Hpr290155 - 15.5Kw - Grant Aerona 290 Installation & Operating Instructions Manual

12.5

HPR290155 - 15.5KW

Item Description
1 Front panel - 12kW & 15.5kW
2 Grill - 12kW & 15.5kW
3 Fan - 12kW & 15.5kW
4 Fan Motor - 12kW & 15.5kW
5 Fan Motor bracket - 12kW & 15.5kW
6 Electric box cover
7 Electrical control box
8 Drive PCB
9 Refrigerant PCB
10 Hydraulic PCB - 12kW & 15.5kW
11 Wire Holder- 6 Position - (All models)
12 Wire Holder- 3 Position - (All models)
13 Wire Holder- 2 Position - (All models)
14 PHE cover - 12kW & 15.5kW
15 PHE - 12kW & 15.5kW
16 Reactor cover
17 Reactor
18 Partition board assembly
19 Compressor
20 Compressor cover plate
21 Base assembly - 612kW & 15.5kW
22 Circulating Pump - (All models)
23 Water Pressure sensor - (All models)
24 Relief Valve - (All models)
25 Electric expansion valve
26 Water flow switch - (All models)
27 4-way valve body
28 4-way valve coil
Refrigerant Low Pressure sensor - 12kW &
29
15.5kW
Refrigerant High Pressure sensor - 12kW &
30
15.5kW
31 Pin Valve - (All models)
Refrigerant High Pressure switch - 4kW, 6.5kW,
32
9kW &15.5kW
Refrigerant storage tank assembly - 12kW &
33
15.5kW
34 Exhaust valve - (All models)
35 Top cover - 12kW & 15.5kW
36 Condenser
37 Condenser cover plate
38 Condenser connecting plate - 12kW & 15.5kW
39 Right panel - 12kW & 15.5kW
40 Right front column - 12kW & 15.5kW
41 Rear-right side plate assembly- 12kW & 15.5kW
42 Wind deflector panel - 12kW & 15.5kW
43 Left panel - 12kW & 15.5kW
44 Meter connector - (All models)
45 Drain hose - 12kW & 15.5kW
46 Sensor clamp - 12kW & 15.5kW
47 Refrigerant leakage sensor - (All models)
Outdoor air temperature sensor T4 - 4kW,
48*
6.5kW, 9kW & 15.5kW
Refrigerant discharge temperature sensor (TP) -
49*
12kW & 15.5kW
Page 58
Product
Item
code
HPR488 Evaporator coil temperature sensor (T3) - 12kW
50*
& 15.5kW
HPR382
Refrigerant suction temperature sensor (TH) -
51*
HPR362
12kW & 15.5kW
HPR462
Liquid Tube temperature sensor (T5) - 12kW &
52*
15.5kW
HPR142
Return temperature sensor (TA) - 12kW &
HPR328
53*
15.5kW
HPR244
54* Flow temperature sensor (TB) - 12kW & 15.5kW
HPR506
55* Compressor electric heater
HPR507
56* Chassis Heating Belt - 12kW & 15.5kW
HPR504
57* Carton - 12kW & 15.5kW
HPR702
*Not shown in exploded diagram
HPR701
HPR700
HPR405
HPR406
HPR329
HPR582
HPR123
HPR266
HPR530
HPR102
HPR560
HPR608
HPR669
HPR673
HPR621
HPR671
HPR201
HPR614
HPR615
HPR668
HPR620
HPR641
HPR667
HPR326
HPR284
HPR533
HPR531
HPR489
HPR222
HPR534
HPR490
HPR491
HPR300
HPR441
HPR181
HPR606
HPR604
HPR610
Description
Section 12: Spare Parts
Product
code
HPR607
HPR616
HPR611
HPR609
HPR612
HPR267
HPR421
HPR162
