Summary of Contents for CYC Motor DS103
- Page 1 User Guide CYC MOTOR LTD www.cycmotor.com...
- Page 2 Switch Dashboard .......................... 6 Assist Levels Select ......................... 7 Dark & Light Theme ........................9 Walk Assist ............................ 10 Error Codes ............................11 Installation ............................11 Compatibility ............................ 12 Pin Layout ............................12 Certification ............................12 © 2024 CYC MOTOR LTD...
- Page 3 Intelligent LCD display, model: DS103 Firmware: CYC MOTOR LTD specific firmware • Simple and lightweight, separate installation bracket design • High brightness, high contrast 3.5 coloured TFT screen • Clock function (clock is on when the display shutdown) • Excellent outdoor design with IP65 level waterproof •...
- Page 4 • Waterproof level: IP65 After unboxing and installing your CYC motor system, there are two main things you need to set 1. Change your Battery No. settings according to your rated voltage. Upon startup, long press the MENU button within 15 seconds to access the SETTINGS page. Press UP/DOWN to navigate the settings page &...
- Page 5 Press and hold the POWER button for 3 seconds to turn the display on/ off. MENU The MENU button is used to go into your main settings page & your clear data page. It is also used to enter and DOWN select a setting or function. ON / OFF © 2024 CYC MOTOR LTD...
- Page 6 Wait 15 seconds after starting up the motor system to enter the “Clean Data” menu. Long press the MODE button to clear previous trip data. Please note that trip data does not automatically clear once the motor system is restarted. It is a manual process. © 2024 CYC MOTOR LTD...
- Page 7 Upon startup, long press the MENU button within 15 seconds to access the SETTINGS page, then select TRIP MODE to swap between STREET and RACE mode. Switch the main dashboard to display different information by pressing the MENU button. © 2024 CYC MOTOR LTD...
- Page 8 There are 3 sets of assist levels; 3, 5 & 9. To change the assist levels set, long press the MENU button upon within 15 seconds upon startup and access ALL GEAR in the main settings page. © 2024 CYC MOTOR LTD...
-
Page 9: Assist Levels
APP ASSIST LEVEL 3 ASSIST LEVELS 5 ASSIST LEVELS 9 ASSIST LEVELS 0 (Neutral) 0 (Neutral) 0 (Neutral) 1 – 0.3 (30% BY DEFAULT) 2 – 0.6 (60% BY DEFAULT) 3 – 1 (100% BY DEFAULT) © 2024 CYC MOTOR LTD... - Page 10 26 x 1.9 47 – 559 2055 26 x 2.125 54 – 559 2070 29 x 2.1 54 – 622 2288 29 x 2.2 56 – 622 2298 29 x 2.3 60 – 622 2326 © 2024 CYC MOTOR LTD...
- Page 11 Hold in the DOWN button to activate walk assist. Please note it takes 3 seconds to activate & will deactivate immediately when the button is released. © 2024 CYC MOTOR LTD...
- Page 12 In certain circumstances, an error code may appear on your display. Contact us for assistance. Error Code on App & DS103 Display Controller Over Voltage Controller Under Voltage Controller Over Temperature Hall Sensor Error Throttle Error Speed Sensor Error Controller Internal Error 1...
- Page 13 TxD (display -> controller) Green Wire: RxD (controller -> display) Blue wire: Power cord to the controller CE / IP65 (waterproof) / ROHS Be sure to contact us if further assistance is needed. Thank you! © 2024 CYC MOTOR LTD...
