  • Page 1 Operator’s Manual Light Tower LTW6K-V, LTW6K-VS LTW8K-V, LTW8K-VS Type LTW6K-V, LTW6K-VS, LTW8K-V, LTW8K-VS Document 5200013123 Date 1115 Version Language 5 2 0 0 0 1 3 1 2 3...
  • Page 2 Copyright notice © Copyright 2015 by Wacker Neuson Production Americas LLC All rights, including copying and distribution rights, are reserved. This publication may be photocopied by the original purchaser of the machine. Any other type of reproduction is prohibited without express written permission from Wacker Neuson Production Americas LLC.

  • Page 3: Foreword

    Use the separate Parts Book supplied with the machine to order replacement parts. If you are missing any of these documents, please contact Wacker Neuson to order a replacement or visit www.wackerneuson.com. When ordering parts or requesting service information, be prepared to provide the machine model number, item number, revision number, and serial number.
  • Page 4 The information contained in this manual is based on machines manufactured up until the time of publication. Wacker Neuson reserves the right to change any portion of this information without notice. The illustrations, parts, and procedures in this manual refer to Wacker Neuson factory-installed components.

  • Page 5: Table Of Contents

    LTW 6K-V / 8K-V Table of Contents Foreword Safety Information Signal Words Used in this Manual ............9 Machine Description and Intended Use ..........10 Safety Guidelines for Operating the Machine ........11 Lamp Safety ..................13 Operator Safety while Using Internal Combustion Engines ....14 Safety Guidelines for Towing the Machine .........
  • Page 6 Table of Contents LTW 6K-V / 8K-V 4.10 Before Starting ..................52 4.11 Starting the Engine ................53 4.12 Operating the Lights ................54 4.13 Meanings of Genset Controller Indicator Lights ........55 4.14 Stopping the Machine ................57 4.15 Automatic/Remote Start-Up ..............57 4.16 Generator Derating ................57 4.17 Raising the Tower ................58 4.18...
  • Page 7 LTW 6K-V / 8K-V Table of Contents Machine - LTW 6/8K-V ............... 88 Machine - LTW 6/8K-VS ..............89 Dimensions - LTW 6K-V, LTW 8K-V ..........90 Dimensions - LTW 6K-VS, LTW 8K-VS ..........90 Dimensions - LTW Skid ..............90 Tire Safety Information Schematics LTW 6K—Electrical Schematic ............
  • Page 8 Table of Contents LTW 6K-V / 8K-V wc_bo5200013123_03TOC.fm...

  • Page 9: Safety Information

    Safety Information Safety Information Signal Words Used in this Manual This manual contains DANGER, WARNING, CAUTION, NOTICE, and NOTE signal words which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal hazards. Obey all safety messages that follow this symbol.

  • Page 10: Machine Description And Intended Use

    Safety Information Machine Description and Intended Use Machine This machine is a mobile, trailer-mounted light tower. The Wacker Neuson Light description Tower consists of a trailer with a cabinet containing a diesel engine, a fuel tank, a control panel, and an electric alternator. A telescoping tower with four metal halide lights is vertically mounted to the top of the machine.

  • Page 11: Safety Guidelines For Operating The Machine

    Familiarize yourself with the location and proper use of all controls and safety devices. Contact Wacker Neuson for additional training if necessary. When operating this machine: Do not allow improperly trained people to operate the machine. People operating the machine must be familiar with the potential risks and hazards associated with it.
  • Page 12 Do not operate the machine if any safety devices or guards are missing or inoperative. Do not modify or defeat the safety devices. Only use accessories or attachments that are approved by Wacker Neuson. Safe When operating this machine: operating Remain aware of the machine’s moving parts.

  • Page 13: Lamp Safety

    Safety Information Do not raise, lower, or turn the tower while the unit is operating. If any part of the tower hangs up, or the winch cable develops slack while raising or lowering the tower, STOP immediately! Contact an authorized Wacker Neuson service representative.

  • Page 14: Operator Safety While Using Internal Combustion Engines

    Safety Information Operator Safety while Using Internal Combustion Engines WARNING Internal combustion engines present special hazards during operation and fueling. Failure to follow the warnings and safety standards could result in severe injury or death. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below.

  • Page 15: Safety Guidelines For Towing The Machine

    Safety Information Safety Guidelines for Towing the Machine WARNING Risk of severe injury or death. Improper trailer condition and towing technique can lead to an accident. Obey the trailer manufacturer’s instructions and the instructions below to reduce the risk of an accident. When towing the machine: Do not tow the machine if the towing vehicle’s hitch or the trailer’s coupler are damaged.

