MOVING HEAD
OMNIA HYBRID-250
MANUAL
WIDE AND FAST ZOOM
HIGH BRIGHTNESS
LED SOURCE
LIGHTWEIGHT
HOUSING
www.light-inc.nl
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNIA HYBRID-250 and is the answer not in the manual?

Questions and answers

Related Manuals for LIGHT INC OMNIA HYBRID-250

Summary of Contents for LIGHT INC OMNIA HYBRID-250

  • Page 1 MOVING HEAD OMNIA HYBRID-250 MANUAL WIDE AND FAST ZOOM HIGH BRIGHTNESS LED SOURCE LIGHTWEIGHT HOUSING www.light-inc.nl...

  • Page 2: Table Of Contents

    CONTENTS PAGE 1. Safety Information 2. Technical Information 3. Photometric 4. Display 5. Menu 6. Wiring Chart 7. DMX Chart 8. Error Messages 9. Cleaning and Maintenance 10. Notes...

  • Page 3: Safety Information

    THANK YOU FOR PURCHASING OUR PRODUCTS Every unit has been thoroughly tested and has been shipped in perfect operating condition. Carefully check the outer and inner packaging for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your fixture for any damage and be sure all accessories necessary to operate the unit have arrived intact.

  • Page 4: Technical Information

    2. TECHNICAL INFORMATION POWER COLORS Voltage: AC100~240v,50/60Hz 1 color wheel with 8 color + white Source: 250W white LED Indexable, bidirectional infinite color rotation effect Power consumption: 320W 7200K Life: >20,000H Open MOVEMENT Pan movement: 540° (16 bit) Blue Tilt movement: 270°...

  • Page 5: Dimensions And Weight

    FEATURES DISPLAY DMX channels: 19/25CH 2.8 inch LCD display with English/Chinese menu Prism: 5 facet circular rotating prism Auto lock and display flip Motorized Focus Motorized zoom: CONTROL 2.7°- 45° linear zoom Various strobe DMX, Auto, Manual Linear heavy frost Dimming: DIMENSIONS AND WEIGHT 0-100% linear dimming...

  • Page 6: Photometric

    3. PHOTOMETRIC...

  • Page 7: Display

    4. DISPLAY Shows the various menu options and selected functions. Button: ENTER Choose the selected function DOWN Move down in the menu MENU To enter into, or leave the menu To go back or move up in the menu ETHERNET: Transfers fixture’s information to a main controller.
  • Page 8 Rotating Gobo Wheel 000 - 255 Gobo Rotation 000 - 255 Fix Gobo Wheel 000 - 255 Mode Manual Control Prism 000 - 255 Prism Rotation 000 - 255 Frost 000 - 255 Control 000 - 255 Display Reverse Auto Display Keylock Celsius...

  • Page 9: Wiring Chart

    Zoom Focus Calibrate Password / 8 Prism Prism Rot. Frost Pan / Tilt Motor Reset Color Gobo Other Reset Default Menu Chinese Language English User Time Password Set IP 000.000.000.000 Ethernet * Set Mask IP 000.000.000.000 Set Universe 001-512 Software Version V1.00 Current Time Time Info...

  • Page 10: Dmx Chart

    OMNIA HYBRID-250 DMX ADDRESS SETTING All OMNIA HYBRID-250 fixtures must have a DMX start address correctly set when using a DMX signal to control them. The DMX start address is the channel from which the OMNIA HYBRID-250 “listens” to the digital control information sent by the DMX controller.
  • Page 11 DMX Mode Value Function 19CH 25CH Dimmer intensity: 0-255 Intensity 0 to 100% Dimmer intensity Fine: 0-255 Dimmer intensity fine Zoom: 0-255 Zoom adjustment from small to big Zoom Fine: 0-255 Zoom adjustment Fine Focus: 0-255 Continuous adjustment from near to far Focus Fine: 0-255 Continuous adjustment Fine...
  • Page 12 DMX Mode Value Function 19CH 25CH 86-98 Rot. gobo7 99-111 Rot. Gobo 1 shake slow to fast 112-124 Rot. Gobo 2 shake slow to fast 125-137 Rot. Gobo 3 shake slow to fast 138-150 Rot. Gobo 4 shake slow to fast 151-163 Rot.
  • Page 13 DMX Mode Value Function 19CH 25CH Prism 0-127 Open 128-255 Prism Rotating prism index, rotating prism rotation 0-127 Prism indexing 128-189 Forwards prism rotation from fast to slow 190-193 No rotation 194-255 Backwards prism rotation from slow to fast Rotating prism indexing Fine 0-255 Fine indexing Frost...

  • Page 14: Error Messages

    8. ERROR MESSAGES When you turn on your OMNIA HYBRID-250, it will first perform an automatic reset. The display may show “Err channel is XX” indicating there is a problem with one or more of the channels. “XX”represents channel 1, 2, 3, 4, 5 or 6, which contain the testing sensor for positioning.

  • Page 15: Cleaning And Maintenance

    Frost Er (Frost - error) This message will appear after the reset of the fixture if the head’s magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the steppermotor is defective (or its driving IC on the main PCB).The Frost 1 - movement is not located in the default position after the reset. 9.
  • Page 18 ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE BSL B.V. SPAARPOT 19 | 5667 KV GELDROP | THE NETHERLANDS | +31 (0)40 750 24 95 WWW.BSL-LIGHTING.COM | WWW.LIGHT-INC.EU...
