Decoder is to accept a 1Gb IP feed containing the video information to be displayed. It decodes and formats the video and audio information for display on the attached viewing device.
Page 29: Ports (Decoder Front)
ZyPerUHD60 Port Name Index Deﬁnition HDMI Out HDMI 2.0a output port capable of up to 4KP60 4:4:4 with embedded audio and HDCP 2.3 encryption. Audio Out Audio Output connector. Output of balanced stereo audio on Phoenix connector. RS232 RS232 Control Port for sending and receiving side-band serial trafﬁc to/from decoders as directed by ZMP.
Page 30: Decoder "No Source Found" Background
ZyPerUHD60 Decoder “No Source Found” Background The ZyPerUHD60 decoder will output a default screen when no active video source is routed from an encoder to the decoder. This default background can be changed to any custom background desired. The default background looks something like this: The default background can be changed from the ZyPer Management Platform GUI in the Display Grid page Conﬁg tab.
Page 31 ZyPerUHD60 Once a ﬁle is selected, the ZyPerUHD60 unit will reboot itself in order for this change to take effect. Rev: 20231115 Page User Manual...
Page 32: Web Browser Interface
ZyPerUHD60 Web Browser Interface All ZyPerUHD60 Encoders and Decoders can be accessed directly via a web browser interface. Note that this feature is password protected. To access the web browser interface you will need to enter the IP address of the encoder or decoder into the browser address bar.
Page 33: Utilities Tab
The Update Firmware tabs allows you to update the ﬁrmware for the encoder or decoder. Choose the appropriate ﬁrmware update ﬁle that you have obtained from ZeeVee and press the Upload button. Note this process will force the encoder or decoder unit to reboot.
Page 34: Password Tab
ZyPerUHD60 Password Tab The Password tab will allow you to change the password. Statistics Tab The Statistics tab will show you a lot of basic information about the encoder or decoder.   This includes current IP address, MAC address, Status, Output information from a decoder, Input information for an encoder as well as EDID information for the endpoint.
Page 35: Video Wall Tab
ZyPerUHD60 Video Wall Tab The Video Wall tab is available on the Decoder side only. It allows you to set the size/ conﬁguration of a Video wall and select what display this decoder represents in the wall. Horizontal and Vertical Monitor Count determine the video wall size.
Page 36: Network Tab
ZyPerUHD60 Network Tab The Network tab allows you to set the IP address of the endpoint. Options include Auto IP, DHCP and Static. Default setting is DHCP. Note that if a DHCP server is not found, the units will assign themselves a Link-Local address.
Page 37: Function Tab
ZyPerUHD60 Function Tab The Function Tab allows you to enable / disable many features of the encoder or decoder. One important feature of the Decoder is the ability to select the encoder to route video/audio from. Routing The connected Encoder (Identiﬁed by MAC address is shown here) If you click on the small down arrow in this Source box you will bring up a listing of all available encoders on the network.
Page 38: Video Over Ip
ZyPerUHD60 Video over IP The Video over IP section allows the user to enable or disable certain features. Note that most changes will require a reboot of the encoder/decoder before being implemented. Turn off screen feature will cause decoder to not output the “Source Not Found” screen.
Page 39: Usb Over Ip
Important Note: The settings above are only valid when a ZyPer Management Platform is NOT connected to the system. The ZMP will automatically override any of the settings above with whatever setting is programmed to the ZMP. Contact ZeeVee support if other custom settings are needed.
Page 40: Serial Over Ip
ZyPerUHD60 Serial over IP This section allows you to set the baud rate, data bits, stop and parity bits for serial communications. Audio over IP This section allows you to enable or disable audio.  Rev: 20231115 Page User Manual...
Page 41: 802.1X Tab
ZyPerUHD60 802.1X Tab The 802.1X Tab allows the user to enable and conﬁgure 802.1X Authentication. Please note this this feature is intended to be used to experienced Network Engineers that are already familiar with 802.1X. The user can select a Certiﬁcate Authority certiﬁcate (Provided by the user) and an authentication method.
Page 42: Preview Stream
The ZyPerUHD60 encoder has the ability to output a Motion JPEG preview stream. This stream can be accessed easily from a browser. Note this stream does not contain audio. To view the stream in a browser point the browser to the IP Address of the ZyPerUHD60 encoder with /stream.