  • Page 16: Service Safety

    Do not modify the machine without the express written approval of the modifications manufacturer. Replacing Replace worn or damaged components. parts and Use only spare parts recommended by Wacker Neuson. labels Replace all missing and hard-to-read labels. Check all external fasteners at regular intervals. wc_si000782gb.fm...

  • Page 17: Hydraulic Fluid Safety

    Safety Information Lifting and When lifting the machine: transporting Make sure slings, chains, hooks, ramps, jacks and other types of lifting devices are attached securely and have enough weight-bearing capacity to lift or hold the machine safely. Remain aware of the location of other people when lifting the machine. To reduce the possibility of injury: Do not stand under the machine while it is being hoisted or moved.

  • Page 18: Safety Guidelines For Lifting And Transporting The Machine

    If you believe your trailer has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Wacker Neuson. If NHTSA receives similar complaints, it may open an investigation; and if it finds that a safety defect exists in a group of trailers, it may order a recall and remedy campaign.

  • Page 19: Labels

    LTW 6K-V / 8K-V Labels Labels Label Locations - LTW 6/8K-V bb n kk bb wc_gr011425 wc_si000783gb.fm...
  • Page 20 Labels LTW 6K-V / 8K-V wc_gr011426 wc_si000783gb.fm...

  • Page 21: Label Locations - Ltw 6/8K-Vs

    LTW 6K-V / 8K-V Labels Label Locations - LTW 6/8K-VS wc_gr012182 wc_si000783gb.fm...
  • Page 22 Labels LTW 6K-V / 8K-V qq bb n r yy wc_gr012183 wc_si000783gb.fm...

  • Page 23: Label Meanings

    LTW 6K-V / 8K-V Labels Label Meanings WARNING WARNING WARNING Explosion hazard. Do not use evaporative ADVERTENCIA ADVERTENCIA starting fluids such as ether on this engine. The AVERTISSEMENT AVERTISSEMENT engine is equipped with a cold starting aid. Using 5200005890 5200005890 evaporative starting fluids can cause an explosion which can cause engine damage, personal injury, or death.
  • Page 24 Labels LTW 6K-V / 8K-V WARNING Crushing hazards. Stand clear of front and rear of machine when tower is being raised or lowered. WARNING Crushing hazards. Stand clear of the front of the machine when the tower is being lowered with the hydraulic manual override valve.
  • Page 25 LTW 6K-V / 8K-V Labels DANGER Asphyxiation hazard. Engines emit carbon monoxide. Do not run the machine indoors or in an enclosed area unless adequate ventilation, through such items as exhaust fans or hoses, is provided. Read the Operator’s Manual. No sparks, flames, or burning objects near the machine.
  • Page 26 Labels LTW 6K-V / 8K-V See Operator’s Manual for metal halide lamp information and troubleshooting. BEFORE STARTING THE ENGINE: 1. Check levels of Engine oil Fuel Coolant 2. Move the circuit breakers to the OFF position. TO START THE ENGINE: 1.
  • Page 27 LTW 6K-V / 8K-V Labels TO LOWER TOWER: 1. Turn off all lights and engine. 2. Use switch inside door to lower tower. TO SECURE TOWER FOR TRANSPORT: 3. Loosen knob. 4. Use handle to rotate sets so lights are level. 5.
  • Page 28 AVERTISSEMENT AVERTISSEMENT 178775 Electrical ground Operator’s Manual must be stored on machine. Replacement Operator’s Manual can be ordered through your local Wacker Neuson distributor. Tie-down point 113726 Ultra low sulfur fuel only Insert jack locking pin before extending jack. wc_si000783gb.fm...
  • Page 29 LTW 6K-V / 8K-V Labels Fork lift pocket 177124 177124 WARNING WARNING WARNING Roll-over hazard To prevent injury or equipment damage, avoid high speeds and sharp turns when towing. ROLL OVER HAZARD Avoid high speeds, rapid acceleration and sharp turns when towing. ATENÇÃO ATENÇÃO PERIGO DE CAPOTAGEM...
  • Page 30 Labels LTW 6K-V / 8K-V Fuses 1.Not used 2. Controller 3. Fuel pump / solenoid 4. Alternator (on trailer, if equipped) Certification Label (VIN Number) Also attached to each unit is a Certification Label. This label specifies that the trailer conforms with all Federal Motor Vehicle Standards in effect at the time of manufacture.
  • Page 31 LTW 6K-V / 8K-V Labels Protecting Our Environment Fluid containment system (if equipped) Skid drain access point CAUTION Wheel nuts must be tightened to 85 ft.lbs. WARNING Operation of this equipment may create sparks that can start fires around dry vegetation. A spark arrester may be required.
  • Page 32 Labels LTW 6K-V / 8K-V Uncoupling will cause trailer to come loose from tow vehicle. 1. CHECK the pintle LOAD RATING is same or great than ring LOAD RATING. 2. LOCK the clamp in place using a pin or lock. ALWAYS use safety chains.
  • Page 33 LTW 6K-V / 8K-V Labels Lights can prevent trailer from being hit by other vehicles. You must: 1. CONNECT trailer and tow vehicle electrical connectors. 2. CHECK all lights: tail lights, turn signals, and brake lights. 3. DO NOT TOW if lights are not working. —...

