- Page 1 SW102 DISPLAY User Guide CYC MOTOR support@cycmotor.com +952 3690 8938...
-
Page 2: Table Of Contents
SW102 Display User Guide TABLE OF CONTENTS SW102 Display User Guide ..............3 Product Details ........................... 3 Dimensions & Materials ........................3 Quick Start Guide ..........................4 Functionalities ............................ 5 Installation ............................9 Pin Layout ............................9 Certification ............................9... - Page 3 SW102 Display User Guide © 2023 CYCMOTOR LTD...
-
Page 4: Sw102 Display User Guide
SW102 Display User Guide SW102 Display User Guide Product Details Product Name Intelligent OLED display, model: SW102 Firmware: CYCMOTOR LTD specific firmware Features • Minimalist design and process • High brightness, high contrast 1.3-inch monochromatic OLED screen • Excellent outdoor design with IP65 waterproof rating Dimensions &... -
Page 5: Quick Start Guide
SW102 Display User Guide Quick Start Guide After unboxing and installing your CYC motor system, there are two main things you need to set 1. Change your Battery No. setting according to your rated voltage. a. Within 15 seconds of turning on your display, long press the MENU button to enter the settings functions. -
Page 6: Functionalities
SW102 Display User Guide Functionalities Power On/Off Press and hold the POWER button for 2 seconds to turn the display on/off. The display will automatically shut down when there is no operation for a period of time. Navigation 1. POWER 2. - Page 7 SW102 Display User Guide Switch Dashboard Switch the main dashboard to display different information by pressing the MENU button. Assist Level Operating Press the UP/DOWN button to change the assist level between level 1, 2, and 3. Please note that “OFF”...
- Page 8 SW102 Display User Guide Walk Assist Long press the DOWN button to activate walk assist. Note that it takes 3 seconds to activate & will deactivate immediately when the button is released. Walk assist can only be activated if you are in assist level 1, 2, or 3.
- Page 9 This is a manual process. Error Codes In certain circumstances, an error code may appear on your display. Contact us for assistance. Error Code on SW102 Display Error Code on App Controller Over Voltage...
-
Page 10: Installation
SW102 Display User Guide Installation Open the display lock clip, set the display in the left handlebar (standard handlebar size Φ22.2). Adjust it in place and tighten the screw accordingly. Note: Damage caused by excessive torque is not covered by warranty.