Page 43: Http Commands
Any HTTP capable application such as web browsers or cURL can be used to issue commands and receive outputs from the unit directly. Basic Format Given the IP address of the ZyPerUHD60 unit, the basic command syntax is: http://ipaddr/cgi-bin/query.cgi?cmd=xxxx ...
Page 44: Decoder Commands
ZyPerUHD60 Example: send the values “33 44 ab cd”, 115200 baud, 8 data bits, no parity, 1 stop bit curl “http://ipaddr/cgi-bin/query.cgi?cmd=soip2+-f+/dev/ttyS0+-b+115200-8n1+-H+-s+” 3344ABCD”” Note: There are no spaces between the Hex Data values above. Hex values can use upper or lower case.
Page 45 ZyPerUHD60 3. Switch input to HDMI2 curl http://ipaddr/cgi-bin/query.cgi?cmd=e+e_v_switch_in::hdmi2 4. Switch input to USB-C curl http://ipaddr/cgi-bin/query.cgi?cmd=e+e_v_switch_in::usb-c 5. Switch input to Auto Mode curl http://ipaddr/cgi-bin/query.cgi?cmd=e+e_v_mode_in::auto Rev: 20231115 Page User Manual...
Page 46: Dante Av-A
ZyPerUHD60 Dante AV-A Some ZyPerUHD60 Encoders and Decoders support Dante AV-A. This means every endpoint can be conﬁgured to support both Dante transmission and receive functionality. Feature Supported/Descrip:on Dante Audio channels 2x2 (input x output) Sample rate 44.1, 48, 88.2, 96 kHz...
Page 47 Dante AV-A can be implemented on both single and dual LAN ZyPerUHD60 units. In a single LAN conﬁguration, the Dante function and standard UHD60 AV function share the same LAN. Dante will share the same IP address as the ZyPerUHD60 unit itself. This IP address cannot be changed in Dante Controller.
Page 48: Dante Operation
- Represents the ﬁnal bytes of the ZyPerUHD60 MAC Address Note that the device can be renamed in Dante Controller software. A factory reset of the ZyPerUHD60 will restore the default Dante name. Important Note: ZyPerUHD60 Dante devices should never be made the Dante Clock Leader.
Page 49 ZyPerUHD60 Rev: 20231115 Page User Manual...
Page 50 ZyPerUHD60 Important Note: The Sample Rate must be set to the correct rate of the incoming audio. Incorrect setting of the Sample Rate ﬁeld will cause a Dante Transmitter to not see audio as available to transmit. Incorrect setting of the Sample Rate ﬁeld will cause a Dante Receiver to not receive audio from a Dante Transmitter.
Page 51: Dante Related Console Commands
ZyPerUHD60 Dante Related Console Commands The ZyPerUHD60 encoder and decoder units that support Dante can be conﬁgured as either a Dante Transmitter or Receiver device. There are various console commands to change this functionality. Note that some commands require a Reboot of the endpoint to be implemented.
Page 52: Encoder Dante Commands
ZyPerUHD60 c. Reboot via the Reboot command button Set HDMI audio output to the received Dante stream. (RX mode) e e_a_out_src_sel::addon Set HDMI audio output to the native stream received from encoder. (TX or RX mode) e e_a_out_src_sel::native Encoder Dante Commands...
Page 53 ZyPerUHD60 Important Notes: The following command can be used on either an encoder or decoder to check the status of the a_bridge_en setting. Please note the setting is reversed between an encoder and a decoder. astparam g a_bridge_en This will report back either “y” or “n”...
Page 54: Dual Ethernet Port Dante Commands
ZyPerUHD60 Dual Ethernet Port Dante Commands The dual ethernet port ZyPerUHD60 encoder and decoder units that support Dante can be conﬁgured to have the Dante transport stream output on either ethernet port. Note that both ports can be independent LANS or part of the same LAN.
Page 55: Dual Port Dante Commands
ZyPerUHD60 Dual Port Dante Commands Set IP Address Mode of “eth1” port astparam s dante_ip_mode MODE MODE values can be “static | dhcp” astparam save Reboot via the Reboot command button Set Static IP Address of “eth1” port (Assumes mode is set to Static above)
Page 56 ZyPerUHD60 astparam g dante_port The command astparam dump will provide an output of many settings. Rev: 20231115 Page User Manual...