  • Page 34: Lifting And Transporting

    Lifting and Transporting LTW 6K-V / 8K-V Lifting and Transporting Before Lifting or Transporting Checklist Requirements Machine stopped Flatbed truck or trailer capable of supporting the machine’s weight Chains, hooks, or straps capable of supporting the machine’s weight WARNING Crushing hazard. Improperly securing the machine can lead to a crushing hazard. Use only the designated tie-down points to secure the machine to a truck or trailer.

  • Page 35: Before Towing Checklist

    LTW 6K-V / 8K-V Lifting and Transporting Before Towing Checklist Before towing the machine, check the licensing requirements for trailers in your area. Also check the following items: Towing vehicle Check that the towing vehicle is rated to tow the load. Check that the towing vehicle is in serviceable condition.

  • Page 36: Lifting The Machine

    Lifting and Transporting LTW 6K-V / 8K-V Lifting the Machine Requirements Lifting equipment (crane, hoist, or fork truck) capable of supporting the machine’s weight Lifting devices (hooks, chains, and shackles) capable of supporting the machine’s weight Engine stopped Lifting points A lifting eye (a) is used for lifting the machine using a crane or hoist.

  • Page 37: Tying Down And Transporting The Machine

    LTW 6K-V / 8K-V Lifting and Transporting Tying Down and Transporting the Machine Requirements Engine shut down Transport vehicle (flatbed truck or trailer) capable of handling the weight and size of the machine. See Technical Data for dimensions and weights. NOTICE: Do not position steel ropes or chains across the machine frame or panels when tying down the machine.

  • Page 38: Testing The Breakaway System (Electric Brakes)

    Lifting and Transporting LTW 6K-V / 8K-V Testing the Breakaway System (Electric Brakes) Requirements Voltmeter Battery charger or backup battery (charged) When Test the breakaway system: Before towing Monthly if the machine is not in service Procedure Perform the following procedure to test the breakaway system. NOTICE: Disconnect the trailer wiring plug from the tow vehicle before testing.
  • Page 39 LTW 6K-V / 8K-V Lifting and Transporting Continued from the previous page. 5. If the brakes did not function, check the voltage of the breakaway battery. To do so: a. Remove the cover of the battery box. b. Remove the wires connected to the breakaway battery (d). c.

  • Page 40: Testing The Breakaway System (Hydraulic Surge Brakes)

    Lifting and Transporting LTW 6K-V / 8K-V Testing the Breakaway System (Hydraulic Surge Brakes) Requirements Hydraulic reservoir filled Machine parked on a flat surface When Test the breakaway system: Before towing After filling the hydraulic reservoir Procedure Perform the following procedure to test the breakaway system. 1.
  • Page 41 LTW 6K-V / 8K-V Lifting and Transporting Continued from the previous page. 7. Stop the tow vehicle. 8. Release the brake by simultaneously pulling on the breakaway cord and prying the locking spring with a screwdriver (c) or pry bar. wc_gr008510 Result The procedure to test the breakaway system is now complete.

  • Page 42: Operation

    1. Make sure all loose packaging materials have been removed from the machine. 2. Check the machine and its components for damage. If there is visible damage, do not operate the machine! Contact your Wacker Neuson dealer immediately for assistance.

  • Page 43: Control Panels

    LTW 6K-V / 8K-V Operation Control Panels wc_gr011402 Ref. Description Ref. Description 15A lights circuit breaker Glow plug indicator LTW 6K-V: 25A circuit breaker E-stop indicator LTW 8K-V: 33A circuit breaker LTW 20Z1-V: 80A circuit breaker LTW 20Z3-V: 70A circuit breaker Low oil pressure indicator Auto mode button High coolant temperature indicator...

  • Page 44: Positioning The Machine

    Position the trailer on a firm, flat surface clear of overhead wires and obstructions. CO Alarms Because this machine produces carbon monoxide (CO), Wacker Neuson recommends that CO alarms be installed in all structures in close proximity to the machine. CO alarms provide an extra measure of protection against this poison that you cannot see or smell.

