Route de Cavaillon
B.P. 47
84122 PERTUIS cedex
(France)
Tel : +33(0)4 90 09 47 00 Fax : +33(0)4 90 09 64 09
E-mail : pellenc.sa@pellenc.com
www.pellenc.com
Content:
- a blower
- a blowing nozzle
- a carrying hook
- an Allen wrench
- a user guide
READ THE USER'S GUIDE CAREFULLY BEFORE USE
pellenc s.a.
USER GUIDE
AIRION
Blower
ENG
Translation of the
original user guide
57_83350_F - 11/2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRION and is the answer not in the manual?

Questions and answers

Related Manuals for pellenc AIRION

Summary of Contents for pellenc AIRION

  • Page 1 Route de Cavaillon B.P. 47 84122 PERTUIS cedex (France) Tel : +33(0)4 90 09 47 00 Fax : +33(0)4 90 09 64 09 E-mail : pellenc.sa@pellenc.com www.pellenc.com Translation of the original user guide USER GUIDE AIRION Blower Content:...

  • Page 2: Table Of Contents

    «PELLENC sa» Terms of Warranty and Non-responsibility Clause ....... . .
  • Page 3 Refer to the «SAFETY INDICATIONS» heading in order to identify the location of the safety indications on the tool. No part of this manual may be reproduced without the written consent of PELLENC. The technical characteristics and the illustrations given in this manual are for information purposes and are in no way contractual.

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS GENERAL SAFETY INSTRUCTIONS FOR THE TOOL CAUTION Read all the safety measures and all the instructions. Retain all the safety measures and instructions for later reading. WORK AREA SAFETY a. Keep the work area clean and well lit. b.

  • Page 5: Safety Instructions For Airion

    SAFETY INSTRUCTIONS FOR AIRION 1– Do not misuse the power lead. Never use the power lead to carry, pull or disconnect the tool. Keep the power lead away from heat, lubricant, sharp edges and moving parts. 2– Never modify the connector in any way whatsoever.

  • Page 6: Description And Technical Characteristics

    4– Gradual control trigger 11– Shaped blowing nozzle 5– Protective casing 12– Carrying hook (see page 17) 6– Blower power cord 13– Allen wrench 7– Air intake elbow (Pellenc innovation) 14– Hanging hook 15– Carrying strap TECHNICAL CHARACTERISTICS AIRION Type...

  • Page 7: Putting The Tool Into Service

    Sound emission Maximum A-weighted sound pressure level (ref. 20 µPa) at the position of the = 78 dB(A) K = 2,5 dB(A) user C-weighted peak sound pressure (ref. 20 µPa) at the position of the user < 130 dB(C) Symbol Value Unit Reference...

  • Page 8: Preparing The Battery For Use

    STARTING Before start-up, make sure that the blower is in perfect condition to guarantee safe operation. 1– Connect the blower power cord to the Pellenc power tool battery. Screw it on and make sure it is properly attached. 2– Hold the blower in its operating position, blowing nozzle pointing to the ground.

  • Page 9: Booster" Mode

    Indicator light status Selected speed Power Air speed Air fl ow 1 lights lit Speed 1 200 W 37 m/s 450 m 2 lights lit Speed 2 350 W 46 m/s 555 m 3 lights lit Speed 3 450 W 52 m/s 620 m 4 lights lit...

  • Page 10: After Use

    Attach the blower to the carrying hook. AFTER USE 1– Flip the ON/OFF switch of the Pellenc power tool battery to OFF «0» 2– Unscrew the blower power cord and remove the battery. 57_11_009B 3– Make 3 loops with the cord and attach it at the rear of the handle with the carrying hook (see picture).

  • Page 11: Air Intake Grille Cleaning (Or Replacement)

    CAUTION: Never use solvents (Trichlorethylene, White Spirit, gasoline, etc) to clean the tool. AIR INTAKE GRILLE CLEANING (OR REPLACEMENT) DISASSEMBLY - Remove the two grille TBHC M4x14 screws (1). 57_11_012A - Unclip the grille from the casing in the order indicated: (2) then (3).

  • Page 12: Servicing Intervals

    When the tool is stored, it must be clean and the battery must be charged. INSTRUCTIONS FOR REPAIRING CAUTION! Only perform the maintenance and servicing interventions described in this manual. More important repairs can only be carried out by an approved Pellenc dealer. PART NUMBERS FOR SPARE PARTS 83335 Fine grille STORAGE - Always make sure the tool is clean and its battery is charged before storing it.

  • Page 13: Incidents

    INCIDENTS...
  • Page 14 INCIDENTS...

  • Page 15: Pellenc Sa» Terms Of Warranty And Non-Responsibility Clause

    As concerns parts or equipment that are not manufactured by PELLENC sa, in particular ball screw, battery, etc., the warranty is limited to that of the suppliers to PELLENC sa. Normal wear parts worn out as the result of use are never under warranty.

  • Page 16: Ec" Declaration Of Conformity

    "EC" DECLARATION OF CONFORMITY MACHINES DIRECTIVE 2006/42/CE, APPENDIX IIA. (ONLY CONCERNS EUROPE) MANUFACTURER PELLENC S.A. ADDRESS QUARTIER NOTRE-DAME ROUTE DE CAVAILLON - B.P. 47 84122 PERTUIS CEDEX (FRANCE) PERSON/ENTITY AUTHORISED TO COMPILE THE TECHNICAL DOSSIER PELLENC S.A. ADDRESS QUARTIER NOTRE-DAME ROUTE DE CAVAILLON - B.P.