Page 57: Mounting Brackets
The ZyPerUHD60 units come with mounting brackets in the box. These brackets can be used to securely attach a ZyPerUHD60 to a wall, ceiling, table etc.. It is up to the installer to provide the appropriate screws or bolts to afﬁx the unit to whatever surface it is to be mounted.
Page 58: Power Save Mode
ZyPerUHD60 Power Save Mode The ZyPerUHD60 decoders can be put into a power save mode when not receiving an active stream. By default when not receiving a video stream the decoder will output a backsplash screen indicating no source found. This can be disabled by entering power saving mode. This will disable all video output.
Page 59: Switch Requirements
ZyPerUHD60 Switch Requirements When the ZyPerUHD60 series deliver video, transfer rates can vary between 400 Mbps and 900 Mbps, which requires a gigabit Ethernet switch. (Date rates and compression depend on the resolution, color space and refresh rate of the input video stream.) Switches must support the following features: •...
Page 60: Setting Up Zyperuhd60
A network switch is needed in these many to many conﬁgurations. These environments also require conﬁguration through the ZyPerUHD management software. To set up ZyPerUHD60 in a many to many environment, you have to: • Install ZyPerUHD60 management software (Optional in some conﬁgurations) •...
Page 61: Usb Details
The maximum number of USB Hops allowed is 7. However the ZyPerUHD60 itself counts as 2 Hops making the real Hop limit = 5. Note: Only the UHD60 Encoder counts against Hop limit. Encoder = 2 Hops, Decoder = 0 Hops. ...
Page 62: Device Technical Specifications
ZyPerUHD60 Device Technical Speciﬁcations Encoder and Decoder HDMI Video Specifications All encoders and decoders have at least one exposed HDMI port. There is an input and output on the encoder and an output on the decoder. All the parameters in terms of the formats of video and audio carried are the same for either.
Page 63: Physical And Environmental
ZyPerUHD60 Physical and Environmental The following parameters apply to all encoders and decoders unless speciﬁcally stated otherwise. Type Parameter A/C Adapter 100-1240VAC 50-60Hz 0.7-0.45A draw on AC Mains Output Max: 12VDC 2.0A Output Max: 20VDC 6.0A (1WE, 2E, 2EA and 2EMP models only)
Page 64: General Safety And Care Instructions
ZyPerUHD60 General Safety and Care Instructions Safety WARNING: When using electronic products, basic precautions should always be followed, including: • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. •...
Page 65 Opening or damaging the ZyPerUHD unit in any way voids the warranty and immediately nulliﬁes any assertion of regulatory compliance made by ZeeVee. Any required service shall be performed by trained and qualiﬁed service personnel authorized by ZeeVee.
Page 66: Cleaning
ZyPerUHD60 Cleaning Encoder, Decoder and ZyPerMP Unit Cleaning Procedures Before cleaning: 1.Switch off or fully disconnect the AC power from the external supply unit connector to the ZyPer unit. 2.If the state of the AC power cannot be established, disconnect the DC input plug from the ZyPer unit before proceeding.
Page 67: Zypermp Specific Cleaning Procedure
ZyPerUHD60 Care should be taken to not spray cleaner directly on to the unit or into the vents to avoid liquid ingress and damage to the internal electronics. CAUTION: Do not apply or spray liquid directly on to the unit’s exterior as excess liquid may cause damage to internal electronics.
Page 68: Important Siting And Application Considerations
ZyPerUHD60 Important Siting and Application Considerations ZyPerUHD60 Equipment Type and Uses ZyPerUHD60 Intended Uses • Equipment is intended for the distribution of Audio Visual Information in and around a facility. • Equipment is intended to distribute Human Interface and control information over the same network as the Audio Visual information following the same or different logical distribution paths.
Page 69: Installation Environment
ZyPerUHD60 Installation Environment The general area where the ZyPerUHD60 unit is to be installed shall be clean and free of obstructions or clutter. Mounting Options • Unit may be mounted horizontally • Unit may be bolted to a horizontal surface using the provided L-brackets •...
Page 70: Water And Moisture
Water and moisture   Never expose the ZyPerUHD60 unit to direct rain, moisture, or excessively high humidity.   Never use the device near water - e.g. near a bathtub, basin, pool, sink, or in a wet basement.   Clean only in accordance with the instructions in this manual.