  • Page 45: Mounting The Machine

    LTW 6K-V / 8K-V Operation Mounting the Machine Important Skidded machines do not include trailers or outriggers. The skidded machines must be mounted to a suitable surface before use. NOTICE: Mount the machine before raising the tower or operating the machine. Requirements Level mounting surface M12 mounting hardware (8 sets)

  • Page 46: Ground Connection

    Operation LTW 6K-V / 8K-V Ground Connection A ground connection (a) is located on the trailer frame. wc_gr010955 Function This ground connection is used for electrically grounding the Light Tower when necessary to comply with the National Electrical Code and other federal, state, and local regulations.

  • Page 47: Leveling The Trailer

    LTW 6K-V / 8K-V Operation Leveling the Trailer WARNING Tipping / falling hazard. Failure to level the trailer or extend the outriggers will severly reduce the stability of the unit. Level the trailer and extend the outriggers before raising the tower. The outriggers must remain extended while the tower is up.

  • Page 48: Refueling The Machine

    Operation LTW 6K-V / 8K-V Refueling the Machine Requirements Machine shut down Engine cool Machine/fuel tank level with the ground Fresh, clean fuel supply Procedure Perform the procedure below to refuel the machine. WARNING Fire hazard. Fuel and its vapors are extremely flammable. Burning fuel can cause severe burns.

  • Page 49: Aiming The Lights - Ltn-V

    LTW 6K-V / 8K-V Operation Aiming the Lights - LTN-V Overview Each individual light fixture can be aimed up, down, left, or right independent of one another. There are four total light fixtures on each machine. The light bars, which include two light fixtures each, can be tilted 45° in each direction from horizontal.
  • Page 50 Operation LTW 6K-V / 8K-V Continued from the previous page. Aiming Left or Right 1. Grasp the light fixture and aim it to the light left or right. If necessary, loosen the bracket nut (c) to allow movement of the fixture. NOTICE: Do not loosen the nut (b).
  • Page 51 LTW 6K-V / 8K-V Operation Continued from the previous page. Aiming the Perform the procedure below to aim the light bars. light bars 1. Loosen the knob (d), grasp the handles (e), and tilt the light bar to the desired angle.

  • Page 52: Before Starting

    Operation LTW 6K-V / 8K-V 4.10 Before Starting Before putting the Light Tower into service, review each item on the following checklist. Light Towers often run unattended for long periods of time. Therefore, it is important to make sure that the machine is set up properly to avoid possible operating problems.

  • Page 53: Starting The Engine

    LTW 6K-V / 8K-V Operation 4.11 Starting the Engine Requirements Review all items in topic Before Starting. NOTICES Do not use evaporative starting fluids (for example, ether) to start the engine. Do not start the engine under load. If the fuel tank was empty, you many need to bleed the fuel lines. Refer to the engine manufacturer’s documentation.

  • Page 54: Operating The Lights

    Operation LTW 6K-V / 8K-V 4.12 Operating the Lights Requirements Review all items in Section 4.10 Before Starting. Raise tower to desired height Start and warm up engine Procedure Perform the procedure below to operate the lights. 1. Turn on the main circuit breaker (a). wc_gr011396 2.

  • Page 55: Meanings Of Genset Controller Indicator Lights

    LTW 6K-V / 8K-V Operation 4.13 Meanings of Genset Controller Indicator Lights Background The genset controller includes eight LED indicator lights. Six of the indicators signal fault conditions. Two of the indicators signal operational conditions. See topic Troubleshooting Automatic Shutdown for more information. wc_gr010175 Ref.
  • Page 56 Consult the engine manufacturer’s documentation. Note: The generator can also cause problems. Consult a qualified electrician or your nearest Wacker Neuson dealer for possible causes of generator problems. Restarting the After fault conditions have been identified and rectified, press the red stop button machine and restart the machine.

  • Page 57: Stopping The Machine

    Push the STOP button (m) to de-energize the fuel solenoid. machine 4.15 Automatic/Remote Start-Up The engine controller is capable of automatically starting the engine. Contact Wacker Neuson Product Support for more information. 4.16 Generator Derating Background All generator sets are subject to derating for altitude and temperature. Although derating should not affect operation of the lights, it will reduce the available reserve power to the receptacles.

  • Page 58: Raising The Tower

    Operation LTW 6K-V / 8K-V 4.17 Raising the Tower Overview The tower is raised by the action of a hydraulic cylinder (c). Note: The tower can be raised without running the engine. WARNING Personal injury hazard. Raising or lowering the tower creates situations that if not avoided, will cause death or serious injury from striking, crushing, pinching, electrocution, etc.

