WOOD PILASTER KIT
TOOLS REQUIRED:
#2
#2
ESTIMATED ASSEMBLY TIME:
25 MIN
NOT INCLUDED:
• Pilaster Upright Mounting Screws
CARE AND MAINTENANCE:
Clean with a damp cloth and wipe
parts dry.
For video instruction visit:
rev-a-shelf.com/videos
No.
A
B
C
D
E
F
G
H
A
B
E
F
INSTALLATION INSTRUCTIONS: PILASTER UPRIGHT KIT
Parts List
Description
Pilaster Upright
Slide Bracket Sets
Installation Template
Drawer Slide Set
Drawer Boxes
Slide Locking Device Set
Wood Pegs
Wire Dividers
C
G
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
Qty
4
2-3
1
2 or 3
2 or 3
2 or 3
3 or 4
6 or 8
D
H
I-4PIL-KIT-0624
Advertisement
Related Manuals for Rev-A-Shelf 4WDB4-PIL-18SC-1
Summary of Contents for Rev-A-Shelf 4WDB4-PIL-18SC-1
- Page 1 12400 Earl Jones Way Louisville, KY 40299 rev-a-shelf.com Customer Service: 800-626-1126 WOOD PILASTER KIT TOOLS REQUIRED: ESTIMATED ASSEMBLY TIME: 25 MIN NOT INCLUDED: • Pilaster Upright Mounting Screws Parts List Description CARE AND MAINTENANCE: Pilaster Upright Slide Bracket Sets Clean with a damp cloth and wipe Installation Template parts dry.
- Page 2 (not included). In frameless cabinets, place the template 3/4” back from the front edge of the cabinet. NOTE: Pilaster Uprights can be installed with metal pins facing toward the front or the rear of the cabinet. Customer Service: 800-626-1126 | rev-a-shelf.com...
- Page 3 STEP 3A Lay the Installation Template on its side on the bottom of the cabinet, against the back of the front Pilaster Upright. Place the rear Pilaster Upright against the back of the Installation Template, and attach using one screw in the bottom location.
- Page 4 Utilize bracket hooks on slide Slide Locking Devices BLUM TRIGGERS to find preferred height on pilaster rails. Press down to lock into place. FRONT OF BOX Front of Box CLICK CLICK 12400 Earl Jones Way Louisville, KY 40299 rev-a-shelf.com Customer Service: 800-626-1126 Customer Service: 800-626-1126 | rev-a-shelf.com...
-
Page 5: Tools Required
12400 Earl Jones Way Louisville, KY 40299 rev-a-shelf.com Customer Service: 800-626-1126 WOOD PILASTER KIT TOOLS REQUIRED: ESTIMATED ASSEMBLY TIME: 25 MIN NOT INCLUDED: • Tornillos de montaje vertical de Lista de Partes / Liste des pièces pilastra / Vis de montage vertical Descripción / Description... - Page 6 Dans les armoires sans cadre, placez le gabarit à 3/4 po à l’arrière du bord avant de l’armoire. NOTE: Les montants de pilastre peuvent être installés à l’aide de goupilles métalliques orientées vers l’avant ou l’arrière de l’armoire. Customer Service: 800-626-1126 | rev-a-shelf.com...
- Page 7 STEP 3A Coloque la plantilla de instalación sobre la parte inferior del gabinete, contra la parte posterior del pilar vertical. Coloque el pilar vertical trasero contra la parte posterior de la plantilla de instalación y fíjela con un tornillo en la ubicación inferior. Déposez le gabarit d’installation sur le côté, au bas de l’armoire, contre l’arrière du montant de...
- Page 8 (pieza B) en las correderas, usando los tornillos suministrados, en los orificios de instalación recomendados. El logotipo de Rev-A-Shelf en el soporte de la corredera debe quedar orientado hacia la parte delantera de la corredera. (Ver figura 1).
