- Page 1 Translated from original operating instructions manual BLOWER AIRION 3 57_147010-E Operating Instructions 04/2024 READ THE USER OPERATING GUIDE CAREFULLY BEFORE USE...
-
Page 3: Table Of Contents
2.2.5. BATTERY TOOL USE AND CARE ..................... 2.2.6. MAINTENANCE ..........................2.2.7. MANAGEMENT OF THE RECYCLING AND RECOVERY OF WASTE FROM YOUR TOOL ....2.3. SAFETY INSTRUCTIONS FOR THE BLOWER AIRION 3 ............. 2.4. SAFETY MEASURES ASSOCIATED WITH BATTERY USE ............2.5. SAFETY SIGNS .......................... - Page 4 10. WARRANTIES ........................32 10.1. GENERAL WARRANTIES ......................10.1.1. STATUTORY WARRANTY ......................10.1.2. PELLENC COMMERCIAL WARRANTY ................... 10.1.3. PAID AFTER-SALES SERVICE ...................... 11. COMPLIANCE STATEMENTS .................... 35 11.1. STATEMENT OF COMPLIANCE: AIRION 3 ............... 11.2. UK DECLARATION OF CONFORMITY : AIRION 3 .............
-
Page 5: Introduction
57_147010-E 1. INTRODUCTION Dear Customer, Thank you for your purchase of Blower AIRION 3. Correctly used and maintained, this tool will give years of satisfactory performance. Warning In accordance with product liability laws, we are not responsible for damage caused by our product if the product includes an accessory that is not from the manufacturer or is not approved by the manufacturer. -
Page 6: Safety
• The is a professional tool and exclusively reserved for clearing green spaces by blowing (leaves, grass, paper and similar materials). • The company PELLENC declines all responsibility for damage caused by improper usage or usage for which the tool was not intended. -
Page 7: Personal Safety
BLOWER AIRION 3 57_147010-E 2.2.3. PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating a power tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention when using a power tool can result in serious personal injury. -
Page 8: Maintenance
2.2.7. MANAGEMENT OF THE RECYCLING AND RECOVERY OF WASTE FROM YOUR TOOL When the tool reaches the end of its life, PELLENC provide the end-of-life sheet of the equipment. The end-of-life sheet provides instructions for safely removing components. -
Page 9: Safety Measures Associated With Battery Use
• Battery alone: product that is classified as class 9, UN3480. 14. Use of a battery other than that provided by Pellenc SA is dangerous (risk of serious injury). If a different battery is used, Pellenc SA cannot be held responsible for any consequences. -
Page 10: Personal Protection Equipment
BLOWER AIRION 3 57_147010-E LwA sound power level guaranteed. Please read the operating instructions. Read the instructions carefully and follow the safety precautions. It is mandatory to wear safety goggles. IP54 protection rating of the tool (Protection against dust and water splashes from all directions.), does not apply to the battery. -
Page 11: Description And Technical Features
BLOWER AIRION 3 57_147010-E 3. DESCRIPTION AND TECHNICAL FEATURES 3.1. DESCRIPTION OF THE TOOL Blower AIRION 3 With standard exhaust pipe dia. 75mm Holding clips for the power cord Stud Tool power cord 10. Protective casing Control handle 11. Axial turbine Speed / mode selector button 12. -
Page 12: Technical Features
BLOWER AIRION 3 57_147010-E 3.2. TECHNICAL FEATURES Effective thrust* (N) 17.5 (boost) / 13.5 (speed 4) Peak power (W) Power supply voltage (V) 43.2 Weight of the tool with cable (kg) Weight of the tool without the cable (kg) 2.45 Actual weight of the tool in use (kg) 2.55... -
Page 13: Start-Up
57_147010-E 4. START-UP 4.1. CONTENT OF THE KIT Make sure the box contains: • A Blower AIRION 3 that comes with: • 1 standard blower nozzle dia. 75mm (8) • 1 Allen wrench (15) • 1 user guide • 1 warranty notice 4.2. -
Page 14: Assembly / Disassembly Of The Ergonomic Elbowed Nozzle (Optional)
BLOWER AIRION 3 57_147010-E 4.3. ASSEMBLY / DISASSEMBLY OF THE ERGONOMIC ELBOWED NOZZLE (OPTIONAL) 4.3.1. MOUNTING Choose the working position for the ergonomic elbowed nozzle according to the blowing work to be performed: • Detail A: 'COMFORT' position. • Detail B: 'HARD WORK' position. -