  • Page 59: Lowering The Tower

    LTW 6K-V / 8K-V Operation 4.18 Lowering the Tower Overview A low-voltage electrical circuit controls the release of pressure in the hydraulic cylinder (c). When pressure is released, the tower will lower. Notes The engine does not need to be running to lower the tower. The hydraulic circuit includes a pressure release valve that lowers the tower in an emergency situation.

  • Page 60: Manually Rotating The Mast

    Operation LTW 6K-V / 8K-V 4.19 Manually Rotating the Mast Overview The operator can rotate the mast 360° while the tower is lowered. Procedure Perform the procedure below to rotate the mast. 1. Pull out the locking pin (a) on the bottom of the mast. 2.

  • Page 61: Receptacle Panel

    LTW 6K-V / 8K-V Operation 4.20 Receptacle Panel Overview The Light Tower is equipped with receptacles for running accessories and tools from the generator. Power to these receptacles is available any time the engine is running and the circuit breakers are “ON”. Receptacles The receptacle panels are equipped as follows: wc_gr005237...

  • Page 62: Emergency Stop Switch

    Operation LTW 6K-V / 8K-V 4.21 Emergency Stop Switch Location The emergency stop switch (f) is the red button located on the receptacle panel at the rear of the Light Tower cabinet. Operation Activate the emergency stop switch by pushing the red button in. Pushing the emergency stop switch opens the main circuit breaker and the fuel solenoid and results in the engine shutting down and an indicator to illuminate.

  • Page 63: Emergency Shutdown Procedure

    LTW 6K-V / 8K-V Operation 4.22 Emergency Shutdown Procedure General If a breakdown or accident occurs while the machine is operating, follow the procedures procedure below: 1. Stop the engine. 2. Disconnect all loads from the machine. 3. Lower the tower. 4.

  • Page 64: Factory-Installed Options

    This machine may be equipped with one or more of the following factory-installed options. To verify if any of these options are installed on your machine, contact Wacker Neuson Corporation at 1-800-770-0957. A nameplate listing the Model Number, Item Number, Revision, and Serial Number is attached to each unit.
  • Page 65 LTW 6K-V / 8K-V Factory-Installed Options Engine Block The engine block heater includes a Heater block heater (a) with a cord (b). The function of the block heater is to heat the engine coolant/ engine block to improve cold-weather engine starting. Plug the cord into a 120V power supply.
  • Page 66 Factory-Installed Options LTW 6K-V / 8K-V Battery An optional battery charger maintains Charger the battery at peak power while the machine is turned off. Use of a battery charger is recommended when the generator is not operated on a regular basis.

  • Page 67: Using The Internal Light Storage

    LTW 6K-V / 8K-V Factory-Installed Options Using the Internal Light Storage Prerequisites Machine shut down Left side of Light Tower cabinet open wc_gr005287 Procedure Perform the procedure below to store the light fixtures. 1. Rotate the two retaining wires (a) forward so that they lie flat in an open position. 2.

  • Page 68: Cold Weather Options

    Factory-Installed Options LTW 6K-V / 8K-V 4. Orient light fixture #2 so that the lens is facing you and the mounting bracket is on the top side. Place the fixture behind the left-hand divider (e) inside the light tower cabinet. NOTICE: Avoid pinching the electrical cables beneath the fixtures or between the fixtures and dividers.

  • Page 69: North Slope Options

    LTW 6K-V / 8K-V Factory-Installed Options North Slope Options North Slope machines include the following options: Containment system Electric brakes or surge brakes Manual winch or power winch Electronic governor Engine block heater Battery charger Rear hitch Additional options included with North Slope machines: Quad Outlet North Slope machines are equipped with an internal 4"...
  • Page 70 Factory-Installed Options LTW 6K-V / 8K-V Battery An electrically powered blanket (a) Blanket warms the battery while the machine is not in use. The blanket eliminates engine starting difficulties caused by a cold, frozen, or discharged battery. Plug the cord into a 120V power supply. wc_gr007422 Oil Pan Heater Cold, thick engine oil does not flow freely and may cause engine starting difficulties.
  • Page 71 LTW 6K-V / 8K-V Factory-Installed Options Containment A vertical pipe (e) with a 3/4" NPT Suction thread is provided next to the battery on Access Point the control panel side of the machine. The pipe extends into the containment skid tank, enabling suction cleanout of the tank.

  • Page 72: Maintenance

    Wacker Neuson. The use of service parts that are not equivalent in performance and durability to authorized parts may impair the effectiveness of the emission control system and may have a bearing on the outcome of a warranty claim.
  • Page 73 LTW 6K-V / 8K -V Maintenance Interval (hours of service) Before Item Task each 1 yr 2 yr Oil filter Replace. Radiator Flush. Fan belt Replace. Fuel tank Remove sedi- ment. Valve clearance Check and adjust as needed. Air filter element Replace.

