WOOD TIERED COOKWARE ORGANIZER
TOOLS REQUIRED:
3
#2
32
ESTIMATED ASSEMBLY TIME:
25 MIN
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
WATCH TUTORIALS OF OUR
PRODUCTS BEING INSTALLED
WWW.REV-A-SHELF.COM/VIDEOS
No.
Description
A
Wood Cookware Organizer (18 OR 24)
B
Upper Tray (18 OR 24)
C
#6 X 1/2" Pan Head Screws
D
#6 X 3/8" Flat Head Screws
E
Slide Straps
F
Slide Strap Feet
G
Left & Right Slides
H
Left & Right Slide Triggers
I
Wood Pegs
J
Wood Cookware Lid Organizers
K
Pots & Pans Organizer
L
Pots & Pans Handle Rest
M
Diagonal Pots & Pans Handle Rest
* 18" model comes with (1) 24" model comes with (2)
INSTALLATION INSTRUCTIONS: WOOD TIERED COOKWARE ORGANIZER
Parts List
1 Set
1 or 2*
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
Qty
A.
1
1
4
4
2
4
D.
C.
2
4
F.
G.
1
1
J.
I.
1
L.
M.
B.
E.
H.
K.
I-4CW2SC-1119
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rev-A-Shelf WOOD TIERED COOKWARE ORGANIZER
Summary of Contents for Rev-A-Shelf WOOD TIERED COOKWARE ORGANIZER
- Page 1 Pots & Pans Organizer Pots & Pans Handle Rest WATCH TUTORIALS OF OUR Diagonal Pots & Pans Handle Rest PRODUCTS BEING INSTALLED * 18” model comes with (1) 24” model comes with (2) WWW.REV-A-SHELF.COM/VIDEOS INSTALLATION INSTRUCTIONS: WOOD TIERED COOKWARE ORGANIZER I-4CW2SC-1119...
- Page 2 Note: Release triggers are side Slide triggers sensitive and are marked with an “L” & “R” for Left and Right. Pre-drilled holes FIGURE 4 STEP 4 Use instructions on the template to complete installation (See Figure 4). Customer Service: 800-626-1126 | rev-a-shelf.com...
- Page 3 12400 Earl Jones Way Louisville, KY 40299 rev-a-shelf.com Customer Service: 800-626-1126 INSTRUCCIONES DE INSTALACIÓN / LES INSTRUCTIONS D’INSTALLATION ORGANIZADOR DE UTENSILIOS DE COCINA EN NIVELES DE MADERA ORGANISATEUR D’USTENSILES DE CUISSON À ÉTAGES EN BOIS Herramientas requeridas: Outils Requis: Tiempo estimado de ensamblado Durée de l’installation:...
- Page 4 « R » pour la droite. PASO 4 / ÉTAPE 4 Utilice las instrucciones de la plantilla para completar la instalación (véase la figura 4). Utilisez les instructions d’utilisation sur le gabarit pour terminer l’installation (voir la figure 4). Customer Service: 800-626-1126 | rev-a-shelf.com...