Page 15: Fitting/Removing The Blower Scraper (Optional)
BLOWER AIRION 3 57_147010-E 4.4. FITTING/REMOVING THE BLOWER SCRAPER (OPTIONAL) 4.4.1. MOUNTING Set up the wire scraper (18) in the guide ring (19) and the support ring (20) by pressing on the rods. Align the rods on the wire scraper (18) with the notches and clip the unit into the outlet blowing nozzle (8). -
Page 16: Connecting The Extension
(20) and the guide ring (19) by pressing on the rods. 4.5. CONNECTING THE EXTENSION The extension makes it easy to connect the AIRION 3 using its quick connector, see 9. Accessories and consumables, page 29. 4.5.1. 750 / 1200 / 1500 ULIB BATTERIES Put the battery in the harness (see harness mounting instructions). -
Page 17: 260 / 520 Alpha Batteries
BLOWER AIRION 3 57_147010-E Set up the pin of the quick connector into the harness buckle. Turn the quick connector a quarter turn to hold it in position. 4.5.2. 260 / 520 ALPHA BATTERIES Connect the battery to the harness, making sure it is in good orientation (see harness mounting instructions). -
Page 18: Dropping The Extension Cord
4.6.2. 260 / 520 ALPHA BATTERIES Disconnect the tool from the battery, see 4.8. Disconnecting PELLENC batteries from the tool, page 20. Turn the fast connector a quarter of a turn to remove the extension from the harness strap. -
Page 19: Connecting Pellenc Batteries To The Tool
To prolong the life of the connectors, they should be protected when disconnected. Avoid leaving the connectors in contact with abrasive or dirty surfaces, or subjecting them to major impacts (falls). For more information on PELLENC batteries, see battery instructions. • Connect the power cord of the tool (2) of the extension... -
Page 20: Disconnecting Pellenc Batteries From The Tool
To prolong the life of the connectors, they should be protected when disconnected. Avoid leaving the connectors in contact with abrasive or dirty surfaces, or subjecting them to major impacts (falls). For more information on PELLENC batteries see the battery instructions. • Disconnect the power cord from the tool (2) from the extension cord (24). -
Page 21: 260 / 520 Alpha Batteries
BLOWER AIRION 3 57_147010-E 5.2.2. 260 / 520 ALPHA BATTERIES • Press the On/Off button. 5.3. START-UP Hold the tool in its operating position, with the outlet blowing nozzle pointing to the ground. Turn the battery on by pressing the On/Off button, see 5.2. -
Page 22: Speed Selector
BLOWER AIRION 3 57_147010-E Press the control trigger (6) to start the blower. Note The progressive control trigger allows precise and instantaneous control of the air flow. Release the trigger (6) to stop the tool. Important Make sure to keep a sufficient distance (30 cm minimum) between the suction mouth and any volatile source (soils, walls, ceilings...), such as sand, gravel, liquids... -
Page 23: Booster" Mode
BLOWER AIRION 3 57_147010-E Selected speed Speed 1 speed 2 speed 3 speed 4 Booster Indicator light status Power (W) Battery life with the 1100 battery (mins) Battery life with the 1200 battery (mins) Battery life with the 1500 battery (mins) -
Page 24: Battery Life Reading" Mode
BLOWER AIRION 3 57_147010-E 5.6. “BATTERY LIFE READING” MODE To know the charge level of the battery, the tool has a ‘battery life reading’ mode. To activate the ‘battery status display’ mode: Press the selector button for 2 seconds, the LEDs then indicate the charge level of the battery: •... -
Page 25: Maintenance
BLOWER AIRION 3 57_147010-E Disconnect the tool from the battery, see 4.8. Disconnecting PELLENC batteries from the tool, page 20. Make loops with the tool's power cord (2) and attach it to the back of the handle using the holding clips (1). -
Page 26: Cleaning
• Check that the whole air duct (from the intake to the outlet) is not obstructed. • Ensure that air intake screen holes are not obstructed. • Visually check the status of the intake grid. If a replacement is necessary, contact your authorised PELLENC distributor. -
Page 27: Incidents And Troubleshooting
BLOWER AIRION 3 57_147010-E 7. INCIDENTS AND TROUBLESHOOTING... - Page 28 BLOWER AIRION 3 57_147010-E...