  • Page 74: Removing And Replacing Lamps

    Maintenance LTW 6K-V / 8K -V Removing and Replacing Lamps Prerequisites Engine shut down Light circuit breakers turned OFF Lamps and fixtures cool to the touch Eye and hand protection WARNING Burn hazard. Lamps become extremely hot in use. Allow lamps and fixtures to cool 10–15 minutes before handling. WARNING Personal injury hazard.
  • Page 75 LTW 6K-V / 8K -V Maintenance Continued from the previous page. Perform the procedures below to remove and install the lamp. Removing the 1. Remove the screws (a) securing the flange rings (b) and remove the flange lamp rings. wc_gr005881 2.

  • Page 76: Inspecting The Machine

    Maintenance LTW 6K-V / 8K -V Inspecting the Machine When Daily Overview Inspect the machine before each use. A thorough inspection will help to identify mechanical faults or potentially unsafe operating conditions. Correct these problems before operating the machine. External Perform an external inspection of the machine.

  • Page 77: Checking The Engine Coolant Level

    LTW 6K-V / 8K -V Maintenance Checking the Engine Coolant Level When Daily Requirements Machine shut down Engine cool 50/50 coolant/water solution (as needed) NOTICE: Do not use water alone to fill the radiator. Use a long-life ethylene glycol coolant. Procedure Perform the procedure below to check the engine coolant level.

  • Page 78: Cleaning Air Filter Element

    Maintenance LTW 6K-V / 8K -V Cleaning Air Filter Element When Clean the air filter element every 100 hours. Procedure Perform the procedure below to clean the air filter element. 1. Remove the cover (b) from the air filter housing (a). 2.

  • Page 79: Changing Engine Oil

    LTW 6K-V / 8K -V Maintenance Changing Engine Oil WARNING Most used oil contains small amounts of materials that can cause cancer and other health problems if inhaled, ingested, or left in contact with skin for prolonged periods of time. Take steps to avoid inhaling or ingesting used engine oil.

  • Page 80: Maintaing The Fuel And Water Separator

    Maintenance LTW 6K-V / 8K -V Maintaing the Fuel and Water Separator When Drain bowl as needed Replace element every 250 hours (along with fuel filter) or as needed Requirements Container Replacement element Draining bowl Perform the procedure below to drain water bowl (a). wc_gr006235 1.

  • Page 81: Maintaining The Trailer

    LTW 6K-V / 8K -V Maintenance Maintaining the Trailer Tires Keep tires inflated to the proper pressure as shown on the tire sidewall. Check tread periodically for wear. Replace tires as required. Wheels Check that lug nuts holding wheels are tight. Replace any missing lug nuts immediately.

  • Page 82: Long-Term Storage

    Maintenance LTW 6K-V / 8K -V 6.10 Long-Term Storage Introduction Extended storage of equipment requires preventive maintenance. Performing these steps helps to preserve machine components and ensures the machine will be ready for future use. While not all of these steps necessarily apply to this machine, the basic procedures remain the same.

  • Page 83: Connecting And Maintaining The Battery

    LTW 6K-V / 8K -V Maintenance 6.11 Connecting and Maintaining the Battery WARNING Explosion hazard. Batteries can emit explosive hydrogen gas. Keep all sparks and flames away from the battery. Do not short-circuit battery posts. WARNING Battery fluid is poisonous and corrosive. In the event of ingestion or contact with skin or eyes, seek medical attention immediately.

  • Page 84: Troubleshooting

    Fuel circuit failure Check fuel lines. No generator output Main circuit breaker open Close main circuit breaker. Voltage regulator malfunction Call Wacker Neuson for service. Low oil pressure Low oil level Fill engine sump with oil. Clogged oil filter Replace oil filter.
  • Page 85 LTW 6K-V / 8K-V Troubleshooting Problem Cause Remedy Lamp will not light Lamp is too hot Allow lamp to cool 10–15 minutes before restarting. Faulty lamp connection Check that lamp is tight in socket. Check connections inside connection boxes on light fixtures and tower.

  • Page 86: Technical Data

    Technical Data LTW 6K-V / 8K-V Technical Data Engine Engine Power Rating Net power rating per ISO 3046 IFN. Actual power output may vary due to conditions of specific use. Machine LTW 6K, LTW 6K-V LTW 8K, LTW 8K-V Engine Make Kubota Model...

