HOMCOM 370-142V70 Manual Book page 2

Installation Order Diagram
1.Front axle and front spring assembly
First, put the flat iron on the front axle. Put 1pcs front spring to each
side of square tube. Then insert the front axle into the hole of square
tube, add 1pcs washer and use spanner to tighten the nut. The same
way for the other side. Direction lever should be passed through the
hole of front axle, then add 1pcs small washer and use spanner to
thighten the nut.
2.
2.Front wheel assembly
Add 1pcs big washer, 1pcs wheel, 1pcs small washer step by step, use
spanner to tighten the nut. Finally put the small wheel cover on. The
same way for the other side.
3.Rear spring and rear spring holder assembly
Insert the rear spring holder into the reserved place on the car body,
use 8pcs M4*14 screw to tighten.
4.Rear axle and motor assembly
Insert the rear axle through the holes of rear spring holder. Add
1pcs motor, 1pcs wheel, 1pcs small washer step by step, use
spanner to tighten the nut. The same way for the other side.
5.Door and rearview mirror holder assembly
Insert the door into the reserved place on the car, then insert the
rearview mirror holder into the reserved place on the car and door.
Use 2pcs M4*14 screw to tighten. The same way for the other side.
6. Steering wheel assembly
Unscrew the steering wheel, insert steering wheel into the
direction lever, use screw and nut to tighten. .
7.Windshield, rearview mirror, search light
holder, search light assembly
Insert the windshield, rearview mirror, search light holder into the
reserved place on the car. Then insert tinsert the search light into
the search light holder.
8.Motor line and battery line connection
Connect the motor line correctly.
Connect the red battery line to the red terminal.
1
9.Seat assembly
Insert the seat into the reserved
place on the car, usd 2pcs M4*14
screw to tighten.
.
10.Switch the remote control and manual switch
1. Remove the screw from the switch cover by a screwdriver.
2. Open the switch cover, switch the remote control and
manual switch. Under remote control mode, the car can only
be operated by remote control, the foot can not be operated.
Under manual mode, the car drive can only be operated by
foot, remote control can not be operated.
Warnings
For children's safety, please read these carefully.
Assembly and adjustment must be done by adults, keepchildren away.
Keep children under 36 months away from small parts.
Safe belt is a must when children playing. Do not be close to fire.
Adult must teach how to play it and never leave children alone for playing.
Do not stand up or play when children are stepping on foot pedal.
Battery must be charged by adults only. Please charge it
first before use.
Keep children away from plastic bag, or suffocation may occur.
Only use spare parts which provided by manufacturer.
Charger is not a toy for playing.
Maximum loading capacity is 30KG. Do not overload.
Suitable age: 37-95 months.
Safety use
Do not play in the street, road, slope or ditch.
Do not change the line or add electric device to the car.
Play the car in the dry area, not wet. Keep away from fire,
or may damage the line.
One or two riders one time only. Do not overload.
Maximum capacity is 30KG.
Turn power off if no use. If long time no use,
unplug battery line.
Check battery, charger and other spare parts regularly.
If any problem, please fix it before playing.
Charging notification
For the first use, please charge 8-12 hours, or will damage
the battery.
Plug charger DC line into charge hole first, then plug
charger into socket. Car can not be played when it charging.
Every time it charged, do not charge more than 20 hours.
It is normal that charger and battery warm (under 60°)
during charging.
Do not charge if plug is wet, or will occur short-circuited.
Only use charger provided by manufacturer, or will damage
charger and battery or occur short-circuited.
If long time no use, please charge 1 time per month at least.
Charging steps are as follows:
Step 1: The charging hole is on the multi-functional board.
Step2: Put the charger plug into the plug hole.
Step 3: Connect the charger to the power socket.
Warning: Car must be charged by adults only. Car is useless
during charging
Maintenance and Service
Check battery, charger and other spare parts regularly. If any
problem, please fix it before playing.
and sunshine. Park it on the even place, not reversal or
gradient.
melt.
Keep away from flammable things, or may occur fire accident.
time no use, please charge it 1 time per month, in order to
maintain battery.
solvent to wipe plastic parts. Do not wash it with water or play
it when raining or snowing. Water will damage motor, electric
system or battery.
' s structure or electric line. Check job
request some skills or under specialist' s guidance.