-
Page 29: Storage And Transport
BLOWER AIRION 3 57_147010-E 8. STORAGE AND TRANSPORT 8.1. STORAGE • Switch off the tool (see 5.8. After use, page 24). • Disconnect the battery (see 5.8. After use, page 24). • Store the battery (refer to the battery operating instructions). -
Page 30: Optional Accessories
BLOWER AIRION 3 57_147010-E 9.2. OPTIONAL ACCESSORIES Name Reference Snap hook to carry accessories 131701 Carrying strap 110002 Airion carrying strap for comfort harness 137018 Flat nozzle 122865 Tool hook 86708 Accessory scraper blower 102930 Elbow end piece kit 131967... - Page 31 BLOWER AIRION 3 57_147010-E Name Reference Comfort harness 57194 PELLENC ALPHA 260 battery 57192 PELLENC ALPHA 520 battery 57193 Extension cord 57238 Name Reference Comfort harness 57183 1200 Ultra Lithium Battery 57253 1500 Ultra Lithium Battery 57254 Extension cord 57238...
-
Page 32: Warranties
BLOWER AIRION 3 57_147010-E Name Reference 750 ULiB battery harness 57257 750 Ultra Lithium Battery 57191 Extension cord 57238 10. WARRANTIES 10.1. GENERAL WARRANTIES 10.1.1. STATUTORY WARRANTY 10.1.1.1. LATENT DEFECTS WARRANTY Apart from the commercial warranty provided for under Article II, Article 1641 of the French Civil Code states that "the seller is bound to a warranty on account of latent defects of the object sold which render it unfit for the use for... -
Page 33: Pellenc Commercial Warranty
PELLENC products are guaranteed under the commercial warranty as from delivery to the customer for a period of two (2) years for products connected to a PELLENC battery, and for a period of one (1) year for other PELLENC products. -
Page 34: Paid After-Sales Service
Paid after-sales service also covers PELLENC original spare parts, excluding labour and outside the legal and commercial warranty period. In case of replacement of original PELLENC spare parts in the context of after-sales service, said latter are covered by a warranty of one year as from the installation date. -
Page 35: Compliance Statements
BLOWER AIRION 3 57_147010-E 11. COMPLIANCE STATEMENTS 11.1. STATEMENT OF COMPLIANCE: AIRION 3 MANUFACTURER / PERSON AUTHORISED TO COMPILE PELLENC THE TECHNICAL FILE ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine designated below: GENERIC DENOMINATION... -
Page 36: Declaration Of Conformity
BLOWER AIRION 3 57_147010-E 11.2. UK DECLARATION OF CONFORMITY : AIRION 3 MANUFACTURER / ENTITY AUTHORIZED TO COMPILE PELLENC THE TECHNICAL FILE ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) We hereby declare that the machine referred to below as: GENERIC DENOMINATION... - Page 40 PELLENC Quartier Notre Dame - 84120 Pertuis (France)