  • Page 87: Generator

    LTW 6K-V / 8K-V Technical Data Generator LTW 6K, LTW 6K-V, LTW 8K, LTW 8K-V, Machine LTW 6K-VS LTW 8K-VS Generator Make / Type Mecc Alte / Brushless Frequency Generator speed 1800 Continuous output AC voltage output volts/phase 120 / 240, 1Ø Amps 50 / 25 67 / 33...

  • Page 88: Machine - Ltw 6/8K-V

    Technical Data LTW 6K-V / 8K-V Machine - LTW 6/8K-V Machine LTW 6K-V LTW 8K-V Operating weight kg (lbs.) 1380.28 (3043) 1398.43 (3083) Dry weight kg (lbs.) 1194.31 (2633) 1212.45 (2673) Travel Dimensions cm (in.) 318 X 191 X 234 (125.2 X 75.2 X 92.1) (l x w x h) Height - tower extended m (ft.)

  • Page 89: Machine - Ltw 6/8K-Vs

    LTW 6K-V / 8K-V Technical Data Machine - LTW 6/8K-VS LTW 6K-VS LTW 8K-VS Machine LTW 6K-VS (custom) LTW 8K-VS (custom) LTW 6K-VS (CW) LTW 8K-VS (CW) Dry weight kg (lbs.) 1293 (2850.6) 1315 (2899.1) 1320 (2910.1) 1343 (2960.8) 1313 (2894.7) 1336 (2945.4) Dry weight kg (lbs.)

  • Page 90: Dimensions - Ltw 6K-V, Ltw 8K-V

    Technical Data LTW 6K-V / 8K-V Dimensions - LTW 6K-V, LTW 8K-V cm (in.) (92.1) 318 (125.2) 191 (75.2) wc_gr011510 Dimensions - LTW 6K-VS, LTW 8K-VS cm (in.) 256.5 (101) 332.8 190.5 (75) (131) wc_gr012194 Dimensions - LTW Skid cm (in.) (91) (104) 145 (57)

  • Page 91: Tire Safety Information

    Tire Safety Information Tire Safety Information Introduction to Tire Safety Information Federal Regulation 49 CFR 575 requires trailer manufacturers to include certain tire information in the owner’s manuals for the trailers they manufacture. This regulation requires that the information be in the English language. This chapter includes all the information required by Federal Regulation 49 CFR 575.
  • Page 92 Tire Safety Information 1. T AFETY NFORMATION This portion of the - Trailer . Section 1.1 contains Tow Vehicle . Section 1.2 contains Section 1.3 contains a Glossary of Tire Terminology -technical terms. Section 1.4 contains information from the NHTSA brochure entitled “Tire Safety – Everything Rides On It”. This brochure This brochure, as well as the preceding subsections, describes the following items;...
  • Page 93 Tire Safety Information Excessive loads and/or underinflation cause tire overloading and, as a result, abnormal tire flexing occurs. This situation can generate an excessive amount of heat within the tire. Excessive heat may lead to tire failure. It is the air pressure that enables a tire to support the load, so proper inflation is critical.
  • Page 94 Tire Safety Information Bead The part of the tire that is made of steel wires, wrapped or reinforced by ply cords and that is shaped to fit the rim. Bead separation This is the breakdown of the bond between components in the bead. Bias ply tire A pneumatic tire in which the ply cords that extend to the beads are laid at alternate angles substantially less than 90 degrees to the centerline of the tread.
  • Page 95 Tire Safety Information Intended outboard sidewall The sidewall that contains a white-wall, bears white lettering or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire or the outward facing sidewall of an asymmetrical tire that has a particular side that must always face outward when mounted on a vehicle.
  • Page 96 Tire Safety Information A layer of rubber-coated parallel cords. Ply separation A parting of rubber compound between adjacent plies. Pneumatic tire A mechanical device made of rubber, chemicals, fabric and steel or other materials, that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load. Production options weight The combined weight of those installed regular production options weighing over 2.3 kilograms (5 lbs.) in excess of those standard items which they replace, not previously considered in curb weight or accessory...
  • Page 97 Tire Safety Information Tread rib A tread section running circumferentially around a tire. Tread separation Pulling away of the tread from the tire carcass. Treadwear indicators (TWI) The projections within the principal grooves designed to give a visual indication of the degrees of wear of the tread.
  • Page 98 Tire Safety Information Use this information to make tire safety a regular part of your vehicle maintenance routine. Recognize that the time you spend is minimal compared with the inconvenience and safety consequences of a flat tire or other tire failure.
  • Page 99 Tire Safety Information 1.5.4. S TEPS FOR AINTAINING ROPER RESSURE Step 1: Locate the recommended tire pressure on the vehicle's tire information placard, certification label, or in the owner's manual. Step 2: Record the tire pressure of all tires. Step 3: If the tire pressure is too high in any of the tires, slowly release air by gently pressing on the tire valve stem with the edge of your tire gauge until you get to the correct pressure.
  • Page 100 Tire Safety Information 1.5.9.1. Information on Passenger Vehicle Tires Please refer to the diagram below. The "P" indicates the tire is for passenger vehicles. Next number This three-digit number gives the width in millimeters of the tire from sidewall edge to sidewall edge. In general, the larger the number, the wider the tire.
  • Page 101 Tire Safety Information Letter Rating Speed Rating 99 mph 106 mph 112 mph 118 mph 124 mph 130 mph 149 mph 168* mph 186* mph * For tires with a maximum speed capability over 149 mph, tire manufacturers sometimes use the letters ZR. For those with a maximum speed capability over 186 mph, tire manufacturers always use the letters ZR.
  • Page 102 Tire Safety Information Please refer to the following diagram. Tires for light trucks have other markings besides those found on the sidewalls of passenger tires. The "LT" indicates the tire is for light trucks or trailers. An "ST" is an indication the tire is for trailer use only. Max.