Page 71: Ac Mains Connection
The ZyPerUHD60 system is intended and rated for continuous operation Should the ZyPerUHD60 equipment be unused for an extended period of time it should be disconnected from the AC mains at the AC inlet to the external AC/DC converter in order to protect the equipment from transient over-voltage conditions.
Page 72: Ac Power Cord
ZyPerUHD60 AC Power Cord Connect the external AC/DC supply unit to the AC mains with a UL-listed detachable power cord, 3-wire, type SJ or equivalent, 18 AWG min., rated 250 V min., plug 5-15P conﬁguration for 120V application, or 6-15P for 240V application.
Page 73: Responsibility And Stewardship
Product Lines: ZyPer Products supplied by ZeeVee, Inc. Be advised that based on the information available to ZeeVee from our component and sub- assembly providers, the product lines listed above do not contain as intentional additives, any of the referenced materials at the levels indicated, as referenced in the subject EU directives. To the best of our knowledge, none of these materials are generated during production and the supplied component parts of the ZeeVee products do not contain the listed materials.
Page 74 This information is believed to be accurate and refers to the laws, regulations and products at the date of issue. However, ZeeVee makes no express or implied representations or warranties with respect to the information contained herein. It is the responsibility of our customers to determine that their use of ZeeVee products is safe, lawful, and technically suitable for their applications.
Page 75: Fcc Compliance Statement
ZyPerUHD60 FCC Compliance Statement The ZyPerUHD family of devices has been tested and found to comply with the limits for Class A Digital Devices pursuant to Part 15 of the FCC Rules. Operation is subject to the following conditions: 1) these devices may not cause harmful interference, and 2) these devices must accept any interference received including interference that may cause undesired operation.
Page 76: Emc Information
ZyPerUHD60 EMC Information The ZyPerUHD devices should be mounted and operated in accordance with the guidelines speciﬁed in this guide to maintain the integrity of the expected EMC characteristics. The supplied Power Supply (AC/DC Conversion unit) should be used. Any other AC/DC supply has not been tested or veriﬁed to perform at the levels indicated in this manual.
Page 77: Known Good Usb-C Cables
Appendix 1 Known Good USB-C Cables The following USB-C cables have been tested with the ZyPerUHD60 units for simultaneous support of the following features: 3840 x 2160 video at 60Hz. Audio. USB Data for Webcam video transfer. 60W power charging. (External power supply to ZyPerUHD60 required)
Page 78: Usb-C Charging
USB-C Charging The ZyPerUHD60 Encoders with USB-C input are capable of charging devices over the attached USB-C cable if the external 20V power supply is connected to the ZyPerUHD60 Encoder. Charging level is controlled by the attached device such as a MacBook. This ensures that the ZyPerUHD60 is not providing more power to the connected device than is called for.
Page 79: Poe Power And Poe Switches
DC Resistance Unbalance per Pair 3% or < 200mΩ Important Note If using a Network Switch to provide PoE power to the ZyPerUHD60 devices, it is important that the switch itself be protected against electrical surges that could be caused by something like a lightning strike.
Page 80: Dual Lan Connection Options (Non-Dante Uhd60 Units)
Dual LAN Connection Options (Non-Dante UHD60 units) The following are examples of how the secondary or utility LAN port can be used with a ZyPerUHD60 encoder or decoder. Please note these examples are for the Non-Dante enabled UHD60 units. Green connections are valid. Red connections are not valid.
Page 81 ZyPerUHD60 Dante Devices (Speaker, Microphone etc..) Other ZyPerUHD60 Endpoints (Not allowed) Back to the same LAN (Not allowed) Rev: 20231115 Page User Manual...
Page 82: Accessories
ZUHD60BP ZyPerUHD60 Spare blank panel for ZUHD60RACK. 12V2APS ZyPerUHD60 12 Volt Power Supply is a 12 Volt, 2A Power Supply for UHD60 units. Includes US, UK, EU and AU adapters. (Not compatible with 2E, 2EA, 2EMP and 1WE encoders) 20V6APS ZyPerUHD60 20 Volt Power Supply is a 20 Volt, 6A Power Supply for UHD60 Encoder units.
Page 83: Disclaimers
ZeeVee hardware designs are property of ZeeVee. Components, sub-assemblies, and methods utilized in the designs are free of any encumbrances or appropriate licenses and rights have been obtained by ZeeVee for the use in the described products in the intended manner.