  • Page 103: Schematics

    LTW 6K-V / 8K-V Schematics Schematics This page is intentionally left blank. wc_tx003384gb.fm...

  • Page 104: Ltw 6K-Electrical Schematic

    Schematics LTW 6K-V / 8K-V LTW 6K—Electrical Schematic wc_gr011449...

  • Page 105: Ltw 6K-V-Electrical Schematic Components

    LTW 6K-V / 8K-V Schematics LTW 6K-V-Electrical Schematic Components Ref. Description Ref. Description Generator Light bar Engine controller Terminal strip Main circuit breaker Transformers Floodlights Capacitors, 24 mF Receptacle, 120V GFI Receptacle, 125/250V 30A Circuit breaker, 15A Capacitor, generator excitation Circuit breaker, 20A Fuse, 2A Wire Colors...

  • Page 106: Ltw 8K-Electrical Schematic

    Schematics LTW 6K-V / 8K-V LTW 8K—Electrical Schematic wc_gr011450...

  • Page 107: Ltw 8K-V-Electrical Schematic Components

    LTW 6K-V / 8K-V Schematics LTW 8K-V-Electrical Schematic Components Ref. Description Ref. Description Generator Terminal strip Engine controller Transformers Main circuit breaker Capacitors, 24 mF Floodlights Receptacle, 125/250V 30A Receptacle, 120V GFI Capacitor, generator excitation Circuit breaker, 15A Fuse, 2A Circuit breaker, 20A Circuit breaker, 30A (250V) Light bar...

  • Page 108: Engine Wiring

    Schematics LTW 6K-V / 8K-V Engine Wiring wc_gr006502...

  • Page 109: Engine Wiring Components

    LTW 6K-V / 8K-V Schematics Engine Wiring Components Ref. Description Ref. Description Emergency stop switch Battery Control panel ground Terminal block Engine controller Hour meter Main breaker Starter motor Engine ground Alternator Control box ground Fuel pump relay Oil pressure sensor Starter relay Water temperature sensor Glow plug relay...

  • Page 110: Trailer Wiring (Electric Brakes)

    Schematics LTW 6K-V / 8K-V Trailer Wiring (Electric Brakes) 47-WH 6-BR 2-GN 5-YL 64-BR 44-WH 34-BU 34-BU 33-BU 4-WH 3-BU wc_gr011779 Trailer Wiring Components (Electric Brakes) Ref. Description Ref. Description Main trailer plug Left brake Breakaway switch Front right side light Battery charger Front left side light Breakaway battery...

  • Page 111: Trailer Wiring (Surge Brakes / No Brakes)

    LTW 6K-V / 8K-V Schematics Trailer Wiring (Surge Brakes / No Brakes) Wire Colors Black Yellow Orange Green Brown Purple Blue Violet Clear Shield Pink White Gray Lt. blue wc_tx003384gb.fm...
  • Page 114 Wacker Neuson Production Americas LLC, N92W15000 Anthony Ave., Menomonee Falls, WI. 53051 Tel.: (262) 255-0500 Fax: (262) 255-0550 Tel.: (800) 770-0957 Wacker Neuson Limited - Room 1701–03 & 1717–20, 17/F. Tower 1, Grand Century Place, 193 Prince Edward Road West, Mongkok, Kowloon, Hongkong. Tel: (852) 3605 5360, Fax: (852) 2758 0032...

This manual is also suitable for:

Ltw6k-vsLtw8k-vLtw8k-vs520001286452000128685200012882 ... Show all

Table of Contents
